LEC-EL Product specification
4.4.1
GPIO
Name
Pin #
Description
GPIO0 /
P108
General purpose I/O pin 0.
CAM0_PWR#
GPIO1 /
P109
General purpose I/O pin 1.
CAM1_PWR#
GPIO2 /
P110
General purpose I/O pin 2.
CAM0_RST#
GPIO3 /
P111
General purpose I/O pin 3.
CAM1_RST#
GPIO4 /
P112
General purpose I/O pin 4.
HDA_RST#
GPIO5 /
P113
General purpose I/O pin 5.
PWM_OUT
GPIO6
P114
General purpose I/O pin 6.
GPIO7
P115
General purpose I/O pin 7.
GPIO8
P116
General purpose I/O pin 8.
GPIO9
P117
General purpose I/O pin 9.
GPIO10
P118
General purpose I/O pin 10.
GPIO11
P119
General purpose I/O pin 11.
GPIO12
S142
General purpose I/O pin 12
GPIO13
S123
General purpose I/O pin 13
Page 11
I/O
I/O
Power
PU / PD
Type
Level
Domain
I/O
1.8V
Runtime
PU 470K on the Module.
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
I/O
1.8V
Runtime
PU 470K on the Module
CMOS
copyright © 2021 ADLINK Technology Inc.
SGET SMARC Rev 2.1
Comments
Default use is GPIO0, alternative use is Camera 0
Power Enable - active low, through DTS
Default use is is GPIO1 alternative use is Camera 1
Power Enable - active low, through DTS
Default use is GPIO2, alternative use is Camera 0
Reset - active low, through DTS
Default use is GPIO3, alternative use is Camera 1
Reset - active low, through DTS
