Quectel SC200R Series Hardware Design page 105

LTE-FDD B5
LTE-FDD B8
LTE-TDD B34
LTE-TDD B38
LTE-TDD B39
LTE-TDD B40
LTE-TDD B41
Table 52: SC200R-EM RF Output Power
Frequency
GSM850
EGSM900
DCS1800
PCS1900
WCDMA B1
WCDMA B2
WCDMA B4
WCDMA B5
WCDMA B8
LTE-FDD B1
LTE-FDD B2
LTE-FDD B3
LTE-FDD B4
LTE-FDD B5
LTE-FDD B7
SC200R&SC262R_Series_Hardware_Design
23 dBm ± 2 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
Max.
33 dBm ± 2 dB
33 dBm ± 2 dB
30 dBm ± 2 dB
30 dBm ± 2 dB
24 dBm +1/-3 dB
24 dBm +1/-3 dB
24 dBm +1/-3 dB
24 dBm +1/-3 dB
24 dBm +1/-3 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
23 dBm ± 2 dB
Smart Module Series
< -39 dBm
< -39 dBm
< -39 dBm
< -39 dBm
< -39 dBm
< -39 dBm
< -39 dBm
Min.
5 dBm ± 5 dB
5 dBm ± 5 dB
0 dBm ± 5 dB
0 dBm ± 5 dB
< -49 dBm
< -49 dBm
< -49 dBm
< -49 dBm
< -49 dBm
< -39 dBm
< -39 dBm
< -39 dBm
< -39 dBm
< -39 dBm
< -39 dBm
