Chapter 1: Introduction
5. The Date/Time Settings are displayed. Tap Next to con-
tinue after making any adjustments.
Select Time 12-hour or 24-hour format
Format:
Select Date DD/MM/YYYY, MM/DD/YYYY, or YYYY/
Format: MM/DD
Select Time
Time zone offset from Greenwich Mean
Zone: Time
Set Date:
Set the current date
Set Time:
Set the current time in the selected time
zone
The Test Settings are displayed. Tap Next to continue after
6.
making any adjustments.
Battery
Default: CCA (Cold Cranking Amps)
Rating
Temperature
Select Fahrenheit or Celsius
Units
Decimal Select decimal point or comma
Separator
7. A list of devices connected to the tester is displayed.
To add a device, tap the plus (+) sign and follow the
on-screen instructions. To unlink from a device, tap the
displayed serial number to select it. Tap the trash can icon
3
( ) to delete it.
NOTE: A passkey number is automatically gener-
ated once the Bluetooth pairing has been estab-
lished.
Tap the check box to require an Amp Clamp when
performing a System Test.
8. A listing of detected Configured WiFi networks is dis-
played.
To select a network: For initial setup, no networks will be
displayed here yet.
To add a network: Tap the plus (+) sign, then select from
one of the displayed detected networks.
To manually add a network, tap the plus (+) sign again.
Follow the on-screen instructions to select the Network
SSID, Security, and IP Settings. Tap Next when finished.
Use the onscreen keypad to manually enter the Network
SSID, security type, and IP settings. If necessary, enter the
WiFi network password. Tap Next when finished.
A confirmation screen is displayed when the analyzer has
successfully connected to the WiFi network.
To delete a network: Tap a displayed network to select it.
Tap trash can icon ( 3 ) to delete it.
9. The BMIS (Battery Management Information System) Ac-
count screen is displayed.
Tap Yes to connect the analyzer to an existing BMIS
account. Enter a BMIS User Name and Password for the
analyzer to use when transmitting test data to the BMIS
database.
Tap No to skip this step.
10. The Email Address Book screen (Admin Only) is displayed.
To add an email address: Tap the plus (+) sign, then use
the displayed keyboard to add the address.
To edit an email address: Tap the pencil
the displayed keyboard to edit the address.
To delete an email address: Tap a displayed email address
to select it. Tap trash can icon (
To use the Default Email Server Settings: Tap the gear
icon to use the default.
11. The Shop Information screen (Admin Only) is displayed
Use the onscreen keypad to enter the store name, address,
and phone number. Tap Next to continue.
Store Name
Street Address
Street Address 2
City
State
Zipcode
Phone #
12. The login screen is displayed.
13. Tap a user name to access the Main Menu.
8
DSS-5000
icon, then use
3 ) to delete it.
Midtronics
7000 Monroe
Willowbrook
IL
60527
1-630-323-2800
93%
Select User
Guest
admin
Add User
