2.6 Multi I/O

SATA: Supports two SATA ports at 6 Gb/s and two ports at 3 Gb/s with support for
RAID 0,1,5,10
USB: Supports up to eight ports USB 2.0
SSD: Optional SATA based Solid State Disk, 8/16/32 GB

2.7 Super I/O

Connected to LPC bus on carrier if needed

2.8 TPM (Trusted Platform Module)

Chipset: Infineon SLB9635TT1.2
Type: TPM 1.2

2.9 Power Specifications

Input Power: AT mode (12 V +/- 5%) and ATX mode (12 V and 5 Vsb +/- 5%)
Power States: supporting S0, S1, S3, S4, S5
Smart Battery Support: yes
Page 10
Express-HR User's Manual
