Signal Descriptions (cont'd)

Pin

Signal

C56

PEG_RX1-

C57

TYPE1#

C58

PEG_RX2+

C59

PEG_RX2-

C60

GND

C61

PEG_RX3+

C62

PEG_RX3-

C63

RSVD

C64

RSVD

C65

PEG_RX4+

C66

PEG_RX4-

C67

RSVD

C68

PEG_RX5+

C69

PEG_RX5-

C70

GND

C71

PEG_RX6+

C72

PEG_RX6-

C73

RSVD

C74

PEG_RX7+

C75

PEG_RX7-

C76

GND

C77

RSVD

C78

PEG_RX8+

C79

PEG_RX8-

C80

GND

C81

PEG_RX9+

C82

PEG_RX9-

C83

RSVD

C84

GND

C85

PEG_RX10+

C86

PEG_RX10-

C87

GND

C88

PEG_RX11+

C89

PEG_RX11-

C90

GND

C91

PEG_RX12+

C92

PEG_RX12-

C93

GND

C94

PEG_RX13+

C95

PEG_RX13-

C96

GND

C97

RSVD

C98

PEG_RX14+

C99

PEG_RX14-

C100

GND

C101

PEG_RX15+

C102

PEG_RX15-

C103

GND

C104

VCC_12V

C105

VCC_12V

C106

VCC_12V

C107

VCC_12V

C108

VCC_12V

C109

VCC_12V

C110

GND
