2 Introduction

Before you start using the InfoAlarm Operator's Manual, it is important to understand the typographic conventions used in this publication.
Note: Throughout this document, the terms "panel" and "system" can be replaced with "4100U/4100ES" or "4010ES", depending on the Fire
Alarm Control Panel (FACP) used.
2.1

InfoAlarm Conventions

InfoAlarm features six softkeys arrayed beside the LCD. The function of these softkeys varies depending on the icons displayed on the
screen. When describing the action of the softkey, the following convention is used.
Convention
"title" softkey
Note: All commands and screens shown in this document are based on the default English setup. Titles of commands may differ
depending on the display language; however, the functions remain the same as the English version.
page 4
Figure 1: LCD with Softkeys Cutaway
Table 1: Conventions
Indicates the softkey beside the icon containing the same title as the phrase in quotations. For
example, the "Menu" softkey in Figure i would refer to the button directly to the right of the
Menu icon.
