LED/Key
Fire Alarm LED and Fire Alarm ACK Key
Priority 2 Alarm LED and Priority 2 Ack Key
System Supervisory LED and Supv ACK key
System Trouble LED and Trouble ACK
Alarm Silenced LED/Alarm Silence Key
System Reset Key
AC Power LED
Entry Keypad
Menu Key
Enter Key
Facility-Specific Control Keys
Page Up/Page Down Keys
Previous/Next
InfoAlarm Softkeys
LCD
Note: The degree to which you are allowed to control the system depends on the passcode assigned to you. See "Logging In and Out of
the System" for details on this.
page 6
Table 2: InfoAlarm controls
The Fire Alarm LED flashes to indicate the presence of an unacknowledged alarm condition.
Other components of the system, such as the horns and strobes, also activate to indicate
the presence of an alarm. The FIRE ALARM ACK key allows you to indicate that you have
observed the presence of an alarm.
The Priority 2 Alarm LED flashes to indicate the presence of an abnormal condition with
sprinkler systems.
The System Warning LEDs - Supervisory and Trouble - indicate when abnormal, non-fire
conditions occur to the fire alarm system's wiring or devices. The system warning keys -
SUPV ACK - allow an operator to acknowledge the presence of the abnormal condition.
The System Trouble LED flashes to indicate the presence of an unacknowledged trouble
condition. Other components of the system may be programmed to activate and indicate
the presence of a trouble. The TROUBLE ACK key allows you to indicate that you have
observed the presence of a trouble.
Pressing the ALARM SILENCE key provides a means of silencing the building's audible
notification appliances (horns). The LED indicates when this key has been used.
Pressing this key directs the panel to reset all attached devices and clear all acknowledged
alarms, troubles, and supervisory conditions.
Indicates the presence of AC power at the panel.
Used to call up points for monitoring and control.
Selects the main menu programmed in InfoAlarm
Processes the command displayed on the screen.
These are programmable keys. Typical functions include manual evacuation and ground fault
monitor.
Pressing these keys moves the cursor up or down by one screen. Holding the key for 2
seconds shifts the cursor to the top or bottom of the displayed information.
Pressing these keys moves the cursor up or down by one line. Holding the key shifts the
cursor up or down by one line at a 1/4 second increment.
These keys conform to the image on the LCD and can change depending on the menu that
has been selected.
Displays text describing abnormal conditions for devices attached to the panel (e.g., a smoke
detector in the main lobby is in alarm). Also displays system prompts and messages.
InfoAlarm Operator's Manual 4100U, 4100ES, 4010ES
Description
579-685 Rev. D
