4100/4120 INSTALLATION MANUAL

CONTRACTOR INSTALLATION INSTRUCTIONS

THE INSTALLER IS RESPONSIBLE FOR SAFEGUARDING ALL 4100+ MATERIAL SHIPPED TO THE JOB SITE.

DURING SYSTEM INSTALLATION, STORE ALL 4100+ ITEMS (INCLUDING ALL DOCUMENTATION) IN A CLEAN,

DRY AND SAFE PLACE UNTIL NEEDED.

NOTIFY APPROPRIATE PERSONNEL (BUILDING OCCUPANTS, FIRE DEPARTMENT, MONITORING FACILITY,

ETC.) IF AN EXISTING SYSTEM MUST BE SHUT DOWN WHILE THE 4100+ SYSTEM IS BEING INSTALLED.

This publication provides a logical sequence of procedures to follow when installing a 4100+ system. Throughout this

publication, you are often referred to the documentation listed below. In such cases, notes describing use of the

documents will generally follow immediately after the reference.

The envelope that contained this publication also contains the following documents:

• 4100+/4120/UT Back Box Installation Instructions (Pub. No. FA4-21-203)

• Factory Documentation (packed in a clear plastic envelope)

• 4100 Field Wiring Diagram (841-731)

• Field Wiring Diagrams, Smoke Detectors (841-687)

• Field Wiring Diagrams, MAPNET II

• 4100/4100+ Fire Alarm Operating Instructions (Pub. No. FA4-31-201)

Except for the last publication, all of the above documents are required for system installation.

Document No: 4100-M002

* * * IMPORTANT * * *

* * * * * * * * * * * *

Devices (841-804)

Issue 1.0
