2.2 Installing the Backplane or Motherboard/安装无
源底板或母板/安裝背板或主機板
To install backplane or motherboard into the chassis, please find the yellow label in
the chassis; follow the label indications to screw the cooper stubs into the correct
locations.
安装底板或母板到機箱之前，请先找到机箱上的黄色标签，并将铜柱安装在正确位
置。
安裝底板或主機板到機箱之前，請先找到機箱上的黃色標籤，並將銅柱安裝在正確位
置。
PCA-6113P4R
PCA-6114P7
PCA-6114P12
PCA-6114P4
PCA-6114P10
PCA-6114
PCE-5B10
PCE-5B12
PCE-5B13
PCE-5B12D
PCE-7B13
AIMB-5 series
AIMB-7 series
ASMB-7 series
ASMB-805
ASMB-815
ASMB-816
Figure 2.2: Yellow Label Indicating Copper Stub Locations
ACP-4010 User Manual/用户手册/用戶手冊
Max. Torque of copper stub 10kgf・ cm
