4.5
Pin Definitions/ 针脚定义 / 針腳定義
Table 4.8: SMB_MB1
Pin 1
I2C_SCLK
Table 4.9: IPMB1
Pin 1
NC
Pin 2
S_SCLK_R
Table 4.10: PMBUS1
Pin 1
+V_PMBUS
Pin 2
GND
Pin 3
NC
Table 4.11: SMB_3V_1
Pin 1
+V_SMB
Pin 2
M_SCLK_R
Table 4.12: SMB_3V_2
Pin 1
+V_SMB
Pin 2
M_SCLK_R
Table 4.13: LEDBOARD1
Pin 1
GND
Pin 2
+V5_R
Pin 3
+V12_R
Pin 4
-V5_R
Pin 5
-V12_R
Pin 6
HDD_LED
Pin 7
P-G_LED
Pin 8
P-F_LED
Table 4.14: VOLT1
Pin 1
+V5_SB
Pin 2
GND
Pin 3
GND
Pin 4
-V5
Table 4.15: TR1~4
Pin 1
TEMP_SEN1~4
Pin 2
I2C_SDAT
Pin 3
S_SDAT_R
Pin 4
GND
Pin 4
I2C_SDAT
Pin 5
I2C_SCLK
Pin 3
M_SDAT_R
Pin 4
GND
Pin 3
M_SDAT_R
Pin 4
GND
Pin 9
T-G_LED
Pin 10
T-F_LED
Pin 11
F-G_LED
Pin 12
F-F_LED
Pin 13
NC
Pin 14
+V3.3_R
Pin 15
+V5_SB_R
Pin 5
+V5
Pin 6
+V3.3
Pin 7
-V12
Pin 8
+V12
Pin 2
GND
31
ACP-4010 User Manual/用户手册/用戶手冊
