Configuration and Use Manual
P/N 20002983, Rev. A
October 2005
Micro Motion
Model 3711
Gas Flow Computers
Configuration and Use Manual
®

Advertisement

Table of Contents
loading

Related Manuals for Emerson Micro Motion 3711

Summary of Contents for Emerson Micro Motion 3711

  • Page 1 Configuration and Use Manual P/N 20002983, Rev. A October 2005 ® Micro Motion Model 3711 Gas Flow Computers Configuration and Use Manual...
  • Page 2 Motion, Inc., Boulder, Colorado. MVD and MVD Direct Connect are trademarks of Micro Motion., Inc., Boulder, Colorado. Micro Motion is a registered trade name of Micro Motion, Inc., Boulder, Colorado. The Emerson logo is a trademark of Emerson Electric Co. All other trademarks are property of their respective owners.

  • Page 3: Table Of Contents

    Contents Chapter 1 Before You Begin ........1 Overview .
  • Page 4 Contents Chapter 4 Setting Up Communications......25 Overview ............25 Communications overview .
  • Page 5 Contents Configuring an analog output ......... . 67 7.5.1 Analog Output –...
  • Page 6 Contents Chapter 11 Function Sequence Tables ......107 11.1 About this chapter ..........107 11.2 FST overview .
  • Page 7 Contents 13.3 Initial calculations and recalculations ........153 13.4 Viewing sensor alarms and communication statistics .
  • Page 8 Contents 15.18 Checking sensor pins ..........184 15.18.1 Remote core processor with remote transmitter installation .

  • Page 9: Chapter 1 Before You Begin

    Chapter 1 Before You Begin Overview This chapter provides an orientation to the use of this manual, and includes a pre-configuration worksheet. This manual describes the procedures required to start, configure, use, maintain, and ® troubleshoot the Micro Motion Model 3711 Gas Flow Computer system. Safety Safety messages are provided throughout this manual to protect personnel and equipment.

  • Page 10: Implementation Overview

    Before You Begin 1.3.3 Implementation overview A typical Model 3711 gas measurement system is configured to write measurement data to history at minute, hourly, daily, and user-specified intervals. The history data is then delivered to an external system for various accounting and analysis procedures. The delivery interval is controlled by the user. The event and alarm logs contain information related to configuration changes and various system conditions.

  • Page 11: Basic Configuration

    Before You Begin 6. Configure the following parameters for volumetric flow measurement: • Averaging technique – see Section 6.3.1 • Pressure compensation – see Section 6.3.2 • Gas quality data – see Section 6.4 • Pressure data for pressure compensation – see Section 6.4.1 1.5.2 Basic configuration To perform a complete basic setup, the following tasks are required:...

  • Page 12: Model 3711 Administration Overview

    Before You Begin Model 3711 administration overview To administer the Model 3711 effectively, you should know why, when, and how to perform the following tasks: • Writing to flash memory • Saving configuration to a file • Downloading configuration data to the Model 3711 •...

  • Page 13: Chapter 2 Getting Started

    Chapter 2 Getting Started Overview This chapter discusses the following topics: • Starting the Model 3711 • Installing ROCLINK 800 • Using ROCLINK 800 • Configuration files • Defining groups and devices • Connecting to the Model 3711 Starting the Model 3711 To start the Model 3711: 1.

  • Page 14: Installing Roclink 800

    Getting Started On initial power-up, all configuration parameters are set to default values. If your unit includes the optional dial-up modem card, set it to Auto Answer before supplying power. (Auto Answer is the default setting.) To remove power from the unit, insert the power jumper into the OFF slots (the left and center slots). After initial power-up, there are several ways to initialize the Model 3711.

  • Page 15: Using Roclink 800

    Getting Started Using ROCLINK 800 This section describes how to start ROCLINK 800, how to log into ROCLINK 800, and how to connect from ROCLINK 800 to the Model 3711. 2.4.1 Starting ROCLINK 800 You can start ROCLINK 800 using any of the following methods: •...
  • Page 16 Getting Started ROCLINK 800 uses a standard Windows interface. Use standard Windows techniques to open and close windows and dialog boxes, expand and hide options, etc. ROCLINK 800 windows ROCLINK 800 windows can be maximized, minimized, or resized, using the standard Windows controls.
  • Page 17 Getting Started ROCLINK 800 buttons Several buttons are used to manage the ROCLINK 800 interface or data exchange with the Model 3711 component. They do not interact with the core processor component. These buttons are found on many ROCLINK 800 windows and dialog boxes (see Figure 2-4): •...

  • Page 18: Tlp System

    Getting Started 2.4.3 TLP system Particular locations, or “points,” in Model 3711 memory are identified using a TLP system, where: • T = Type • L = Logical number • P = Parameter For example, a TLP value of represents the value, in engineering units, of the analog AOU B3, EU output associated with point B3 in the Model 3711’s physical memory.

  • Page 19: Configuration Files

    Getting Started Configuration files When using ROCLINK 800 to configure the Model 3711, two types of configuration files are involved: • The ROCLINK 800 configuration file is specific to each installation of ROCLINK 800 on a PC. It is created automatically, and automatically saved to a file each time that ROCLINK 800 is closed.
  • Page 20 Getting Started Figure 2-6 New Configuration File dialog box 3. Specify your I/O type. • If your Model 3711 was ordered without the optional 6-point I/O expansion termination board, select 6-point no I/O • If your Model 3711 was ordered with the optional 6-point I/O expansion termination board, select 6-point with I/O 4.

  • Page 21: Setting Up Devices And Groups

    Getting Started 2.5.3 Device configuration backup and duplication Once a device configuration file has been saved to your PC, it can be downloaded to any Model 3711. This feature allows you to replicate a configuration across multiple Model 3711 installations. When downloading, you can select specific types of configuration data as required (see Section 14.10.3).

  • Page 22: Disconnecting And Closing

    Getting Started CAUTION Removing the termination board cover in hazardous environments could result in personal injury or property damage. Any procedure that requires removal of the enclosure end caps must be performed only in an area known to be non-hazardous. Performance of these procedures in a hazardous area could result in personal injury or property damage.

  • Page 23: Chapter 3 System Configuration

    Chapter 3 System Configuration Overview This chapter discusses the following topics: • Setting the Model 3711 clock • Configuring security • Configuring device information • Configuring the Auto Scan interval • Configuring TLP display options Note: During the configuration process, save your data frequently, both to the PC and to the Model 3711’s flash memory.

  • Page 24: Configuring Security

    System Configuration Figure 3-1 Clock dialog box Red circle Configuring security Using ROCLINK 800 with the Model 3711 requires two types of security: • Access to the ROCLINK 800 software (ROCLINK 800 security) • Access to the COM ports on the Model 3711 (device security) The ROCLINK 800 operator ID and password are required when you start the ROCLINK 800 program.

  • Page 25: Device Security

    System Configuration Figure 3-2 ROCLINK 800 Security dialog box 2. To add an operator ID: a. Enter a 1–3 character value in the column. Any alphanumeric character may Operator ID be used. All operator IDs must be unique on this ROCLINK 800 installation. The field is case-sensitive.
  • Page 26 System Configuration To manage device security: 1. Connect to the Model 3711. 2. Click . The Device Security dialog box shown in Figure 3-3 is displayed, Device > Security showing the default operator ID. Passwords are concealed. The default password is 1000 Note: Access level 5 is required to open the Device Security dialog box.

  • Page 27: Access Level

    System Configuration b. Enter values as required. • The operator ID must be a 1–3 character value. Any alphanumeric character may be used. The operator ID should be unique; however, no check is performed. The field is case-sensitive. • The password must be a 1–4 character value. Only numeric characters may be used. The password does not have to be unique.
  • Page 28 System Configuration Table 3-1 Access levels for ROCLINK 800 security and device security Menu Option Access level required File Open Download Close Save Configuration Print Configuration Print Setup Recent Files Exit Edit View Directory EFM Report Calibration Report History > From ROC History >...

  • Page 29: Configuring Model 3711 Device Information

    System Configuration Table 3-1 Access levels for ROCLINK 800 security and device security continued Menu Option Access level required Utilities Upgrade Firmware Upgrade Hardware Upgrade to FlashPAC License Key Administrator Convert EFM File User Program Administrator ROCLINK Security AI Calibration Values RTD Calibration Values MVS Calibration Values FST Editor...
  • Page 30 System Configuration Figure 3-5 Device Information dialog box 2. On the General tab, configure parameters as required. Parameters are listed and defined in Table 3-2. Table 3-2 Device Information dialog box – General panel Parameter Description Comments Station Name Name of this Model 3711 Corresponds to Tag value in Communication Properties dialog box Address...

  • Page 31: Configuring Display Options

    System Configuration 3. If you will configure a PID control loop on this Model 3711, open the Points panel and set the value to 1. See Chapter 10 for more information. Active PIDs Note: The Other Information and Revision Information panels contain read-only information describing the Model 3711 hardware, software, purchase, and so on.
  • Page 32 ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 33: Setting Up Communications

    Chapter 4 Setting Up Communications Overview This chapter describes: • Connecting to the Model 3711 through the LOI • Connecting to the Model 3711 through COMM 2 • Configuring communications parameters Configuring COMM 2 on the Model 3711 Configuring ROCLINK 800 communications parameters •...

  • Page 34: Connecting To The Model 3711 Through The Loi

    Setting Up Communications Both functions can be used to connect through either the LOI or COMM 2. If the ROCLINK 800 platform is wired directly to the Model 3711, either the Direct Connect or the Connect function can be used. On a multidrop network, the Connect function must be used to specifically identify the Model 3711.

  • Page 35: Using A Host Program

    Setting Up Communications Note: ROCLINK 800 always uses ROC protocol to connect to the Model 3711. ROC protocol always uses 8 data bits, 1 stop bit, and no parity. If you are having trouble connecting, ensure that the COM port on your PC is configured for 8 data bits. ROCLINK 800 auto-adjusts the other PC COM port settings as required.
  • Page 36 Setting Up Communications 5. On the General panel, configure parameters as required (see Table 4-1). Parameters set here apply to both the serial communications card and the dial-up modem card. Table 4-1 Comm Port – General panel Parameter Description Comments Baud Rate Send and receive bits per second The PC COM port must be...
  • Page 37 Setting Up Communications Figure 4-2 Comm Ports window, Modem panel Table 4-2 Comm Port – Modem panel Parameter Description Comments Connect Time Enter the number of seconds that the Model 3711 will wait, after The modem will initiate a call only initiating a call, to receive a connect message from the remote if RBX alarming is enabled (see device.

  • Page 38: Configuring Roclink 800 Communications Parameters

    Setting Up Communications 4.5.2 Configuring ROCLINK 800 communications parameters If you will connect to the Model 3711 using the Connect function, ROCLINK 800 communications parameters must be configured. Because ROCLINK 800 can be used to connect to multiple devices, communications parameters are saved separately for each device. Note: PC COM port parameters are automatically adjusted by ROCLINK 800 as required.
  • Page 39 Setting Up Communications Table 4-3 ROCLINK 800 Communication Parameters – General panel Model 3711 Parameter Description ROCLINK 800 Default Default Model 3711 station name device name Model 3711 Device Address A unique value within the device group Device Group The group that the Model 3711 belongs to Host Address A unique value within the host group Host Group...

  • Page 40: Configuring Communications For Rbx Alarming

    Setting Up Communications 6. In the Advanced panel, set connection parameters as desired (see Table 4-4). Table 4-4 ROCLINK 800 Communication Parameters – Advanced panel Parameter Description Comments Number of Specify the number of times that ROCLINK 800 will request Range: 0 to 25 Retries data from the Model 3711, before reporting a timeout error, if...
  • Page 41 Setting Up Communications Figure 4-5 Comm Port dialog box – RBX panel 7. Set RBX parameters as desired (see Table 4-5). Table 4-5 Comm Port – RBX panel Parameter Description Comments RBX Mode • Enabled: RBX alarming can be configured and used. •...

  • Page 42: Configuring Passthrough Mode

    Setting Up Communications Table 4-5 Comm Port – RBX panel continued Parameter Description Comments RBX Alarm Index Displays any alarms currently being reported through the RBX feature. RBX Status Indicates the status of RBX message: • Active: An RBX alarm is being processed. •...
  • Page 43 Setting Up Communications Figure 4-6 Flags window – Advanced panel Note: Other functions available on this panel are discussed in Section 14.7. Configuration and Use Manual...
  • Page 44 ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 45: Configuring The Core Interface

    Chapter 5 Configuring the Core Interface About this chapter This chapter explains how to configure the interface between the Model 3711 and the Micro Motion Coriolis sensor. Note: The terms “core” and “core processor” refer to the component which provides preprocessing of the sensor data.

  • Page 46: Using Roclink 800 With The Micro Motion Core Interface

    Configuring the Core Interface Using ROCLINK 800 with the Micro Motion core interface The flowchart in Figure 5-1 displays the recommended procedure for using ROCLINK 800 to configure the core interface. See Section 2.4.2 for information on the function buttons, and see Sections 14.2 and 14.3 for information on the saved configuration file and flash memory.
  • Page 47 Configuring the Core Interface Figure 5-2 Mass Flow panel Table 5-1 Mass flow configuration parameters Parameter Description Comments Flow Direction Forward Only: Only flow in the direction defined by the flow Read-only. arrow on the sensor is used in the calculation of flow rate and flow totals.

  • Page 48: Density Panel

    Configuring the Core Interface Table 5-1 Mass flow configuration parameters continued Parameter Description Comments Flow Temp Coeff One of the values required to characterize the Model 3711 for (FT) the particular sensor it is using. See Section 5.5.1. Meter Factor The adjustment to be applied to the mass flow process variable.

  • Page 49: Temperature Panel

    Configuring the Core Interface Table 5-2 Density configuration parameters Parameter Description Comments Damping Period The number of seconds over which the reported density value Default: 1.6 seconds will change to reflect 63% of the change in the actual process. See Section 5.5.2. Low Density The density value below which the Model 3711 will report a Default: 200 kg/m...
  • Page 50 Configuring the Core Interface Figure 5-4 Temperature panel Table 5-3 Temperature configuration parameters Parameter Description Comments Damping Period The number of seconds over which the reported temperature Default: 4.8 seconds value will change to reflect 63% of the change in the actual process.

  • Page 51: Special Topics In Configuring The Core Interface

    Configuring the Core Interface Special topics in configuring the core interface This section provides additional information on characterizing the Model 3711, configuring damping, calculating and configuring meter factors, and configuring slug flow. 5.5.1 Characterization Characterizing the meter adjusts the Model 3711 to compensate for the unique traits of the sensor it is paired with.

  • Page 52: Damping

    Configuring the Core Interface Flow calibration values Two separate values are used to describe flow calibration: a 6-character FCF value and a 4-character FT value. Both values contain decimal points. On the sensor tags, these two values are concatenated to form a 10-character string called Flow Cal or Flow Cal Factor (see Figure 5-5). •...

  • Page 53: Slug Flow

    Configuring the Core Interface Example The meter is installed and proved for the first time. The meter mass measurement is 250.27 lb; the reference device measurement is 250 lb. A mass flow meter factor is determined as follows: × ----------------- - MassFlowMeterFactor 0.9989 250.27...

  • Page 54: Zeroing The Meter

    Configuring the Core Interface Zeroing the meter Zeroing the meter establishes the system’s point of reference when there is no flow. The meter should be zeroed when it is first installed. When you zero the meter, you may need to adjust the zero time parameter. Zero time is the amount of time the transmitter takes to determine its zero-flow reference point.
  • Page 55 Configuring the Core Interface 4. The zero procedure is performed from the Mass Flow Calibration panel. On this panel: a. Adjust the parameter if required. Zero Time b. Click Begin Meter Zero 5. Close the shutoff valve downstream from the sensor. 6.
  • Page 56 ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 57: Configuring Volumetric Flow Measurement

    Chapter 6 Configuring Volumetric Flow Measurement About this chapter This chapter explains how to configure the special volumetric flow calculations performed by the Model 3711. Terminology In this chapter, the following terms are used: • Flowing pressure – the current process pressure •...
  • Page 58 Configuring Volumetric Flow Measurement Figure 6-1 Input Defs panel Table 6-1 Input Defs parameters Parameter Description Comments Flow Input Definitions Mass Flow Rate Specifies the point from which the mass flow rate will be Typically, this will be the Micro read.

  • Page 59: Mass Compensation Panel

    Configuring Volumetric Flow Measurement Table 6-1 Input Defs parameters continued Parameter Description Comments Density Input Definitions Base Density Specify the point from which the base density value will be This is a calculated value. Specify Source read. the point that holds the result of the calculation.
  • Page 60 Configuring Volumetric Flow Measurement Figure 6-2 Mass Compensation panel Table 6-2 Mass Compensation parameters Parameter Description Comments Enable Mass • Enabled: The configured pressure correction factors are Flow Rate applied to the mass flow measurement from the sensor. Compensation for •...

  • Page 61: Gas Quality Panel

    Configuring Volumetric Flow Measurement Gas Quality panel The Gas Quality panel is shown in Figure 6-3. This panel is used to select the method that will be used for volumetric flow measurement, and provide the required data for the selected method: •...

  • Page 62: Advanced Panel

    Configuring Volumetric Flow Measurement Table 6-3 Gas Quality parameters Parameter Description Comments AGA8 Specify the AGA8 equation of state that will be used to calculate Compressibility gas volume. Method Gas Mole Enter values as required to describe the complete composition Used only if AGA8 Compressibility Percentage of the gas mixture.
  • Page 63 Configuring Volumetric Flow Measurement Figure 6-4 Advanced panel Table 6-4 Advanced parameters Parameter Description Comments Base Pressure Enter the pressure at which gas base volume will be calculated (i.e., the pressure to which gas base volume will be corrected). Base Enter the temperature at which gas base volume will be Temperature calculated (i.e., the temperature to which gas base volume will...

  • Page 64: Sampler Panel

    Configuring Volumetric Flow Measurement 6.4.2 Sampler panel The Sampler panel is shown in Figure 6-5. This panel is used to set up a discrete output to send a pulse to another device, for example, to control a gas sampler or an odorizer. Whenever the value configured for is exceeded, the discrete output is turned on for the Sampler volume accumulation...

  • Page 65: Ao Assignment Panel

    Configuring Volumetric Flow Measurement AO Assignment panel The AO Assignment panel is shown in Figure 6-6. This panel is used to configure the analog output (AO) to report a specific process variable. Parameters on this panel are listed and defined in Table 6-6. Note: To report a process variable through the AO, the optional 6-point I/O board is required (see Section 2.5.2), and an AO must be configured (see Section 7.3).

  • Page 66: Alarms Panel

    Configuring Volumetric Flow Measurement 6.5.1 Alarms panel The Alarms panel is shown in Figure 6-7. This panel is used to enable and configure flow alarms. Parameters on this panel are listed and defined in Table 6-7. Figure 6-7 Alarms panel ®...
  • Page 67 Configuring Volumetric Flow Measurement Table 6-7 Alarms parameters Parameter Description Comments Flow Alarms • Enabled: Flow alarms will be written to the 3711 alarm log, Flow alarms are defined by the and reported through RBX alarming if RBX alarming is values specified for Low Alarm and enabled.
  • Page 68 ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 69: Chapter 7 Configuring I/O

    Chapter 7 Configuring I/O About this chapter This chapter discusses the following topics: • Configuring the I/O types • Configuring analog inputs • Configuring analog outputs • Configuring discrete inputs • Configuring discrete outputs • Configuring pulse inputs Overview If the Model 3711 was purchased with the built-in pressure sensors, you must configure one or two analog inputs.

  • Page 70: Configuring I/O Type

    Configuring I/O Configuring I/O type The I/O option on the Model 3711 termination board provides six I/O “points.” Each point is identified by a unique point number. Note: The point number identifies the physical location of the point by its module slot number and channel number.

  • Page 71: Filtering

    Configuring I/O Figure 7-2 Analog Input – General panel 1. Use the dropdown list to select the AI to configure. Analog Inputs • To configure the built-in pressure sensors, select Line Press Aux Press • To configure an external RTD input using the built-in RTD terminals, select •...

  • Page 72: Analog Input - General Panel

    Configuring I/O 7.4.2 Analog Input – General panel The Analog Input – General panel is shown in Figure 7-2. Parameters on this panel are listed and defined in Table 7-1. Table 7-1 Analog Inputs – General parameters Parameter Description Comments Point Number The module slot number and channel number for this point.
  • Page 73 Configuring I/O Figure 7-3 Analog Inputs – Advanced panel Table 7-2 Analog Inputs – Advanced parameters Parameter Description Comments Filter The percentage of the last value and the new value to use in To disable filtering, enter 0 in this calculating the filtered value.

  • Page 74: Analog Input - Alarms Panel

    Configuring I/O Table 7-2 Analog Inputs – Advanced parameters continued Parameter Description Comments Clipping Controls range of filtered EUs values. • Enabled: Filtered EU values will be cut off at LoLo Alarm and HiHi Alarm limits (see Section 7.4.4). All values below or above the limits will be reported as the limit values.

  • Page 75: Configuring An Analog Output

    Configuring I/O Table 7-3 Analog Inputs – Alarms parameters continued Parameter Description Comments HiHi Alarm Value, in EUs, to which the input value must rise to generate a Typically set higher than the high high-high alarm. alarm value. Rate Alarm Value, in EUs, that represents the maximum amount of change To disable the rate alarm without allowed between updates of the Filtered Value.

  • Page 76: Analog Output - General Panel

    Configuring I/O 3. Work through the configuration panels in the following order: • General • Advanced Note: To configure the analog output to report a process variable, you can use the AO Assignment panel (see Section 6.5), or you can use an FST to write the EU value of the process variable to the analog output (see Section 11.8.5).
  • Page 77 Configuring I/O Figure 7-6 Analog Outputs – Advanced panel Table 7-5 Analog Outputs – Advanced parameters Parameter Description Comments Raw D/A Output The current value produced by the Digital-to-Analog converter. Read-only. Adjusted D/A 0% The Digital-to-Analog value corresponding to 0% output. Used in conversion of EUs to an analog signal.

  • Page 78: Configuring Discrete Inputs

    Configuring I/O Configuring discrete inputs You need to configure discrete inputs if the Model 3711 was purchased with the I/O option, and you configured the I/O terminals for one or more discrete inputs. You may need to configure up to four discrete inputs.

  • Page 79: Discrete Input - Advanced Panel

    Configuring I/O Table 7-6 Discrete Inputs – General parameters Parameter Description Comments Point Number Module slot number and channel number for this point. Not configurable. Scan Period Number of seconds between updates of the Filter value in the Default: 1 second. Advanced panel.

  • Page 80: Discrete Input - Alarms Panel

    Configuring I/O Table 7-7 Discrete Inputs – Advanced parameters Parameter Description Comments Filter Intervals Used with the Filter parameter to define a time delay in Filter Intervals and Filter apply detecting the discrete input’s On status: only to detection of the On state. •...
  • Page 81 Configuring I/O Figure 7-9 Discrete Inputs – Alarms panel Table 7-8 Discrete Inputs – Alarms parameters Parameter Description Comments RBX Alarming Specifies the type of Report By Exception alarming for this If RBX Alarming is enabled, a input: communications port must be •...

  • Page 82: Configuring The Discrete Outputs

    Configuring I/O Configuring the discrete outputs You need to configure discrete outputs if the Model 3711 was purchased with the I/O option. You may need to configure one or two discrete outputs: the I/O option always provides one discrete output, and you may configure a second discrete output.
  • Page 83 Configuring I/O Table 7-9 Discrete Outputs – General parameters Parameter Description Comments State • If Scanning is enabled, State reflects the current output of the In typical use: DO, and is updated by the Model 3711. • On = Closed •...

  • Page 84: Discrete Output - Advanced Panel

    Configuring I/O 7.7.2 Discrete Output – Advanced panel The Discrete Output – Advanced panel is shown in Figure 7-11. Parameters on this panel are listed and defined in Table 7-10. Figure 7-11 Discrete Outputs – Advanced panel Table 7-10 Discrete Outputs – Advanced parameters Parameter Description Comments...
  • Page 85 Configuring I/O Figure 7-12 Discrete Outputs – TDO Parameters panel Table 7-11 Discrete Outputs – TDO Parameters parameters Parameter Description Comments Cycle Time Applies only when DOUT Type = TDO Toggle. Defines the total time of one DO cycle. 0% Count The number of seconds that will be used to represent a 0% Defines the minimum amount of output pulse width.

  • Page 86: Dout Type Options And Examples

    Configuring I/O DOUT Type options and examples For all settings of DOUT Type except Latched, the DOUT Type parameter controls the relationship between the discrete output’s On period and Off period. The following sections provide information on how the duration of the cycle, On period, and Off period are determined, and examples of DO configuration.

  • Page 87: Configuring Pulse Inputs

    Configuring I/O In operation, the discrete output’s On period will be calculated from the values configured for discrete output scaling plus the configured EU Value. The formulas used for calculation are as follows: EUSpan HighReadingEU – LowReadingEU – CountSpan 100%Count 0%Count ×...

  • Page 88: Pulse Input - General Panel

    Configuring I/O 2. Use the Pulse Inputs dropdown list to select Aux PI1 Aux PI2 Note: Do not use PI1 - PIM or PI2 - PIM. These points are not used by the Model 3711. 3. Enter the tag to be used to describe this input. 4.

  • Page 89: Pulse Input - Advanced Panel

    Configuring I/O Table 7-12 Pulse Inputs – General parameters continued Parameter Description Comments Scanning • Enabled: Input from the remote device is automatically If Alarming is enabled, an alarm is processed by the Model 3711. generated when Scanning is set to •...

  • Page 90: Pulse Input - Alarms Panel

    Configuring I/O Table 7-13 Pulse Inputs – Advanced parameters Parameter Description Comments EU Options Controls the contents of the EU Value parameter: See Section 7.9.1 for the formula • Rate (Max Rollover): Displayed EU Value = Calculated rate. used in rate calculation. •...
  • Page 91 Configuring I/O Figure 7-15 Pulse Inputs – Alarms panel Table 7-14 Pulse Inputs – Alarms parameters Parameter Description Comments Low Alarm Specify the value, in EUs, to which the input value must fall to generate a low alarm. High Alarm Specify the value, in EUs, to which the input value must rise to generate a high alarm.
  • Page 92 ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 93: Managing History, Events, And Alarms

    Chapter 8 Managing History, Events, and Alarms About this chapter This chapter discusses the following topics: • The historical databases • History point configuration • Configuring history for audit trail requirements • Viewing, saving, printing and exporting history, event, and alarm logs •...

  • Page 94: Configuring History Points

    Managing History, Events, and Alarms Configuring history points The default history configuration is designed to log all history data required by typical applications. This function is provided by the eleven predefined points in standard history (see Table 8-2). You need to configure additional history points only if your application has requirements that are not handled by the default configuration, or if history points will be needed by an FST.
  • Page 95 Managing History, Events, and Alarms 4. If you will use extended history: a. Specify the number of extended history points that you want to use. Be sure to specify all the points that you will need; if you need to change the number of history points at a later time, you must perform a (see Section 14.2.2).

  • Page 96: Archive Types

    Managing History, Events, and Alarms 8. Repeat Step 6 to assign archive points and archive types to extended history points as required. Figure 8-3 History Setup window – Extended History panel 8.3.1 Archive types Archive Type controls how the logged value is calculated. Archive Types available for selection are listed and defined in Table 8-1.

  • Page 97: Standard History Predefined Points

    Managing History, Events, and Alarms Table 8-1 Archive types continued Option Description Totalize Reset The difference between the current sampled value and the sampled value at the last logging interval is archived. The value being totalized should be an accumulation value that rolls over at a specific time (such as Today’s Total or Yesterday’s Total) rather than at a specific value (e.g., the discrete input ON Counter) FST Data...

  • Page 98: Using The Historical Databases

    Managing History, Events, and Alarms Using the historical databases Options for using data from the historical databases include: • Viewing, saving, printing, exporting, and plotting history data • Viewing, saving, and printing alarm logs and event logs The Log Display window is used for all these functions. See Section 8.4.3. Note: Historical data is not saved to a file automatically.

  • Page 99: Viewing Alarm Logs And Event Logs

    Managing History, Events, and Alarms A window similar to Figure 8-5 is displayed, showing log entries for each selected parameter at each time interval. Figure 8-5 History log display window 8.4.2 Viewing alarm logs and event logs To view an alarm log or an event log: 1.
  • Page 100 Managing History, Events, and Alarms The following actions are available only for history data: • To change the selection, click Select New • To plot the current selection, click . The history data is displayed in chart form. You can: Plot Scroll the chart vertically, using the scroll bar at the left of the chart.

  • Page 101: Monitoring And Displays

    Chapter 9 Monitoring and Displays About this chapter This chapter discusses the following topics: • Model 3711 display variables • Configuring the ROCLINK 800 I/O monitor • Creating and using ROCLINK 800 custom displays Model 3711 display variables The LCD user list allows you to specify up to 16 parameters that will be shown on the Model 3711 display.

  • Page 102: Configuring Display Variables

    Monitoring and Displays 9.2.2 Configuring display variables To configure the LCD user list, click . The dialog box shown in Configure > LCD User List Figure 9-1 is displayed. Figure 9-1 LCD User List dialog box Parameters in this dialog box are listed and defined in Table 9-1. Table 9-1 LCD User List parameters Parameter...
  • Page 103 Monitoring and Displays Figure 9-2 I/O Monitor dialog box To specify the I/O data that will be included on the display: 1. Expand the I/O types to display all options. 2. Check the desired options. 3. Click The I/O monitor is activated, displaying the selected values. The I/O monitor is displayed in a ROCLINK 800 window, and Auto Scan is automatically enabled.

  • Page 104: Roclink 800 Custom Displays

    Monitoring and Displays Figure 9-3 I/O Monitor window ROCLINK 800 custom displays The custom display feature allows you to define displays. Displays present selected real-time data, arranged as desired. Displays can also be used to change Model 3711 parameters. Images may be added to the display as desired.
  • Page 105 Monitoring and Displays Figure 9-4 Display Editor window Custom display elements Properties edit box Lock Controls Other Tools (Tab-Key Order) Save Display Horizontal Spacing Size Vertical Spacing Open Display Align New Display Test 2. In the Properties edit box: a. Enter a name for this display. b.

  • Page 106: Saving And Loading Custom Displays

    Monitoring and Displays 6. Define tab order. Tab order controls the order in which elements are selected when the Tab key is pressed. Tab order applies to tab controls, frames, labels, user-editable text boxes, option buttons, check boxes, combo boxes, and buttons. There is no default tab order in the display. Use either of the following methods to define tab order: •...

  • Page 107: Editing A Custom Display

    Monitoring and Displays 9.4.3 Editing a custom display Any custom display that is loaded into ROCLINK 800 can be edited. To edit a display: 1. Click View > Display > From File 2. Specify the display file to be loaded/viewed. 3.
  • Page 108 ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 109: Chapter 10 Pid Control Loops

    Chapter 10 PID Control Loops 10.1 About this chapter This chapter discusses the following topics: • PID control loops overview • Configuring PID control loops • Tuning PID control loops • Monitoring PID control loops 10.2 PID control loops overview Proportional, Integral, and Derivative (PID) control loops are used to provide smooth and stable operation of the feedback loops that control a regulating device such as a control valve or a motor.

  • Page 110: Pid Control Loop Example

    PID Control Loops If an override loop is implemented, it is configured for either a high select or a low select. The PID algorithm is executed for both the primary loop and the override loop, and the calculated changes are compared.
  • Page 111 PID Control Loops Figure 10-1 PID Loop window Control Type = Primary Only Control Type = Override Control 3. Assign a tag to this PID loop. The tag can contain up to 10 characters. 4. Specify Control Type • – Only a primary control loop will be configured and used. Primary Only •...
  • Page 112 PID Control Loops Note: Even if Mode is set to Manual, the PID control function is monitoring input values and performing other functions that require processor resources. To configure the unit so that no processor resources are consumed by the PID control function, disable the Scanning parameter. 8.

  • Page 113: Tuning The Pid Control Loop

    PID Control Loops Figure 10-2 PID Loop Tuning window 10.4 Tuning the PID control loop To tune the PID control loop: 1. Click the button in the window. The window is expanded as shown in Tuning PID Loop Figure 10-2. 2.

  • Page 114: Monitoring The Pid Control Loop

    PID Control Loops Table 10-1 PID loop tuning parameters continued Parameter Description Comments Scale Factor Ratio of control output span to process variable input span. The • Reverse action: Negative sign of the number specifies the action of the loop: feedback loop: i.e., the control •...

  • Page 115: Configuration And Use Manual

    Chapter 11 Function Sequence Tables 11.1 About this chapter This chapter discusses the following topics: • FST overview • FSTs and Model 3711 memory • FST Editor • Developing an FST • Monitoring and tracing an FST • The FST command library •...

  • Page 116: Fsts And Model 3711 Points

    Function Sequence Tables Depending on the function, the RR and the CF may be loaded, stored, tested, modified, or left unchanged. 11.3 FSTs and Model 3711 points FSTs may read and write to several different point types in Model 3711 memory. The following three point types require special attention during FST development: •...
  • Page 117 Function Sequence Tables Figure 11-1 FST Editor window FST menus FST toolbar FST workspace The FST Editor provides: • Specialized menus • A specialized FST toolbar • Two workspaces for defining functions – one for FST 1 and one for FST 2. You can have two FSTs open in the FST Editor simultaneously.

  • Page 118: Developing An Fst

    Function Sequence Tables 11.5 Developing an FST This section provides instructions for developing an FST. Before beginning FST development, review the following requirements and guidelines: • An END command is required at the end of every FST. The END command tells the FST to return to the top of the first STEP and begin to run from the first line at STEP 0.
  • Page 119 Function Sequence Tables Within each function: • Labels are used to identify functions and to enable branching. A label can contain a maximum of six characters. Enter the value manually. • A command specifies the action to be taken by a function. See Section 11.8 for definitions of all FST commands that can be used with the Model 3711.
  • Page 120 Function Sequence Tables Two examples of FST functions are shown below. These functions are executed sequentially. STEP LABEL ARGUMENT1 ARGUMENT2 CKHIAL AIN 3-1, EU >= AIN 3-1, HIAL PUMPON In the first function, the VAL command writes the current process value (in EUs) of an analog input to the implied Result Register.
  • Page 121 Function Sequence Tables Table 11-1 FST Registers window – General parameters Parameter Description Comments Used to identify the FST register point. 10 characters maximum. Optional. Version Displays the version that was specified during FST download. Description Displays the description that was specified during FST download.
  • Page 122 Function Sequence Tables Table 11-2 FST Registers window – Advanced parameters Parameter Description Comments Timer Countdown timers used to signal that a certain period has See Section 11.8.4 for information #1 – 4 elapsed. To use, specify the number of 100-millisecond periods on timers.

  • Page 123: Monitoring And Tracing

    Function Sequence Tables 11.6 Monitoring and tracing Monitoring is used to observe real-time values for FST timers, integer values in the Misc registers, and strings and values in the Message registers. Monitoring is also used to access Trace mode. You can monitor only one FST at a time. 11.6.1 Monitor mode To monitor an FST:...
  • Page 124 Function Sequence Tables Figure 11-5 FST Monitor window Resume monitoring Start tracing Go to next step Pause monitoring Stop tracing ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 125: Trace Mode And Debugging

    Function Sequence Tables 11.6.2 Trace mode and debugging Trace mode is used to debug FSTs. Trace executes the FST command indicated by the Instruction Pointer (IP), moves the Instruction Pointer to the next FST command to be executed, and then stops. You are given the opportunity to examine the results of the FST command and determine the next FST command to be executed.

  • Page 126: Fst Storage And Restart

    Function Sequence Tables 11.7.3 FST storage and restart The Flags window is used to manage FST storage on the Model 3711 (see Figure 14-1). • To save an FST to the Model 3711’s flash memory, click Save Configuration • If an FST is running when a warm start or a restart after power outage occurs, the FST automatically restarts at Step 0.

  • Page 127: Troubleshooting An Fst

    Function Sequence Tables 11.7.7 Troubleshooting an FST If an error occurs during the compile process, the Output field lists the error type, and the cell in which the error occurred is displayed in red. An execution error occurs when the FST references a point number that has been removed or changed.

  • Page 128: Mathematical Commands

    Function Sequence Tables Table 11-4 FST command summary continued Category Command Action Logical SVD(out) = NOT SVD(in) SVD(out) = SVD(in) AND ARGUMENT1 SVD(out) = SVD(in) OR ARGUMENT1 SVD(out) = SVD(in) XOR ARGUMENT1 Comparison If RR(in) = ARGUMENT1, go to ARGUMENT2 LABEL If RR(in) != ΑRGUMENT1, go to ARGUMENT2 LABEL <...

  • Page 129: Logical Commands

    Function Sequence Tables Table 11-5 Mathematical commands Name Description Arguments Results Add value to RR(in) • ARG1 = Database or RR(out) = RR(in) + ARG1 Constant Value Subtract value from RR(in) • ARG1 = Database or RR(out) = RR(in) – ARG1 Constant Value •...
  • Page 130 Function Sequence Tables Table 11-6 Binary-to-integer conversion example Bit weight Bit value Decimal equivalent Total The bit-wise AND, OR (inclusive OR), and XOR (exclusive OR) operations are summarized in Table 11-7. An example of using AND to interpret a status value is provided following the table. Table 11-7 Bit-wise operations Operation...

  • Page 131: Comparison Commands

    Function Sequence Tables Example The following FST checks AI alarm status using the FST logical command AND. The FST reads the current AI alarm status value and checks for a high alarm (bit weight = 4), high-high alarm (bit weight = 8), and a point failure alarm (bit weight = 64).

  • Page 132: Time-Related Commands

    Function Sequence Tables The equal to (==) command compares the contents of the Results Register to ARGUMENT1, and branches conditionally if they are equal. The equal to (==) command only works if the comparison is between integers ranging from 0 to 255. It does not work if ARGUMENT1 is greater than 255 or if it is a number other than an integer.

  • Page 133: Control-Related Commands

    Function Sequence Tables Table 11-10 Time-related commands Name Description Arguments Results Start specified Timer with specified • ARG1 = FST Point Database FST Timer (ARG1) = ARG2 number of 100-millisecond intervals. Value • ARG2 = Database or Constant Value Check Timer for specified FST. •...

  • Page 134: Database Commands

    Function Sequence Tables 11.8.6 Database commands Database commands provide access to the configuration and historical databases. Operations include reading and writing configuration parameters, reading, writing, and storing values from historical databases, and timestamping values to a history point. Historical database commands The RDB, WDB, and WTM commands are historical database commands.

  • Page 135: Miscellaneous Commands

    Function Sequence Tables Table 11-12 Database commands continued Name Description Arguments Results Sets RR(out) to the value of the • ARG1 = Database or Constant For FST History Point: specified history point (ARGUMENT1) Value • RR(out) = History Value at the specified pointer •...

  • Page 136: Fst Examples

    Function Sequence Tables Table 11-13 Miscellaneous commands Name Description Arguments Results Go to specified LABEL • ARG1 = LABEL Goto ARG1. Send message and value to • ARG1 = Message FST Message String(ARG1) Model 3711 display. One 30–character • ARG2 = Database or Constant FST Message Value(ARG2) message can be sent by each FST as Value...

  • Page 137: Example 2 - Stopping An Fst After Task Completion

    Function Sequence Tables The FST is shown in Figure 11-6. In this FST: • Registers R1, R2, and R5 are automatically initialized to 0 when the FST is loaded into the device. • Steps 0 – 2: Increment the counter (R5) by 1 and store the result in RR. •...

  • Page 138: Example 3 - Cycling An Fst On A Periodic Basis

    Function Sequence Tables Figure 11-7 FST Example 2 11.9.3 Example 3 – Cycling an FST on a periodic basis In this example, the FST is set to run on a 10-second cycle. A timer is used to determine how much, if any, of the cycle remains after the FST executes, and therefore the number of seconds to wait before restarting the FST.

  • Page 139: Example 4 - Calculate An Fst's Approximate Execution Rate

    Function Sequence Tables 11.9.4 Example 4 – Calculate an FST’s approximate execution rate This portion of an FST determines the average time it takes to execute the FST. A timer is used to determine the number of 100-millisecond intervals that have elapsed while a sequence of functions executes.
  • Page 140 ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 141: Chapter 12 Modbus Interface

    Chapter 12 Modbus Interface 12.1 About this chapter This chapter discusses the following topics: • Modbus and the Model 3711 memory structure • Configuring the Modbus interface • Accessing Model 3711 data via the Modbus interface Note: This Modbus interface and these Modbus registers are not the same as the Modbus interface and Modbus registers documented in Section 13.5.

  • Page 142: Modbus And Model 3711 Points

    Modbus Interface In both modes, a Modbus message is placed by the transmitting device into a frame that has a known beginning and ending point. ASCII and RTU modes use different frame structures. However, both frame types contain the following: •...

  • Page 143: Configuring The Modbus Interface On The Model 3711

    Modbus Interface Figure 12-1 Modbus program access to Model 3711 memory Modbus program Modbus registers Modbus history access registers Event and alarm index Points (including soft points) History Event and alarm logs 12.5 Configuring the Modbus interface on the Model 3711 To configure the Modbus interface on the Model 3711: 1.
  • Page 144 Modbus Interface Table 12-1 Modbus Configuration – General parameters Parameter Description Comments Status Displays the Model 3711 Modbus slave status. Possible states: • OK • Illegal function • Illegal data address • Illegal data value • Unknown error Modbus Type •...
  • Page 145 Modbus Interface Figure 12-3 Modbus Configuration window – Scale Values panel 4. Set parameters as required. Scaling may or may not be applied to Modbus communications, as configured in Steps 6 and 9. For a discussion of scaling, see Section 12.5.1. Parameters in this panel are listed and defined in Table 12-2.
  • Page 146 Modbus Interface Figure 12-4 Modbus Configuration window – History Access Registers panel 6. This panel is used to define up to 10 history access registers. Each history access register is a Modbus register that references a set of consecutive history points. For each history access register that you will use, specify its Modbus register number, starting history point, ending history point, archive type, and conversion code (see Table 12-3).
  • Page 147 Modbus Interface Table 12-3 Modbus Configuration – History Access Registers parameters continued Parameter Description Comments Ending History The last history point to be referenced by the history access Point register. Archive Type • Hourly: Return hourly values from standard history. •...

  • Page 148: Modbus Scaling

    Modbus Interface Table 12-4 Modbus Registers parameters Parameter Description Comments Function Select the Modbus function for which registers will be defined. Function Name Specify the tag to be used to identify the Modbus function. Starting Register Specify the first register to which a point will be mapped. Ending Register Specify the last register to which a point will be mapped.

  • Page 149: Datatype Conversions

    Modbus Interface × AnalogValue AnalogLow – ScaleHigh ScaleLow – ScaleValue --------------------------------------------------------------------------------------------------------------------------------------------------- - ScaleLow AnalogHigh AnalogLow – × ScaleValue ScaleLow High log ow – – Value ------------------------------------------------------------------------------------------------------------------------------------------------------- - ScaleHigh ScaleLow – Float scaling Some Modbus hosts cannot process floating-point values. Float scaling allows: •...
  • Page 150 Modbus Interface Table 12-5 Datatype conversion codes Conversion Float scale Modbus Conversion type code used function Comments No Conversion For floating-point values, if Byte Order is set to LSB, returns the following: • Register xxxx: Byte 3, byte 2, byte 1, byte 0 If Byte Order is set to MSB, returns the following:...
  • Page 151 Modbus Interface Table 12-5 Datatype conversion codes continued Conversion Float scale Modbus Conversion type code used function Comments Byte Order in IEEE 03, 04, 16 Applies to data received at the Model 3711. Floating Point Number If Byte Order is set to LSB, returns the following: •...

  • Page 152: Modbus Register Ranges

    Modbus Interface 12.5.3 Modbus register ranges The Model 3711 Modbus interface supports Function Codes 1, 2, 3, 4, 5, 6, 15, and 16. These functions must reference registers that have been mapped in the Modbus Registers window. The function may reference registers that are within a mapped range, or that include the Starting Register and/or the Ending Register.

  • Page 153: Modbus Date And Time Formats

    Modbus Interface 12.5.4 Modbus date and time formats Two different formats are available for date and time values: Table 12-6 Modbus date and time formats Format Date Time Standard MMDDYY HHMMSS MMDDYY HHMM For both formats, the datestamp uses the current year, with no modifications. For example, for calendar year 2005, the YY value is 05.

  • Page 154: Accessing Event And Alarm Data

    Modbus Interface 5. Read and interpret the reply as follows: • If EFM Modbus is disabled, the first two values in the data field are floating-point values representing the timestamp and datestamp (in that order) for the history archive. The datestamp uses the current year, with no modifications.
  • Page 155 Modbus Interface A maximum of twelve records can be returned in one reply. Records are collected until there are no more unacknowledged records or until the maximum record number is reached, whichever occurs first. To access event and alarm logs, a Modbus host program must perform these steps: 1.
  • Page 156 Modbus Interface Table 12-10 Operator change and alarm change bit maps continued Operator change bit map Alarm change bit map Boolean fixed bit – Change to Status in DO or DI Not used Fixed/variable flag – Change to Manual Mode for an I/O point Manual alarm Table entry change –...

  • Page 157: Chapter 13 Model 3711 Operator Interface

    Chapter 13 Model 3711 Operator Interface 13.1 About this chapter This chapter discusses the following topics: • Viewing process data and system information using ROCLINK 800 • Viewing alarms and communication statistics using ROCLINK 800 • Reading and writing to the Modbus interface on the core processor using ROCLINK 800 13.2 Viewing process data and system information The Rates &...
  • Page 158 Model 3711 Operator Interface Figure 13-1 Rates & Totals window Table 13-1 Rates & Totals parameters Parameter Description Comments Input Values Mass Flow Rate Current mass flow rate. May or may not be corrected for pressure, depending on configuration. Flowing Pressure Current pressure value from configured pressure input.

  • Page 159: Using The Volumetric Flow Measurement Configuration Panels

    Model 3711 Operator Interface Table 13-1 Rates & Totals parameters continued Parameter Description Comments Flow Calculations Volume Flow The uncorrected volume flow rate, as calculated by the Rate at Flowing Model 3711. Conditions Volume Flow The volume flow rate, as calculated by the Model 3711, Rate at Base and corrected to reference temperature and pressure.
  • Page 160 Model 3711 Operator Interface Figure 13-2 Model 3711 Core Processor Interface window – General panel Table 13-2 Model 3711 Core Processor Interface – General parameters Parameter Description Comments Polling Status Applies to communication between the Model 3711 and the core processor State Displays the current status Read-only.

  • Page 161: Initial Calculations And Recalculations

    Model 3711 Operator Interface Table 13-2 Model 3711 Core Processor Interface – General parameters continued Parameter Description Comments Temperature Current temperature as reported by sensor RTD Displayed in configured units. Depending on configuration, this may or may not be the temperature value used in volumetric calculations.

  • Page 162: Reading And Writing To The Core Processor Modbus Interface

    Model 3711 Operator Interface Figure 13-3 Model 3711 Core Processor Interface window – Diagnostics panel When this panel is first opened, alarm status and communication statistics are read from the core processor. To view current alarm status and communication statistics, either enable Auto Scan click .
  • Page 163 Model 3711 Operator Interface Figure 13-4 Model 3711 Core Processor Interface window – User Registers panel To read Modbus registers on the core processor: 1. For each register you want to read: a. Enter its register number in the field. Register # b.
  • Page 164 Model 3711 Operator Interface To write to Modbus registers on the core processor: 1. For each register that you will write to: a. Enter its register number in the field. Register # b. Specify its data type. c. Specify the data value to be written. 2.

  • Page 165: Chapter 14 Administration

    Chapter 14 Administration 14.1 About this chapter This chapter discusses the following topics: • Initializing the Model 3711 and managing memory • Model 3711 memory structure • Meter default values • Event log • Alarm log • Advanced communication and system controls •...

  • Page 166: Using Roclink 800

    Administration Note: The Model 3711 ceases operation as soon as the power jumper is removed. The OFF slots are provided for convenience in storing the jumper during unit storage, transportation, etc. 3. Replace the cover on the front of the unit. Tighten securely but do not over-tighten. If the reset jumper is in the NORM slots (left and center) when power is supplied, a “warm start”...
  • Page 167 Administration Table 14-1 Flags window – General panel Option Description Restart Warm Start Shuts down and initializes the Model 3711 as follows: • If user configuration in SRAM is valid, configuration data is loaded from SRAM. • If user configuration in SRAM is not valid, user configuration data is loaded from flash memory.

  • Page 168: Model 3711 Memory Structure

    Administration Note the following: • After a warm start: If the Model 3711 is initialized from SRAM, databases and FSTs remain as they were before the warm start. The FST will resume processing from the point at which it stopped. If the Model 3711 is initialized from flash memory, FSTs are loaded from flash memory, and the history, event, and alarm logs remain as they were before the warm start.

  • Page 169: Meter Default Values

    Administration Figure 14-2 Model 3711 memory SRAM FLASH Reserved RAM area Copy of user configuration data User configuration data • System variables • System variables • I/O assignment • I/O assignment • IO configuration • IO configuration • Communications • Communications •...

  • Page 170: Event Log

    Administration Table 14-2 Meter default values continued Meter configuration parameter Default value Density Units lb/ft or kg/m , according to configured units Temperature Units Deg F or Deg C, according to configured units Pressure Units PSI or kPa Communications Fault Action None, show process variables on communications failure Mass Flow Damping Period...

  • Page 171: Alarm Log

    Administration 14.6 Alarm log The Model 3711 alarm log contains the change in the state of any alarm signal that has been enabled. The alarm log can store up to 240 alarms in a “circular” log. When the log is full, each new alarm overwrites the oldest alarm.

  • Page 172: Using The Optional Dial-Up Modem

    Administration Table 14-3 Flags window – Advanced panel Parameter Description Comments CRC Check • Enabled: Cyclical Redundancy Checking is performed on all ROCLINK 800 uses ROC protocol communications using ROC protocol. to communicate with the • Disabled: No CRC is performed. Model 3711.

  • Page 173: 14.10 Managing Device Configuration Files

    Administration Figure 14-4 Flags window – User Programs panel 14.10 Managing device configuration files A device configuration file contains Model 3711 configuration parameters. You can create, save, open, close, download, and print device configuration files. The ROCLINK 800 File menu is used for these functions.

  • Page 174: Closing A Device Configuration File

    Administration 14.10.2 Closing a device configuration file Closing a device configuration file removes that configuration file from ROCLINK 800 software. It does not remove the file from the Model 3711. However, if you are connected to a Model 3711 and you close its device configuration window, you are automatically disconnected.

  • Page 175: 14.11 Printing And Exporting A Device Configuration File

    Administration 14.11 Printing and exporting a device configuration file To print or export device configuration file: 1. Open or select the device configuration file that you want to print or export. 1. Click . The Print Configuration Setup dialog box is displayed (see File >...
  • Page 176 Administration 1. Click . The dialog box shown in Figure 14-7 is displayed. Utilities > Update Firmware Figure 14-7 Update Firmware dialog box 2. Set the options at the top as desired: • is enabled, the current configuration will be saved to the Save Device Configuration specified file before the update.

  • Page 177: Updating The User Programs

    Administration 14.12.2 Updating the user programs To update a user program, including the Model 3711 user programs: 1. Click . The dialog box shown in Figure 14-8 is Utilities > User Program Administrator displayed. Figure 14-8 User Program Administrator dialog box 2.

  • Page 178: 14.13 Upgrading Hardware

    Administration 14.13 Upgrading hardware This procedure is required only if you replace the base termination board or the Mass Flow Interface board in a Model 3711 unit. This procedure includes: • Saving the configuration • Removing power • Removing hardware •...

  • Page 179: Chapter 15 Maintenance And Troubleshooting

    Chapter 15 Maintenance and Troubleshooting 15.1 About this chapter This chapter provides information and techniques for Model 3711 system maintenance and troubleshooting. Topics include: • Troubleshooting the connection between ROCLINK 800 and the Model 3711 – see Section 15.2 • Debugging ROCLINK 800 communications –...

  • Page 180: Dial-Up Modem And Fcc Compliance

    Maintenance and Troubleshooting Figure 15-1 displays a Communications Monitor window showing a Direct Connect connection request as sent to the Model 3711. In this window: • Bytes sent by ROCLINK 800 are shown in black. • Bytes received by ROCLINK 800 are shown in red. •...

  • Page 181: Diagnostic Monitoring

    Maintenance and Troubleshooting If this unit causes harm to the telephone network, the telephone company may discontinue service temporarily or may request that you disconnect the equipment. The telephone company should advise you of your right to file a complaint with the FCC. The telephone company may make changes to its facilities, equipment, operations, or procedures that could affect the operation of the equipment.

  • Page 182: Backup Battery

    Maintenance and Troubleshooting 15.8 Backup battery The Model 3711 contains a backup battery that provides backup power to the clock and to SRAM. Under normal conditions, the backup battery has a functional life of five years or more. This battery can be replaced in the field. Micro Motion recommends that the battery be replaced every five years, or after any extended period of power-down or storage.
  • Page 183 Maintenance and Troubleshooting Table 15-1 Status alarms and remedies continued Alarm code Message Possible remedy A005 Input Overrange Check the test points. See Section 15.16. Check the sensor pins. See Section 15.18. Verify process. Verify calibration factors in Model 3711 configuration. See Section 15.13. Re-zero the Model 3711.

  • Page 184: 15.11 Checking Process Variables And Test Points

    Maintenance and Troubleshooting Table 15-1 Status alarms and remedies continued Alarm code Message Possible remedy Amplitude Mismatch Contact Micro Motion. See Section 1.8. Pickoff 180 Out of Contact Micro Motion. See Section 1.8. Phase Pickoff Frequency Out of Contact Micro Motion. See Section 1.8. Range 15.11 Checking process variables and test points Micro Motion suggests that you make a record of the variables and test points listed below, under...
  • Page 185 Maintenance and Troubleshooting Table 15-3 Process variables problems and possible remedies Symptom Cause Possible remedy Steady non-zero flow rate under Misaligned piping (especially in new Correct the piping. no-flow conditions installations) Open or leaking valve Check or correct the valve mechanism. Bad sensor zero Rezero the meter.
  • Page 186 Maintenance and Troubleshooting Table 15-3 Process variables problems and possible remedies continued Symptom Cause Possible remedy Inaccurate flow rate Bad flow calibration factor Verify characterization. See Section 15.13. Bad sensor zero Rezero the meter. See Section 5.6. Bad density calibration factors Verify characterization.

  • Page 187: 15.12 Checking Slug Flow

    Maintenance and Troubleshooting 15.12 Checking slug flow Slugs – gas in a liquid process or liquid in a gas process – occasionally appear in some applications. See Section 5.5.4 for a description of slug flow functionality. If slug flow occurs: •...

  • Page 188: Checking The Power Supply Wiring

    Maintenance and Troubleshooting 15.15.1 Checking the power supply wiring To check the power supply wiring: 1. Power down the Model 3711. 2. Ensure that the external power supply wires are connected to the correct terminals on the Model 3711. See Table A-1 and Figure A-6. 3.

  • Page 189: 15.16 Checking The Test Points

    Maintenance and Troubleshooting 15.16 Checking the test points Some status alarms that indicate a sensor failure or overrange condition can be caused by problems other than a failed sensor. You can diagnose sensor failure or overrange status alarms by checking the meter test points.

  • Page 190: Low Pickoff Voltage

    Maintenance and Troubleshooting Table 15-5 Drive gain problems, causes, and remedies Cause Possible remedy Drive board or module failure, cracked flow tube, Contact Micro Motion. See Section 1.8. or sensor imbalance Mechanical binding at sensor Ensure sensor is free to vibrate. Open drive or left pickoff sensor pin Contact Micro Motion.

  • Page 191: Core Processor Resistance Test

    Maintenance and Troubleshooting 3. Check the core processor LED against the conditions described in Table 15-7. 4. To return to normal operation, replace the lid. Note: When reassembling the meter components, be sure to grease all O-rings. Table 15-7 Core processor LED behavior, meter conditions, and remedies LED behavior Condition Possible remedy...

  • Page 192: 15.18 Checking Sensor Pins

    Maintenance and Troubleshooting To return to normal operation: 1. Reconnect the 4-wire cable between the core processor and the Model 3711. 2. Replace the core processor lid. Note: When reassembling the meter components, be sure to grease all O-rings. Figure 15-2 Core processor resistance test 40 kΩ...
  • Page 193 Maintenance and Troubleshooting There should be no open circuits, i.e., no infinite resistance readings. The LPO and RPO readings should be the same or very close (± 5 ohms). If there are any unusual readings, repeat the pin resistance tests at the sensor junction box to eliminate the possibility of faulty cable. The readings for each pin pair should match at both ends.

  • Page 194: 4-Wire Remote Installation

    Maintenance and Troubleshooting 15.18.2 4-wire remote installation If you have a 4-wire remote installation (see Figure A-1): 1. Power down the Model 3711. 2. Remove the core processor lid. Note: You may disconnect the 4-wire cable between the core processor and the Model 3711, or leave it connected.
  • Page 195 Maintenance and Troubleshooting With the DMM set to its highest range, there should be infinite resistance on each lead. If there is any resistance at all, there is a short to case. See Table 15-9 for possible causes and solutions. 6.
  • Page 196 ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 197: Appendix A Installation Types And Components

    Appendix A Installation Types and Components About this appendix This appendix provides illustrations of system architectures, components, wiring, and termination boards, for use in troubleshooting. For detailed information on installation and wiring procedures, see the Model 3711 installation manual. Installation architectures There are two possible installation architectures for the Model 3711 system: •...

  • Page 198: Remote Core Processor

    Installation Types and Components Figure A-2 Installation architecture – Remote core processor with remote transmitter Model 3711 Hazardous area Safe area Power supply cable Sensor 4-wire cable I.S. barrier RS-485 cable 9-wire cable Core processor Junction box Remote core processor In remote core processor with remote transmitter installations, the core processor is installed stand-alone, as shown in Figure A-3.

  • Page 199: Termination Boards

    Installation Types and Components Figure A-4 I.S. barrier terminals 44 (RS-485 B) 14 (RS-485 B) 43 (RS-485 A) 13 (RS-485 A) 42 (VDC +) 12 (VDC +) 41 (VDC –) 11 (VDC –) I.S. terminals Non-I.S. terminals for connection to core processor for connection to Model 3711 Table A-1 Terminal functions at core processor, barrier, and Model 3711...
  • Page 200 Installation Types and Components The Mass Flow Interface termination board is installed on top of the base termination board (see Figure A-6). • The Mass Flow Interface termination board provides the PWR+ and PWR– terminals that power the system, and the MVD terminals for the RS-485 connection to the sensor. The Mass Flow Interface board is required for Model 3711 operation.

  • Page 201: Appendix B Calibration

    Appendix B Calibration About this appendix The following calibration procedures may be performed as required: • Analog input calibration, which includes the optional pressure inputs and RTD, and the auxiliary analog inputs from the Micro Motion sensor – see Section B.2 •...
  • Page 202 Calibration 3. Open the AI Calibration panel. 4. To get a current AI value, enable or click Auto Scan Update 5. Click . This holds the AI value from Step 4. Freeze 6. If you are calibrating an RTD, disconnect the RTD input from the Model 3711 RTD terminals, and connect a decade box (or comparable equipment).

  • Page 203: Verification Procedure

    Calibration B.2.3 Verification procedure You can verify a calibration at the calibration points used during calibration, or you can verify a calibration at selected intervals of the process span. For example, you could verify a calibration at 4 mA, 5 mA, 6 mA, ... 20 mA, if you calculate the EU values to be associated with each value of the input.
  • Page 204 Calibration 10. To verify a midpoint value: a. In the field, enter the midpoint value in EUs. Dead Weight/Tester b. Set the input from the test device to the mA value associated with the midpoint. c. View the live reading. d.

  • Page 205: Viewing Calibration Values For Analog Inputs Or Rtd

    Calibration Example 2 Verify a calibration, using fifteen midpoints. The analog input has a range of 100 to 500 EUs. Calculate the EU value to be associated with each midpoint, to produce a table similar to the following: Midpoint in Midpoint in Midpoint in Midpoint in...
  • Page 206 Calibration Figure B-3 AI Calibration Values dialog box 2. In the Point dropdown list, select the point number of the AI or RTD whose calibration values you want to view. The Tag displays the name of the selected point. 3. Parameters in the AI Calibration Values dialog box are listed and defined in Table B-1. Table B-1 AI Calibration Values parameters Parameter...

  • Page 207: Calibrating The Analog Output

    Calibration Calibrating the analog output The analog output is calibrated at the factory to the values shown in Table B-2. Table B-2 Analog output factory calibration Output in % D/A counts Output in mA 3250 To comply with plant standards, it may be necessary to adjust the AO calibration points. To adjust the AO calibration points: 1.

  • Page 208: Calibration Procedure

    Calibration During calibration, the sensor must be completely filled with the calibration fluid, and flow through the sensor must be at the lowest rate allowed by your application. This is usually accomplished by closing the shutoff valve downstream from the sensor, then filling the sensor with the appropriate fluid.
  • Page 209 Calibration Figure B-5 Density calibration procedure D1 calibration D2 calibration Close shutoff valve Fill sensor with D1 fluid Fill sensor with D2 fluid downstream from sensor Meter Menu > Begin High Density Cal Calibration > Density Enter density of D2 fluid Begin Low Density Cal Enter density of D1 fluid Perform Calibration...
  • Page 210 ® Micro Motion Model 3711 Gas Flow Computers...

  • Page 211: Appendix C Points And The Tlp System

    Appendix C Points and the TLP System About this appendix This appendix provides background information on the TLP system, and also provides documentation for the three user-defined points that are built into the Model 3711 system. Points The term “point” is used to refer to a specific grouping of information that supports communication, data acquisition, data manipulation, and control.

  • Page 212: Points

    Points and the TLP System Figure C-1 Select TLP dialog box To use the Select TLP dialog box: 1. Highlight the point type of the desired point. 2. Highlight the logical number of the desired point. 3. Highlight the desired parameter associated with the specified point. C.3.1 Points Standard point types used by the Model 3711 are listed and defined in the document entitled ROC...

  • Page 213: Parameters

    Points and the TLP System C.3.3 Parameters Each point type is associated with a unique set of parameters. For a listing of the parameters available for each standard point type, see the ROC Protocol User Manual. The parameters associated with the three UDPs are listed below. Note that for UDP 39, parameters 0–50 are displayed in the Select TLP dialog box, but are not used, and are not documented here.
  • Page 214 Points and the TLP System Table C-2 UDP 37 parameters continued Read/ Data Default Parameter Write type Length Range value Description UINT16 0 – 65535 Live Data Register 2 (Mass Rate) UINT8 1 – 16 FL (7) Live Data Register 2 Data Type Live Data Register 2 Value UINT16 0 –...
  • Page 215 Points and the TLP System Table C-2 UDP 37 parameters continued Read/ Data Default Parameter Write type Length Range value Description UINT16 0 – 65535 Setup Reg 11 (Pressure Units) UINT8 1 – 16 UINT16 (4) Setup Register 11 Data Type Setup Register 11 Value (PSI) UINT16 0 –...
  • Page 216 Points and the TLP System Table C-2 UDP 37 parameters continued Read/ Data Default Parameter Write type Length Range value Description Setup Data Register 23 Value UINT16 0 – 65535 Setup Reg 24 (Status Register 422) UINT8 1 – 16 UINT16 (4) Setup Register 24 Data Type Setup Data Register 24 Value...
  • Page 217 Points and the TLP System Table C-2 UDP 37 parameters continued Read/ Data Default Parameter Write type Length Range value Description Setup Data Register 36 Value UINT16 0 – 65535 Setup Reg 37 (Mass Live Zero) UINT8 1 – 16 FL (7) Setup Register 37 Data Type Setup Data Register 37 Value...
  • Page 218 Points and the TLP System Table C-2 UDP 37 parameters continued Read/ Data Default Parameter Write type Length Range value Description Setup Data Register 49 Value UINT16 0 – 65535 Setup Reg 50 (Low Density Limit) UINT8 1 – 16 FL (7) Setup Register 50 Data Type Setup Data Register 50 Value...
  • Page 219 Points and the TLP System Table C-2 UDP 37 parameters continued Read/ Data Default Parameter Write type Length Range value Description Setup Data Register 62 Value UINT16 0 – 65535 Setup Reg 63 (Temperature Cal Slope) UINT8 1 – 16 FL (7) Setup Register 63 Data Type Setup Data Register 63 Value...
  • Page 220 Points and the TLP System Table C-2 UDP 37 parameters continued Read/ Data Default Parameter Write type Length Range value Description STRNG30 30 “No Calibration State (0 = No Cal Active) Calibration Active” UINT8 0 , 1 Use External Temp (0 = No, 1 = Yes) T_L_P 0,0,0 External Temperature Source...
  • Page 221 Points and the TLP System Table C-3 UDP 39 parameters continued Read/ Data Default Parameter Write type Length Range value Description UINT8 0 , 1 , 2 , 4 User Write Reg 3 Read Status User Write Reg 3 Value STRNG20 20 “...
  • Page 222 Points and the TLP System Table C-3 UDP 39 parameters continued Read/ Data Default Parameter Write type Length Range value Description UINT8 0 – 16 User Write Reg 10 Data Type (Undefined) UINT8 0 , 1 , 2 , 4 User Write Reg 10 Read Status User Write Reg 10 Value ®...

  • Page 223: Appendix D Soft Points

    Appendix D Soft Points About this appendix This appendix defines soft points and describes the procedure for configuring them. Soft point overview Soft points are global storage areas for data that can be used by any user application running in the Model 3711.
  • Page 224 Soft Points Figure D-1 Soft Point dialog box 2. For each soft point to be configured: a. Select it from the dropdown list. Softpoints b. Enter the tag to be used to identify this soft point in the field. The tag can contain a maximum of 10 characters.

  • Page 225: Appendix E Opcode Tables

    Appendix E Opcode Tables About this appendix This appendix defines opcode tables and describes the procedure for configuring them. Opcode table overview Opcode tables are used in ROC protocol to minimize the number of polls that a host program must make to obtain the information that it requires.
  • Page 226 Opcode Tables Figure E-1 Opcode Table dialog box 2. Select the opcode table to use from the dropdown list. 3. Enter a version number for this opcode table. This value is used only for version tracking of opcode tables. Update it whenever you update the opcode table. 4.

  • Page 227: Index

    Index Numerics Auto Scan 4-wire remote installations, illustration 189 configuring interval 23 functionality 9 Autozero 46 Administration 157 Averaging technique 50 alarm log 163 device configuration files 165 event log 161 Backup battery 174 initializating the Model 3711 157 Barrier overview 4 See I.S.
  • Page 228 Index Communications temperature measurement parameters 41 configuring COMM 2 27 TLP notation 23 configuring passthrough mode 34 volumetric flow measurement parameters 49 configuring RBX alarming 32 Configuration files 11 configuring ROCLINK 800 communications downloading 166 parameters 30 exporting 167 Modbus interface to Model 3711 133 opening 165 overview 25 printing 167...
  • Page 229 Index Dial-up modem developing 110 command set 164 examples 128 configuring 27 FST Editor 108 FCC compliance 172 historical database commands 126 Direct Connect function 25 logical commands 121 Discrete inputs mathematical commands 120 configuring 70 miscellaneous commands 127 Discrete outputs monitoring and tracing 115 configuring 74 overview 107...
  • Page 230 Index History access registers 137 Memory History points flash 160 archive types 88 Model 3711 160 predefined standard history points 89 SRAM 160 Meter factor calculating 44 I.S. barrier 1 density 41 terminals 190 mass flow 39 Micro Motion customer service 4 channels 61 Modbus interface configuring 61...
  • Page 231 Index connection types 25 Opcode tables custom displays 96 configuring 217 debugging communications 171 overview 217 default operator ID and password 7 Operator ID and password installation 6 access levels 19 operator ID and password 16 device 17 security 16 ROCLINK 800 16 using 7 ROCLINK 800 default 7...
  • Page 232 Index TDO parameters 76 Volumetric flow measurement 49 Temperature configuring measurement parameters 41 Temperature coefficient 41 Warm start 158 Termination boards 191 Wiring problems 179 upgrading 170 Test points troubleshooting 181 Zero 46 configuring notation 23 overview 203 system 10 Troubleshooting battery 174 calibration 179...
  • Page 234 +31 (0) 318 495 670 (65) 6777-8211 +31 (0) 318 495 689 (65) 6770-8003 Micro Motion United Kingdom Micro Motion Japan Emerson Process Management Limited Emerson Process Management Horsfield Way Shinagawa NF Bldg. 5F Bredbury Industrial Estate 1-2-5, Higashi Shinagawa Stockport SK6 2SU U.K.

Table of Contents
