RTM-ATCA-F140
Installation and Use
P/N: 6806800M97A
October 2011
EA Version
Embedded Computing for
Business-Critical Continuity
TM

Advertisement

Table of Contents
loading

Related Manuals for Emerson RTM-ATCA-F140

Summary of Contents for Emerson RTM-ATCA-F140

  • Page 1 EA Version Embedded Computing for Business-Critical Continuity RTM-ATCA-F140 Installation and Use P/N: 6806800M97A October 2011...
  • Page 2 Emerson reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Emerson to notify any person of such revision or changes.

  • Page 3: Table Of Contents

    4.3.3 SFP Connection ............. . 39 RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 4 4.6.7 PHY Management Interfaces ..........49 RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 5 Related Documentation ............. . . 59 Emerson Network Power - Embedded Computing Documents ......59 Safety Notes .
  • Page 6 EA Version Contents Contents Contents RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 7 RTM-ATCA-F140 Mechanical Data ........
  • Page 8 EA Version List of Tables RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 9 Synchronous Ethernet Reference Recovery ....... . . 55 RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 10 EA Version List of Figures RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 11: About This Manual

    RTM and provides some information  on the IPMI functionality of the RTM. Related Documentation lists further Emerson user manuals that are related to the RTM and  the ATCA-F140. Safety Notes summarizes the safety instructions in the manual.
  • Page 12 Repeated item for example node 1, node 2, ..., node Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) Logical OR RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 13 Indicates a property damage message No danger encountered. Pay attention to important information Summary of Changes This manual has been revised and replaces all prior editions. Part Number Publication Date Description 6806800M97A August 2011 First edition RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 14 EA Version About this Manual About this Manual RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 15: Introduction

    The RTM-ATCA-F140 provides the I/O connection for the ATCA-F140 switch blade towards the back of the system. RTM-ATCA-F140 is directly connected to and powered by the front board. The RTM-ATCA-F140 is a rear transition module (RTM) as defined in PICMG 3.0 Revision 3.0 Advanced TCA Base Specification and PICMG 3.1 Revision 1.0 Specification Ethernet/Fiber...

  • Page 16: Standard Compliances

    Class 1.2 019-2-1, Class 1.2 equipment (not temperature controlled storage locations). ETSI Transportation: EN 300 019- The product is designed to comply with ETSI Transportation: EN 2-2 Class 2.3 300 019-2-2, Class 2.3 equipment (public transportation). RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 17 The product complies with VCCI Class A (Japan), Voluntary Control Council for Interference by Information Technology Equipment. Verizon CHECKLIST The product is designed to comply with the latest version of the Verizon Document VZ.NEBS.TE.NPI.2004.015: NEBS Checklist. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 18: Figure 1-1 Declaration Of Conformity - Tbd

    EA Version Introduction Figure 1-1 Declaration of Conformity - TBD RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 19: Mechanical Data

    Ordering Information The following table lists the blade variants that were available as of the time of writing this manual. Consult your local Emerson sales representative for the availability of further variants. Table 1-3 Blade Variants - Ordering Information Part Number...
  • Page 20 EA Version Introduction RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 21: Hardware Preparation And Installation

    4.4 cfm at 55 °C ambient temperature  Shipment Inspection To inspect the shipment, perform the following steps: 1. Verify that you have received all items of your shipment: Printed Quick Start Guide and Safety Notes Summary  RTM-ATCA-F140  RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 22: Environmental And Power Requirements

    PMC modules, with more restrictive environmental requirements. Operating temperatures refer to the temperature of the air circulating around the blade  and not to the actual component temperature. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 23: Table 2-1 Environmental Conditions

    40°C (104°F) under normal operating conditions. Under abnormal Short Term operating conditions such as an HVAC failure the RTM shall require no more than 5.0 CFM at the inlet ambient of 55°C (131°F). RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 24: Rtm Installation And Removal

    1,800m to 4,000m at 30°C Between 106 Kpa and 70 Kpa air pressure RTM Installation and Removal The RTM is fully compatible to the AdvancedTCA standard and is designed to be used in AdvancedTCA shelves. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 25: Installing The Rtm

    In this case it is a purely mechanical installation. Slow down and give blade insertion your full attention! If there are Rear Transition Modules (RTMs) to install, install/secure the RTMs first, then install the front blades. RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 26 4. Insert the RTM into the shelf by placing the top and bottom edges of the RTM in the card guides of the shelf. Ensure that the guiding module of the front blade and RTM are aligned properly. RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 27 8. Tighten the face plate screws which secure the RTM to the shelf. 9. If the front blade has already been installed (as in step 2), activate the front blade by squeezing its lower lever and latch together and press it back into the face plate. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 28: Removing The Rtm

    The front board blue LED blinks indicating that the blade power-down process is ongoing. Data Loss Removing the blade, with the blue LED still blinking, will cause data loss. Wait until the  blue LED is permanently illuminated, before removing the blade. RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 29 4. Unfasten the screws of the RTM face plate until the RTM is detached from the shelf. 5. Unlatch the RTM upper and lower handles and rotate fully outward. Remove the blade from the shelf. RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 30 EA Version Hardware Preparation and Installation RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 31: Controls, Leds, And Connectors

    Controls, LEDs, and Connectors Overview This chapter describes: Face plate connectors  Face plate LEDs  Reset key  Rear panel connectors  Face Plate Connectors and LEDs The following figure shows the face plate of the RTM. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 32: Face Plate

    EA Version Controls, LEDs, and Connectors Figure 3-1 Face Plate RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 33: Leds

    EA Version Controls, LEDs, and Connectors 3.2.1 LEDs RTM-ATCA-F140 provides four panel-visible LEDs that provide the standard ATCA management LED functions: Red (out of service)  Green (in service)  Blue (hot-swap initializing/ shutting down)  Amber (attention)  RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 34 EA Version Controls, LEDs, and Connectors RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 35: Functional Description

    Chapter 4 EA Version Functional Description Block Diagram Figure 4-1 Block Diagram RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 36: Management Resources

    4.2.1 FRU Serial EEPROM The RTM-ATCA-F140 provides a 128Kb (16K byte) I2C serial EEPROM. This is a 24LC128T-type device. The EEPROM resides at I2C address 0xA0. It is supplied with +3.3V management power and thus is available regardless of payload power.

  • Page 37: Leds

    EA Version Functional Description 4.2.3 LEDs The RTM-ATCA-F140 provides four panel-visible LEDs that provide the standard ATCA management LED functions: Red - Out of Service  Green - In Service  Blue - Hot swap (initializing / shutting down) ...

  • Page 38: I2C Address Map

    Temperature sensor (bottom) 0xA0 Serial EEPROM 1 Gbps SFP Ports The RTM-ATCA-F140 provides four 1 Gbps SFP module sites which are connected to the front- blade base switch. 4.3.1 Connectivity Four 1000Base-BX serdes connections from the front-blade are routed directly from the zone...

  • Page 39: Front-Blade Port Mapping

    SFP devices tested with this product. The following table shows the SFP connector pin assignments. Table 4-5 SFP Connector Pin Assignment Signal Signal TX_FAULT TX_DISABLE I2C_SDA I2C_SCL VCCr (+3.3V) MOD_ABS VCCt (+3.3V) RATE_SEL RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 40: I2C Bus

    FPGA to allow control by the service processor. Refer to the Chapter 4, FPGA, on page 52 details. 10 Gbps SFP+ Ports The RTM-ATCA-F140 provides a two 10Gbps SFP+ module sites connected to the base switch on the front blade. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 41: Connectivity

    Figure 4-3. The RTM-ATCA-F140 includes 0.1μF AC-coupling capacitors on the XAUI inputs from the front blade. Similarly, capacitors are expected to be provided on the front blade for signals from the RTM. The SFP+ specification requires AC-coupling capacitors in the module so they are not needed on the board SFI interface.

  • Page 42: Bcm8727 Status

    I2C Bus The SFP+ I2C bus signals (I2C_SDA and I2C_SCL) from each SFP+ site are individually connected to the corresponding BCM8727 which includes a mechanism to allow access to the port through the phy management channel. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 43: Sfp+ Status Signals

    SFP+ Port Channel b1011 Base BIX_XG1 Base SFP+ 2 BIX_XG_MDC/ MDIO Base BIX_XG0 Base SFP+ 1 10Gbps Fabric Ports The RTM-ATCA-F140 provides four 10Gbps SFP+ module sites connected to the fabric switch on the front blade. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 44: Fabric Connectivity

    SFI interface as shown in Figure 4-4. The RTM-ATCA-F140 includes 0.1μF AC-coupling capacitors on the XFI inputs from the front blade. Similarly, capacitors are expected to be provided on the front blade for signals from the RTM. The SFP+ specification requires AC- coupling capacitors in the module so they are not needed on the board SFI interface.

  • Page 45: Bcm84754 Status

    The RS0 and RS1 rate select signals from each SFP+ that are tied together and connected to the RTM FPGA that allows them to be controlled by software. Refer to Chapter 4, GPS Connectors, on page 50 for further detail. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 46: Phy Management Interfaces

    40GbE logical connection. When the fabric switch is configured for 4x XFI mode, the QSFP+ slot supports four 10GbE connections. This mode assumes the use of a fiber breakout cable on the QSFP+ module (MPO to 4x LC cable). The RTM-ATCA-F140 includes RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 47: Fabric Front Blade Port Mapping

    QSFP+ site. This places the PHY and QSFP+ module into low-power mode but may not actually disable the QSFP+ transmitters, according to the QSFP+ specification. Transmitter control should be performed through the software method detailed above. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 48: Bcm84740 Status

    Table 4-9"QSFP+ Connector Pin Assignment". Table 4-9 QSFP+ Connector Pin Assignment Signal Signal TX2- TX1- TX2+ TX1+ TX4- TX3- TX4+ TX3+ MODSEL# LPMODE RESET# VCC1 (+3.3V) VCCR (+3.3V) VCCT (+3.3V) I2C_SCL INT# I2C_SDA MODPRS# RX3+ RX4+ RX3- RX4- RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 49: Qsfp+ I2C Bus

    Table 4-10 BCM84740 PHY Addressing Address Address QSFP+ Management High Bits Channel Source Low Bits Address Switch Port Port Channel b000 Fabric FIX_P14 Fabric FIX_XG_MDC Lane 0 QSFP+ 2/ MDIO2 RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 50: Gps Connectors

    10 MHz clock, and serial time-of-day information from a GPS receiver. 4.7.1 1PPS Input An SMA connector is provided on the front panel of the RTM-ATCA-F140 for reception of a 1PPS signal from a GPS receiver. Below are the characteristics of this input: Table 4-11 1PPS Input Specifications...

  • Page 51: 10Mhz Input

    Functional Description 4.7.2 10MHz Input An SMA connector is located on the front panel of the RTM-ATCA-F140 to receive a 10MHz clock signal from a GPS receiver. Characteristics of this input are: Table 4-12 10MHz Input Specifications 10MHz SMA Input...

  • Page 52: Fpga

    EA Version Functional Description FPGA The RTM-ATCA-F140 includes a Xilinx XC3S200A-4 FPGA that which performs the following functions: Access to control and status signals on SFP, SFP+, and QSFP+  Access to control and status signals on the BCM8727, BCM84754, and BCM84740 ...

  • Page 53: Bcm8727 Control And Status

    PHYs to be placed into low-power mode and disables the associated SFP+ transmitters. The RTM FGPA provides access to the LASI status signals of the BCM84754s. Each signal can be programmed to cause an interrupt when its state changes. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 54: Bcm84740 Control And Status

    The RTM FPGA provides two identical blocks that each select between all of these clock sources (ten total) and convert it to an 8kHz reference that is connected to the front blade telecom clock subsystem. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 55: Spi Flash

    SPI Flash devices, one for each type. Register settings allow access to be granted to any of the PHYs and also provide a programming port. 4.8.9 FPGA Register Map Details of the FPGA register map are included in the RTM FPGA section of the ATCA-F140 FPGA design guide. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 56: 4.8.10 Fpga Configuration

    RTM can withstand signal voltages when unpowered and does not attempt to power itself through input protection diodes. All the 1Gbps, 10Gbps, and 40Gbps Ethernet ports are AC-coupled at some point in their signal path and therefore no additional measures are needed. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 57: 4.11 Power Management

    EEPROM, temperature sensors and I/O extender device. +12V payload power is the source for the onboard DC to DC converters needed for the RTM payload. 4.11.1 Power Requirements The table below summarizes the power requirements of the RTM-ATCA-F140. Table 4-15 Power Requirements Voltage Maximum Current +3.3V Management...
  • Page 58 EA Version Functional Description RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 59: Related Documentation

    The publications listed below are referenced in this manual. You can obtain electronic copies of Emerson Network Power - Embedded Computing publications by contacting your local Emerson Sales Office. For released products, you can also visit our Web site for the latest copies of our product documentation.
  • Page 60 EA Version Related Documentation RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 61: Safety Notes

    Emerson intends to provide all necessary information to install and handle the product in this manual. Because of the complexity of this product and its various uses, we do not guarantee that the given information is complete.
  • Page 62 Changes or modifications not expressly approved by Emerson could void the user's authority to operate the equipment. Board products are tested in a representative system to show compliance with the above mentioned requirements.
  • Page 63 Therefore, carefully inspect the RTM and the backplane for both pin and component integrity before installation. Emerson and our suppliers take significant steps to ensure there are no bent pins on the backplane or connector damage to the blades/RTMs prior to leaving the factory. Bent pins caused by improper installation or by inserting blades with damaged connectors could void the Emerson warranty for the backplane or blades.
  • Page 64 SFP/SFP+ module inoperable. Only remove the optical plug when you are ready to connect a cable to the SFP/SFP+ module. When no cable is connected, cover the port with an optical port plug. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 65: Sicherheitshinweise

    Produkt mit vielfältigen Einsatzmöglichkeiten handelt, können wir die Vollständigkeit der im Handbuch enthaltenen Informationen nicht garantieren. Falls Sie weitere Informationen benötigen sollten, wenden Sie sich bitte an die für Sie zuständige Geschäftsstelle von Emerson. Das System erfüllt die für die Industrie geforderten Sicherheitsvorschriften und darf ausschließlich für Anwendungen in der Telekommunikationsindustrie und im Zusammenhang...
  • Page 66 EA Version Sicherheitshinweise Das Produkt wurde in einem Emerson Standard system getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Produktes in Gewerbe- sowie Industriegebieten...
  • Page 67 Pins und Stecker von Blades/RTMs vor dem Verlassen der Produktionsstätte in einwandfreiem Zustand befinden. Verbogene Pins, verursacht durch fehlerhafte Installation oder durch Installation von Blades/RTMs mit beschädigten Steckern kann die durch Emerson gewährte Garantie für Blades und Backplanes erlöschen lassen.
  • Page 68 Die Schutzkappe eines SFP/SFP+-Modules dient dazu, die sensible Optik des SFP/SFP+- Modules gegen Staub und Schmutz zu schützen. Entfernen Sie die Schutzkappe nur dann, wenn Sie beabsichtigen, ein Kabel anzuschließen. Andernfalls belassen Sie die Schutzkappe auf dem SFP/SFP+-Modul. RTM-ATCA-F140 Installation and Use (6806800M97A)

  • Page 69: Index

    EA Version Index abbreviations block diagram connectors controls conventions environmental requirements face plate features functional description installation, hardware installation, RTM leds removal, RTM RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 70 EA Version Index RTM-ATCA-F140 Installation and Use (6806800M97A)
  • Page 71 EA Version...
  • Page 72 Precision Cooling Surge & Signal Protection Emerson, Business-Critical Continuity, Emerson Network Power and the Emerson Network Power logo are trademarks and service marks of Emerson Electric Co. All other product or service names are the property of their respective owners.
