RT540E OPERATOR MANUAL
Pump #2
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Gear
Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Output - @ 172.4 bar (2,500 psi) w/no load
Section 1 . . . . . . . . . . . . .86.5 l/min (22.9 gpm)
Pump #3
Type . . . . . . . . . . . . . Gear with priority flow divider
Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Output - @ 199.9 bar (2,900 psi) w/no load
Section 1 . . . . . . . . . . . . .57.2 l/min (15.1 gpm)
TRANSPORTATION AND LIFTING DATA RT540E
E
6118 kg
(13487 lb)
BOOM (W/O BOOM EXTENSION)
G H
4305 kg
(9490 lb)
76.5 cm
(30.1 in)
COUNTERWEIGHT (CWT)
J
636 kg
99.3 cm
(1403 lb)
(39.1 in)
13109 kg
(28899 lb)
B
A
158.8 cm
( 6 2 . 5 i n )
G7
8696
GROVE
F
470.7 cm
(185.3 in)
L C
BOOM
PIVOT
L C
ROTATION
C
D
131.6 cm
4271 kg
(58.1 in)
(9416 lb)
TURNTABLE (T/T)
L C
REAR AXLE
B
328.2 cm
(129.2 in)
A
CARRIER
Published 01-15-2016, Control # 526-01
Hoists
Drum Dimensions
Diameter . . . . . . . . . . . . . . . 270 mm (10.63 in)
Length (Standard) . . . . . . . . . 419 mm (16.5 in)
Cable
Diameter . . . . . . . . . . . . . . . . . . 16 mm (5/8 in)
Length-Main . . . . . . . . . . . . . . . .137 m (450 ft)
Length-Aux. . . . . . . . . . . . . . . . .137 m (450 ft)
Max. Permissible Line Pull
(6x36). . . . . . . . . . . . . . . . . . . . .52.4 kN (11,770 lb)
Max. Single Line Speed . . . .156.7 m/min (514 fpm)
Hoist Motor Displacement
Low . . . . . . . . 107 cm
High . . . . . . . . 61 cm
TOTAL CARRIER LIFT
T/T BOOM
UNIT CYL
LIFT LIFT
4 X
A X
B 4 X X X X
2
C X
D 2 X
2
E
F 2
2
G
2
H
J –
X
1. LIFTING OF ENTIRE CRANE OR MAJOR CRANE ASSEMBLIES MUST BE ACCOMPLISHED BY
UTILIZING SPECIFIC FITTINGS INDICATED ON ABOVE CHART. USE OF FITTINGS FOR
PURPOSES OTHER THAN THOSE DESIGNATED ON CHART IS PROHIBITED.
FITTING CAPACITIES ARE MAXIMUM ALLOWABLE LOADS PER INDIVIDUAL FITTING.
2. RIGGING PERSONNEL SHALL BE RESPONSIBLE FOR PROPER SELECTION AND PLACEMENT
OF ALL SLINGS AND LOAD HANDLING DEVICES.
3. DIMENSIONS AND WEIGHTS SHOWN ARE FOR HEAVIEST CONFIGURATION AVAILABLE.
4. RIGGING PERSONNEL SHALL VERIFY DIMENSIONS AS REQUIRED FOR CLEARANCE.
5. EXTEND OUTRIGGER BEAMS 46 CM (18 IN) AND SLING AROUND BEAMS.
6. DO NOT USE PINTLE HOOKS OR CWT LUGS FOR LIFTING OR TIE DOWN OF ENTIRE CRANE.
1194.3 cm
(470.2 in)
B
A
29185 kg
(64341 lb)
TOTAL UNIT (WITH BOOM EXT)
INTRODUCTION
3 3
(6.53 in ) per revolution
3 3
(3,72 in ) per revolution
CWT FITTING CAPACITY (TONS)
TIE DOWN
LIFT LIFT LIFT TOW
FORE
SIDE DOWN
&
AFT
12 SEE NOTE #5
82 25 35 7.1
7.9
2.3
X
3.4
X 3.4
X
2.2
X 9.4
N/A
B
A
181.4 cm
(71.4)
L C
REAR AXLE
FIGURE 1-1
1
80073532
1-3
