SET-UP AND INSTALLATION PROCEDURES
Ball
One Part Line
Using Fixed Boom Extension
Shown at 15°Offset
4-6
One Part Line
Using Fixed Boom Extension
To Hoist
6710-9
Published 01-15-2016, Control # 526-01
RT540E OPERATOR MANUAL
Mast On Boom
To Hoist
Extension
To Hoist
One Part Line
Using Fixed Boom Extension
Shown at 30°Offset
FIGURE 4-6 continued
6710-2
6710-8
