OPERATING CONTROLS AND PROCEDURES
3-32
Figure 3-15 Item Numbers
Item Description
1 Menu Screen Indicator
2 Status Indicator Bar
3 Outrigger Group
4 Outrigger Button
5 WRL Swing Group
6 WRL Height Limit Reached
7 WRL Boom Angle Limit Reached
8 WRL Swing Angle Limit Reached
9 WRL Radius Limit Reached
10 WRL Virtual Wall Limit Reached
11 Tools Group
12 Display Brightness Settings
13 Standard/Metric Display
14 Control Lever Settings
15 Function Speed Setting
16 Information Group
17 Operating Hours
18 Engine System Warning
19 Crane Error
20 Software Revision
21 Active Screen Indicator
