Troubleshooting
This chapter describes how to troubleshoot the universal gateway by referring to the LEDs on DFCs, and
using the bantam jacks. The chapter contains the following sections:
• LEDs, page 6-1
Mixing WAN DFCs, page 6-5
•
• Environment Monitoring, page 6-6
Using the Bantam Jacks for Test Port Functionality, page 6-9
•
Troubleshooting Network Interfaces, page 6-10
•
Getting Help, page 6-10
•
LEDs
The LEDs indicate the current operating condition of the dial feature cards. Observe the LEDs (see
Figure 6-1
contact your system administrator or a customer service representative (see
Assistance"
Figure 6-1
78-13311-01
through Figure 6-4), note any fault condition that the product is encountering, and then
in the "Preface"), if necessary. Refer to
2-Port or 4-Port T1 or E1 DFC LEDs
0
1
0
1
Cisco AS5350 and Cisco AS5400 Universal Gateway Card Installation Guide
C H A P T E R
Table 6-1 for a description of the LEDs.
ACTIVITY (ACT)
OK/MAINT
6
"Obtaining Technical
6-1
