Wiring diagram with OEM Remote Start
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
D2D Port
(-) Ground
(+) 12V Input
(-) Hood Input
(+) Ignition Status Input
9 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
(-) Parking Lights:
Gray or Yellow,
pin 11
Parking Light
Interrupt :
CUT
Hood Pin
Refer to
'Vehicle connections'
for wire and connector
details.
Headlight Switch
9 1
(+)12V: Pin 24
10 2
11 3
12 4
CAN 1 High:
13 5
P in 4 White/Blue or Blue, pin 20
14 6
15 7
CAN 1 Low:
White, pin 19
8
16
CAN 2 High: Tan/Black: 3
CAN 2 Low: Tan: 4
CAN 1 High: Orange/Green: 5
CAN 1 Low: Orange/Brown: 6
Parking Lights Interr. (conn. side): Orange/Red:10
Parking Lights Interr. (veh. side): Yellow/Red:11
(-) Parking Lights Output : Brown/Red:12
(-) Trunk Release Output: Black/White: 1
(+) Ignition Status Output : Gray/Black: 7
Gateway Module
(on OBDII Connector or
right of steering column)
13
24
12
CAN 2 High: Pin 23
11 23
CAN 2 Low: Pin 22
10 22
9 21
8 20
19
7
6 18
5 17
4
16
(-) Ground: Pin 14
3 15
14
2
1
).
XKD2D65
