Vehicle connections

The connection information listed below is specific to the 2015 Lincoln MKZ Hybrid (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
11 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Description
No Connection
No Connection
(Data) HS CAN 2 High (w/ OEM Remote Start) or
(Data) HS CAN 3 High (w/o OEM Remote Start)
(Data) HS CAN 2 Low (w/ OEM Remote Start) or
(Data) HS CAN 3 Low (w/o OEM Remote Start)
(DATA) HS CAN 1 High
(DATA) HS CAN 1 Low
Relay N.O. No Connection
Relay COM No Connection
Relay N.C. No Connection
Relay N.C. Parking Light Interrupt (conn. side)
Relay COM Pk Parking Light Interrupt (vehicle side)
Relay N.O. (-) Parking Light Output
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
(-) Trunk Release Output
No Connection
(-) W2W Only - Door Output
(-) W2W Only - Trunk Output
(AC) W2W Only - Tach Output
(+) W2W Only - Brake Output
(+) Ignition Output
No Connection
No Connection
No Connection
No Connection
(-) W2W Only - Hood Output
Connects To
Wire Location
No Connection
No Connection
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 23
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 18
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 22
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 17
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 20
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 19
No Connection
No Connection
No Connection
headlight switch, black 16 pin plug, pin 4
headlight switch, black 16 pin plug, pin 4
headlight switch, black 16 pin plug, pin 11
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 24
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 14
Connects To
Wire Location
release switch, black or brown 6 pin plug, pin 6
Not Applicable
No Connection
Remote Starter
Remote Starter
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
No Connection
No Connection
Remote Starter
(+/-) Wire Color
data gray (MS CAN)
data green (HS2 CAN)
data violet (MS CAN)
data gray (HS2 CAN)
data blue (HS CAN)
data white (HS CAN)
cut black/blue
cut black/blue
- yellow
+ Gray/Red (7.5A)
- Black/Blue
(+/-) Wire Color
- gray/yellow
