Directed Directechs DB3 Installation Manual page 12

Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire
Ground 2
Hood Pin
Ignition
Second 12 Volts
12 403.FORD12 1.60 2015 Lincoln MKZ Hybrid (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
(-) W2W Only - Trunk Input
No Connection
No Connection
[1]
(-) Hood Input
No Connection
(+) W2W Only - Starter Input
No Connection
(-) W2W Only - GWR Input
Color
Blue
Black
Green
Red
Color
N/A
N/A
Connects To
Wire Location
Gateway Module on OBD-Data Link Connector, black 24 pin plug,
pin 14
BCM/dash fuse box, black 40 pin plug (C), pin 14
BCM/dash fuse box, black 22 pin plug (H), pin 6
Gateway Module on OBD-Data Link Connector, black 24 pin plug,
pin 24
Connects To
Wire Location
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
No Connection
Remote Starter
No Connection
Remote Starter
(+/-)
-
-
+
+
(+/-) Wire Color
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
No Connection
No Connection
Wire Color
Black/Blue
blue/orange
blue/gray (for ignition sense only)
Gray/Red (7.5A)
