System Unit Rear Panel Connectors - HP Visualize b160L Supplementary Manual

Chap1.doc 9 Thu Jul 25 10:22:00 1996
NOTICE:
Single-Ended
SCSI
Security
Loop
Pullout
Card
Audio
Audio
Line Out
Line In
HP Parallel
Figure 2

System Unit Rear Panel Connectors

This section describes the connectors on the system
unit's rear panel
To maintain electro-magnetic and radio frequency
emissions compliance, verify that all cables are
fully seated and properly fastened.
Figure 2 shows the locations of the connectors on the
system unit's rear panel.
Fast, Wide SCSI
Monitor
TOC
LAN-TP LAN-AUI

System Unit Rear Panel Connectors

Product Information
System Unit Rear Panel Connectors
PS/2 Mouse
PS/2 Keyboard
Power
Serial 1
Serial 2
9
