SS Checker
TS-1000-D/
TS-1000SP-D
Thank you very much for purchasing SS Checker TS-1000-D/
TS-1000SP-D.
All of this instruction manual must be read before operation of this
SS Checker for safe and proper operation.
This instruction manual should be kept for future reference such as
maintenance.
The instruction manual is also available on the following website.
https://navi.optex.net/manual/05325/?lang=en
WATER it
Instruction
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-1000-D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Optex TS-1000-D

Summary of Contents for Optex TS-1000-D

  • Page 1 TS-1000-D/ Instruction TS-1000SP-D Manual Thank you very much for purchasing SS Checker TS-1000-D/ TS-1000SP-D. All of this instruction manual must be read before operation of this SS Checker for safe and proper operation. This instruction manual should be kept for future reference such as maintenance.
  • Page 2 The Contents of Packaging Sensor: 1 Lifting lug: 1 Hanging attachment: 1 Cable protective cover: 1 Cable tying band: 5 Instruction manual (this document) If there are any missing or faulty items, please contact our sales representative. Can be connected to SC-U1. Reference...

  • Page 3: Table Of Contents

    Table of Contents For Safe Use ................5 Component Name ..............7 Installation ................8 Sensor installation ..............8 Extension of sensor cable ........... 11 Wiring ................... 12 Sensor Setting ..............13 Display item ................ 13 Response time ..............14 4-20 mA Setting ..............
  • Page 4 11 Cleaning ................30 Manual cleaning ..............30 Cleaning interval ..............30 12 Troubleshooting ..............31 Error code list ..............31 13 Maintenance ................. 33 Maintenance (monthly) ............33 Periodic inspection (every 3 months) ........33 Replacement of consumables ..........33 Calibration ................

  • Page 5: For Safe Use

    ● Please thoroughly read "For Safe Use" before using this SS Checker properly. ● Because these precautions are related to failure or malfunction, observe the precautions for use without fail. Do not use TS-1000-D/TS-1000SP-D except for measurement of water quality. " " denotes "Prohibited action", and "...
  • Page 6 To clean the sensor, first Do not wipe the sensor with wipe away lightly with a clean solvent such as Thinner. soft cloth damped by diluted It may cause failure. mild detergent solution and then wipe off moisture with a dry clean soft cloth. Avoid strong physical Do not apply oil such as shock to the sensor or do...

  • Page 7: Component Name

    Component Name Sensor cable Detection windows Wiper blade ・ Do not carry the sensor with the sensor cable. Caution ・ Do not touch the detection window. Clean the detection window if your hand touches it.

  • Page 8: Installation

    Installation Sensor installation Before installation, turn off the power switch of SC-U1 or disconnect the power cable from the supply source and wire the power cable after the installation is complete. " " denotes "Prohibited action", and " " denotes "Required action" . Suspend the sensor so as With fluctuation of water not to impinge upon a wall...
  • Page 9 For details, contact your dealer or visit our website: https://www.optex.co.jp/e/products/ environmental-sensor/ ・ Read the precautions in the “TA-1 instruction manual” carefully. ・ Attach the cable protective cover without fail. Otherwise, there is a possibility that a cable is scratched during maintenance operation and water intrudes.
  • Page 10 Run the lifting lug through the end of the chain. The chain kit (TA-2: for TS-1000-D only) is optionally available. Reference For details, please contact the dealer or visit our website: https://www.optex.co.jp/e/products/environmental-sensor/...

  • Page 11: Extension Of Sensor Cable

    Put the cable protective cover up to the root of the sensor cable and secure it to the chain or other device with a cable tying band. Use a cable tying band to secure. Cover the cable protective cover over the end of the sensor cable.

  • Page 12: Wiring

    Wiring Use this product by connecting to Universal Transmitter SC-U1. For installation and wiring to SC-U1, refer to the “Universal Transmitter SC-U1 Installation Manual”. Before wiring, turn off the power switch of SC-U1 or disconnect the power cable from the supply source and wire the power cable after all the other wiring is complete.

  • Page 13: Sensor Setting

    Sensor Setting The following settings are available from SC-U1. To start sensor setting, press Caution Pressing automatically retains the measurement value. Display item Set the measurement item to show on the main display and the 2nd display of the SC-U1 display. Main display 2nd display Select an item from the following.

  • Page 14: Response Time

    Display item Factory default Measurement item setting Item Unit Main Suspended solids mg/L SS mg/L display No unit Transparency Trans. display Suspended solids No unit mg/L Transparency Trans. The following display resolutions are available. ・ 0.0 - 49.9: 0.1 ・ 50 - 1000: 1 Transparency ・...

  • Page 15: 4-20 Ma Setting

    4-20 mA Setting Set the 4-20 mA signal output setting from SC-U1. The factory default setting is OFF for 4-20 mA signal output. To set 4-20 mA output setting, press Caution Pressing automatically retains the measurement value. Output item selection Select an item to output by 4-20 mA signal.

  • Page 16: Upper/Lower Limit Of Signal Output Range

    Upper/lower limit of signal output range For the item by 4-20 mA signal output, set the measurement value to output at lower limit (Lo, 4 mA) and upper limit (Hi, 20 mA). 20 mA Signal output 4 mA Measurement Measurement value at 4 mA value at 20 mA For operation, refer to the "Universal Transmitter SC-U1 Operation...

  • Page 17: Relay Setting

    Relay Setting Set the relay output setting from SC-U1. The factory default setting is OFF for relay output. To set the relay setting, press Caution Pressing automatically retains the measurement value. Alarm output setting Set the alarm to be output when the measurement value exceeds a certain value.

  • Page 18: Maintenance Output Setting

    Maintenance output setting Set a maintenance timer for any cycle (“Maintenance timer” P.29) to notify the user when the set period has elapsed. Use this for notification of sensor maintenance, replacement of consumables, and overhaul timing. Check notifications by the relay output and dedicated cloud server (SC-U1 and GW connected).

  • Page 19: Calibration

    Calibration Perform calibration before using the sensor or after cleaning. Distilled or deionized water is required. To calibrate SC-U1, press Caution Pressing automatically retains the measurement value. Zero calibration Immerse the sensor in distilled water or ion-exchange water and adjust the measurement value to the reference value (zero).
  • Page 20 Select a channel connected to TS-1000-D using and press TS-1000SP-D is also displayed as Measurement Sensor item model [TS-1000-D]. Sensor channel The calibration menu is displayed. Select [ZERO Cal.] using , and press The calibration starts. During calibration a processing display is displayed.
  • Page 21 When the calibration is complete, check the result. good: The calibration is properly completed. good E4100 to 4199: Calibration failed. E4100 Try the steps again from 1. Pressing switches to the measurement value display.

  • Page 22: Adjustment

    Suspended solids [SS] -100.0 to 100.0 0.0 Transparency [Trans.] -10 to 10 Press The measurement item selection display is displayed. Select [SS TS-1000-D] using , and press TS-1000SP-D is also displayed as [TS-1000-D]. Sensor model to switch pages. Measurement item The adjustment menu is displayed.

  • Page 23: Span Adjustment

    Select [Offset Adjustment] using , and press Enter the offset value. Select a digit by value by , and press When a value outside the set range is entered, a short beep sounds. Pressing simultaneously while entering a value resets the value to the factory default setting.
  • Page 24 0.30 to 3.00 1.00 Transparency [Trans.] 0.30 to 3.00 1.00 Press The measurement item selection display is displayed. Select [SS TS-1000-D] using , and press TS-1000SP-D is also displayed as [TS-1000-D]. Sensor model to switch pages. Measurement item Sensor channel The adjustment menu is displayed.

  • Page 25: 2-Point Adjustment

    During adjustment a progress bar is displayed. When completed, the display returns to the measurement value display. 2-point adjustment Display current values of the 2 points as any adjustment values, respectively. Performing 2-point adjustment changes the offset and span based on the adjusted values.
  • Page 26 Select [SS TS-1000-D] using , and press TS-1000SP-D is also displayed as [TS-1000-D]. to switch pages. Sensor model Measurement item Sensor channel The adjustment menu is displayed. Select [2-Point Adjustment] using , and press Enter the [Point 1] display, [Point 1] adjusted, [Point 2] display, and [Point 2] adjusted values in this order.

  • Page 27: Adjustment Initialization

    2-point adjustment. Adjustment initialization Reset the adjustment value to the factory default value. Press The measurement item selection display is displayed. Select [SS TS-1000-D] using , and press TS-1000SP-D is also displayed as [TS-1000-D]. to switch pages.

  • Page 28: Maintenance Setting

    Maintenance Setting Set the maintenance setting from SC-U1. To perform maintenance, press Caution Pressing automatically retains the measurement value. Measurement value hold The latest measurement value is retained (held). This is used for sensor maintenance and cleaning. For operation, refer to the "Universal Transmitter SC-U1 Operation Manual", "8 Maintenance Setting"...

  • Page 29: Maintenance Timer

    Maintenance timer Set a maintenance timer for any cycle to notify the user when the set period has elapsed. This is used for notification of sensor maintenance, replacement of consumables, and overhaul timing. Check notifications by the relay output (“Maintenance output setting” P.18) and the dedicated cloud server (SC-U1 and GW connected).

  • Page 30: Cleaning

    Cleaning Set the sensor cleaning setting from SC-U1. To perform cleaning, press ・ Pressing automatically retains the measurement value. Caution ・ Do not press while a sensor with a wiper is in the air. This may cause the sensor to malfunction. Manual cleaning Activate the wiper manually.

  • Page 31: Troubleshooting

    Troubleshooting Error code list The following table describes error codes, causes and actions. If you find any problem other than the error codes, refer to “When in trouble” in the "Universal Transmitter SC-U1 Operation Manual". When the normal condition is not recovered after the countermeasure is taken, when any problem other than these occurs, or when requesting repairs, check the model and the serial No.
  • Page 32 Error code and details Cause Action E3100 to E3199 The detection Clean the detection Measurement error window is not window if it is not clean. clean. E3200 to E3299 The temperature The water temperature must be 0 to 40 ° C. Temperature error of the water to measure is out of...

  • Page 33: Maintenance

    Maintenance ・ To clean the sensor, lightly wipe with a clean, soft cloth and water diluted with a mild detergent, and then wipe with a dry, Caution soft cloth. ・ Do not wipe the sensor with organic solvent such as benzine. ・...

  • Page 34: Calibration

    As the packing will deteriorate over time, we recommend replacing the maintenance parts every 3 years. For details, contact the dealer. Specifications Name SS Checker Model TS-1000-D TS-1000SP-D (for seawater) Measurement SS: 0.0 - 1000 mg/L (kaolin) range Transparency: 0 - 100 cm (JIS K 0102 2016) Display SS: 0.0 - 49.9 mg/L: 0.1 mg/L...

  • Page 35: External Dimensions

    0 to 40 ° C (unfrozen) Operating temperature Major Main body: SUS316L Main body: SUS329J4L material Sapphire glass, fluorocarbon rubber, EPDM, POM ø32 × 163 mm (excluding Hanging Attachment) Dimensions Weight Approx. 930 g Degree of IP68, maximum depth of 2 meters (underwater type) protection Sensor cable length...
  • Page 36 Whole document of the DOC can be referenced in the following website ; www.optex.net OPTEX CO., LTD. 5-8-12, Ogoto, Otsu, Shiga, 520-0101 Japan el.+81-77-579-8680 Fax.+81-77-579-8199 https://www.optex.co.jp/e/products/environmental-sensor/ 2021.10 59-2958-1...

This manual is also suitable for:

Ts-1000sp-d

Table of Contents
