1 Product Overview

Featuring leading 802.11ac Wave2, Ruijie RG-AP730-L supports 2.4G+5G+5G working mode and concurrently 802.11ac
Wave 2, 802.11ac Wave 1 and 802.11n. It delivers up to 400Mbps@2.4G (802.11b/g/n) and 1.73Gbps@5G
(802.11a/n/ac). The overall tri-radio, dual-band performance speeds up to 2.13Gbps per device, totally eliminating Gigabit
wireless bottlenecks. The AP can be mounted on a ceiling or wall. And it supports local power supply and PoE to meet
challenges in a wide variety of deployment scenarios, including large-scaled campuses, enterprises, hospitals and WiFi
hotspots.

1.1 Technical Specifications

Table 1-1 Technical Specifications of RG-AP730-L
Hardware Specifications
Radio
RF
Transmission
Protocol
Operating Bands
Antenna
Spatial Streams
Access Rates
Modulation
Receive Sensitivity
Maximum Transmit
Power
Transmit Power
Adjustment
Physical
Dimensions
2.4GHz: 2 x 2MIMO
5GHz: 2 x 2MU-MIMO
Support concurrent 802.11ac and 802.11 a/b/g/n.
Supports 2.4G + 5G +5G
802.11b/g/n: 2.4 GHz to 2.4835 GHz
802.11a/n/ac: 5.15 GHz to 5.35 GHz, 5.47 GHz to 5.725 GHz, 5.725 GHz to 5.85GHz
(Depending on which country the AP is installed)
Built-in smart antenna
2 streams per radio card
Up to 6 streams per device
2.4GHz: up to 400Mbps
5GHz: up to 1.73Gbps
Total: up to 2.13Gbps
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM , 64QAM and 256QAM
11b: -96dBm(1Mbps), -93dBm(5Mbps), -89dBm(11Mbps)
11a/g: -91dBm (6Mbps), -85dBm (24Mbps), -80dBm (36Mbps), -74dBm (54Mbps)
11n: -90dBm@MCS0, -70dBm@MCS7, -89dBm@MCS8, -68dBm@MCS15
11ac HT20: -88dBm (MCS0), -63dBm (MCS9)
11ac HT40: -85dBm (MCS0), -60dBm (MCS9)
11ac HT80: -82dBm (MCS0), -57dBm (MCS9)
≤100mw (20dBm)
(Depending on the country of use, laws and regulations.)
1 dBm
230 mm x 230 mm x 47 mm (Only host, excluding the bracket)
·
