Detailed Description - Xilinx ML628 User Manual

Chapter 1: ML628 Board Features and Operation
The ML628 board block diagram is shown in
X-Ref Target - Figure 1-1
12V Power In
FPGA Power Source
On-board Regulation:
VCCINT 1.0V at 40 Amps
VCCO 2.5V at 20 Amps
VCCAUX 2.5V at 20 Amps
Auxiliary Power
On-board Regulation:
5.0V at 13 Amps
3.3V at 20 Amps
2.5V at 20 Amps

Detailed Description

Figure 1-2
that is referenced in
Note:
8
Caution!
The ML628 board can be damaged by electrostatic discharge (ESD). Follow
standard ESD prevention measures when handling the board.
Transceiver and
Transceiver Clock SMA
GTH QUAD_106
GTH QUAD_107
GTH QUAD_108
GTH QUAD_116
GTH QUAD_117
GTH QUAD_118
Transceiver and
Transceiver Clock SMA
GTX QUAD_100
GTX QUAD_101
GTX QUAD_102
GTX QUAD_103
GTX QUAD_104
GTX QUAD_105
GTX QUAD_112
GTX QUAD_113
GTX QUAD_114
GTX QUAD_115
Figure 1-1: ML628 Board Block Diagram
shows the ML628 board described in this user guide. Each numbered feature
Figure 1-2
Figure 1-2 is for reference only and might not reflect the current revision of the board.
www.xilinx.com
Figure 1-1.
FMC Interface
FMC1 FMC2
(ANSI/VITA 57.1-2008 v1.1)
Virtex-6 FPGA
XC6VHX380T-2FFG1923C
User GPIO
200 MHz LVDS Clock,
Push Buttons,
Differential User SMA Clocks,
DIP Switches,
Singe-Ended User SMA Clocks
and LEDs
SuperClock-2 Module
is described in the sections that follow.
USB to UART
Bridge
System ACE
Controller
System Monitor
Interface
I 2 C Bus Management
GTX Transceiver
Power Module
GTH Transceiver
Power Module
UG771_c1_01_022211
ML628 Board User Guide
UG771 (v1.0.1) June 28, 2011
