Module Programming - Directed DB3 Installation Manual

Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Wait until the LED turns on solid red.
1
Note: To use this firmware as convenience only, you can skip the bypass by pressing the
programming button 5 times and proceed to step 3.
2
Remove the battery from the factory keyless remote.
Use the tip of the remote to press twice on the Push-to-Start (PTS) button to turn the ignition
ON ("RUN" illuminates on the button). The LED flashes green.
3
Note: If the transponder programming was skipped, the LED turns ON solid orange for
3 seconds then shuts OFF. The programming is now complete.
4
Press on the PTS button once more to turn the ignition OFF.
Once again, use the tip of the remote to press twice on the Push-to-Start (PTS) button to turn
5
the ignition ON ("RUN" illuminates on the button). The LED flashes orange slowly.
6
Press the PTS button once more to turn the ignition OFF.
Remove the module from the vehicle and reconnect it to your computer. The web site will
7
automatically recognize that you are moving onto the second phase of the programming
sequence.
8
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED turns ON solid green for
9
3 seconds, then turns OFF.
You have successfully completed the module programming sequence.
11
403.CHRYSLER3 4.32 2012 Dodge/Ram Journey (Smart Key)
