Wiring diagram with T-Harness (THCHD3 Rev. 1 & 2)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
male
Keyless Ignition Node
Connect T-Harness
(black connector
male connector
at PTS switch)
into PTS switch
Female
Male
T-01
6-pin
Connectors
(+) Ignition Input
(AC) Tach Input
(-) Hood Input
(-) Ground
(+) 12V Input
D2D Port
XKD2D65
6 403.CHRYSLER3 4.32 2012 Dodge/Ram Journey (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Not Used
Not Used
Female
Male
T-02
THCHD3 Rev. 1 & 2 (optional T-Harness)
Hood Pin
Parking Lights (MUX):
Pin 3
3
6 5 4 2
Headlight Connector
(black connector at Headlight Switch)
(+) 12V: Red
or Red/Yellow,
pin 3
Plug (B)
(black connector at BCM
in passenger kick panel)
The Remote Start Safety
Override Switch is inactive
(used for RSR only)
Do not cut the loops
For Rev. 2 ONLY
(+) Ignition Output: Yellow/Red
(AC) Tach Output: Violet/White
(MUX) Parking Light Output: Violet/Brown
1
).
OBDII
only
Diagnostic Connector
OR
Use the style of OBDll
connector that fits the best.
Do not connect
D2D
