Vehicle connections

The connection information listed below is specific to the 2012 Dodge/Ram Journey (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
9 403.CHRYSLER3 4.32 2012 Dodge/Ram Journey (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Description
No Connection
No Connection
(DATA) HS CAN High 1
(DATA) HS CAN Low 1
(DATA) HS CAN High 2
(DATA) HS CAN Low 2
Relay N.O. - No Connection
Relay COM - Immo. Data Interrupt (conn. side)
Relay N.C. - Immo. Data Interrupt (vehicle side)
Relay N.C. - No Connection
Relay COM - (+) Ignition Output
Relay N.O. - (+) 12 Volt Input
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
(-) W2W Only - E-Brake Output
No Connection
(-) W2W Only - Door Output
(-) W2W Only - Trunk Output
[2]
(AC) W2W Only - Tach Output
(+) W2W Only - Brake Output
(+) PTS Output
No Connection
(MUX) Parking Light Output
(Data) Immo. Data (vehicle side)
No Connection
(-) W2W Only - Hood Switch Input
Description
Connects To
Wire Location
No Connection
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 6
OBD-Data Link Connector, black 16 pin plug, pin 14
OBD-Data Link Connector, black 16 pin plug, pin 3
OBD-Data Link Connector, black 16 pin plug, pin 11
No Connection
Keyless Ignition Node (Start/Stop Button), black 6 pin plug, pin 5
Keyless Ignition Node (Start/Stop Button), black 6 pin plug, pin 5
No Connection
Remote Starter
BCM above passenger kick, gray 4 pin plug (B), pin 3
BCM above passenger kick, gray 4 pin plug (B), pin 3
Connects To
Wire Location
Remote Starter
No Connection
Remote Starter
Remote Starter
Remote Starter
Remote Starter
Keyless Ignition Node (Start/Stop Button), black 6 pin plug, pin 4
No Connection
headlight switch, black 6 pin plug, pin 3
Keyless Ignition Node (Start/Stop Button), black 6 pin plug, pin 5
No Connection
Remote Starter
Connects To
Wire Location
(+/-) Wire Color
Data Gray/White (CAN C)
Data Yellow (CAN C)
Data Gray (CAN IHS)
Data White (CAN IHS)
data white/lt. green (Security K Line)
data white/lt. green (Security K Line)
+ red (40A)
+ red (40A)
(chassis ground)
(+/-) Wire Color
+ violet/lt. blue
MUX white/brown
data white/lt. green (Security K Line)
(+/-) Wire Color
