Cls1000-Ai - MICRO-EPSILON optoCONTROL CLS1000 Operating Instructions Manual

Functional Principle, Technical Data
2.3.2

CLS1000-AI

Model
Operating range
Detection range
Response time
Switching frequency
Frequency response (-3 dB)
Temperature stability
Light source
Permissible ambient light
Supply voltage
1
Max. current consumption
Analog output
Switching output
Switching
Signal input
Connection
Electrical
Mounting
Storage
Temperature
range
Operation
Shock (DIN EN 60068-2-27)
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN
60529)
Material
Weight
Compatibility
Control and display elements
Special features
FSO = Full Scale Output
The specified data apply for a consistent room temperature of 22 °C, sensor is continuously in operation, open signal
outputs.
1) Residual ripple ≤ 10%
optoCONTROL CLS1000
CLS1000-
AI-NPN
NPN
FA socket M18x1 for screwable optical fiber (length 0.3 m ... 15 m, min. bending radius
Optical
4-pin M12 socket for power supply and
signals (connection cable see accesso-
DIN rail, DIN rail mounting (see accessories), mounting holes
20 g / 11 ms in 3 axes, two directions and 1000 shocks each
Parameterization/operation via membrane keypad and OLED display on controller;
up to 9 teach-in modes;
adjustable switching output functions
on-delayed and off-delayed as well as
pulse output;
adjustable hysteresis 2 ... 25 %;
CLS1000- CLS1000-
AI-PNP AI-PP
max. 2000 mm (depending on transmission sensor)
max. 1200 mm (depending on reflex sensor)
100 µs
2.5 kHz (depending on pulse/pause ratio)
10 kHz
≤ 0.1 % FSO / K
infrared LED 870 nm
50,000 lx
12 ... 30 VDC
50 mA
Switchable 0 ... 20 mA or 4 ... 20 mA
PNP PP
light/dark switching (switchable)
-
18 mm)
ries)
-10 ... +70 °C (+14 ... +158 °F)
-5 ... +55 °C (+23 ... +131 °F)
15 g / 10 ... 1000 Hz in 3 axes, 10 cycles each
Plastic housing (polycarbonate)
with all CFS sensors (FAR, FAD, FAZ and FAS)
LED for power on
CLS1000- CLS1000-
AI-NPN-T AI-PNP-T
NPN PNP
Trigger in
5-pin M12 socket for power supply and
signals (connection cable see accesso-
ries)
IP67
200 g
up to 9 teach-in modes;
adjustable switching output functions
on-delayed and off-delayed as well as
pulse output;
adjustable hysteresis 2 ... 25 %; many
trigger types
CLS1000-
AI-PP-T
PP
