SuperServer 5019C-WR User's Manual

4.5 LED Indicators

LAN LEDs
Two LAN ports (LAN 1, LAN 2) are located on the back I/O panel of the motherboard. Each
Ethernet LAN port has two LEDs. The green LED indicates activity, while the other Link LED
may be green, amber, or off to indicate the speed of the connection. Refer to the tables below
for more information.
LAN Activity LED (Right)
LED State
Color
Status
Green
Flashing
Unit ID LED
A rear UID LED indicator (LE1) is located near the UID switch on the back I/O panel. This
UID indicator provides easy identification of a system unit that may need service.
IPMI LAN LEDs
In addition to LAN1 and LAN2, an IPMI LAN is also located on the back I/O panel. The amber
LED on the right indicates activity, while the green LED on the left indicates the speed of the
connection. Refer to the table below for more information.
LAN 1/LAN 2
IPMI LAN
Link LED
IPMI LAN
(X8ST3-F)
Definition
Active
UID LED
LED Indicator
LED Color
Blue: On
Activity LED
Link (left)
Activity (Right)
LAN Link LED (Left)
LED State
LED Color
Definition
Off
No Connection/10 Mbps
Amber
1 Gbps
Green
100 Mbps
Definition
Unit Identified
IPMI LAN LEDs
Color/State
Green: Solid
Amber: Solid
Yellow: Blinking
54
Definition
100 Mbps
1Gbps
Active
