The information in this User's Manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
SuperServer
®
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
5019P-MT
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
5019P-MTR
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the manufacturer's instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. "Perchlorate Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate".
WARNING: Handling of lead solder materials used in this product may expose you to lead, a
chemical known to the State of California to cause birth defects and other reproductive harm.
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical
systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
Manual Revision 1.0
Release Date: May 05, 2017
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this
document. Information in this document is subject to change without notice. Other products and companies referred
to herein are trademarks or registered trademarks of their respective companies or mark holders.
USER'S MANUAL
Copyright © 2017 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
Revision 1.0

Advertisement

Table of Contents
loading

Summary of Contents for Supermicro SuperServer 5019P-MT

  • Page 1 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 2: Table Of Contents

    This manual is written for professional system integrators and PC technicians. It provides 1.2 Unpacking the System ......................8 information for the installation and use of the SuperServer 5019P-MT/MTR. Installation and 1.3 System Features ........................9 maintenance should be performed by experienced technicians only.
  • Page 3 SuperServer 5019P-MT/MTR User's Manual Preface 3.3 Motherboard Components ....................24 Chapter 4 Motherboard Connections Processor and Heatsink Installation ..................24 4.1 Power Connections ......................45 Overview of the Processor Socket Assembly ..............25 4.2 Headers and Connectors ....................46 Overview of the Processor Heatsink Module (PHM) ............26 4.3 Front Control Panel ......................51...
  • Page 4 SuperServer 5019P-MT/MTR User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
  • Page 5: Chapter 1 Introduction

    1.2 Unpacking the System Hard Drives Inspect the box the SuperServer 5019P-MT/MTR was shipped in and note if it was damaged Four (4) hot-swap 3.5" SATA hard drives in any way. If any equipment appears damaged, please file a damage claim with the carrier Power who delivered it.
  • Page 6: Server Chassis Features

    SuperServer 5019P-MT/MTR User's Manual Chapter 1: Introduction 1.4 Server Chassis Features Front Features The SC813MFTQC-350B/R407CB is a mini 1U chassis See the illustration below for the features included on the front of the chassis. Control Panel The switches and LEDs located on the control panel are described below. See Chapter 4 for details on the control panel connections.
  • Page 7: Rear Features

    SuperServer 5019P-MT/MTR User's Manual Chapter 1: Introduction Rear Features 1.5 Motherboard Layout The illustration below shows the features included on the rear of the chassis. Below is a layout of the X11SPi-TF with jumper, connector and LED locations shown. See the table on the following page for descriptions.
  • Page 8: Quick Reference Table

    SuperServer 5019P-MT/MTR User's Manual Chapter 1: Introduction Notes: Connector Description JPWR2 24-pin ATX Power Connector • See Chapter 2 for detailed information on jumpers, I/O ports, and JF1 front panel connec- JRK1 Intel RAID Key Header tions. JSD1/JSD2 SATA DOM Power Connectors...
  • Page 9 SuperServer 5019P-MT/MTR User's Manual VCCP0 12v VR13 #F-1 5+1 PHASE #C-1 #E-1 145W #B-1 #D-2 #A-2 #D-1 #A-1 VCCP0 SOCKET ID:0 SNB CORE DDR-IV PECI:30 SLOT 2 #3B #3A #1B DMI3 PCI-E X8 G3 PCI-E X16 G3(X8 option) SLOT 3...
  • Page 10: Chapter 2 Server Installation

    SuperServer 5019P-MT/MTR User's Manual Chapter 2: Server Installation Chapter 2 • Always make sure the rack is stable before extending a server or other component from the rack. • You should extend only one server or component at a time - extending two or more simul- Server Installation taneously may cause the rack to become unstable.
  • Page 11: Circuit Overloading

    SuperServer 5019P-MT/MTR User's Manual Chapter 2: Server Installation 2.3 Installing the Rails Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry There are a variety of rack units on the market, which may require a slightly different assembly and the effect that any possible overloading of circuits might have on overcurrent protection procedure.
  • Page 12: Installing The Server Into A Rack

    Installing the Server into a Telco Rack To install the SuperServer 5019P-MT/MTR into a Telco (or “open”) type rack, use two L-shaped You should now have rails attached to both the chassis and the rack. The next step is to brackets on either side of the chassis (four total).
  • Page 13: Chapter 3 Maintenance And Component Installation

    (If your system has more than one power supply, remove the AC power cords from all power supply modules.) • Refer to the Supermicro website for updates on CPU support. 3. Disconnect the power cord(s) from the power supply modules. •...
  • Page 14: Overview Of The Processor Socket Assembly

    SuperServer 5019P-MT/MTR User's Manual Chapter 3: Maintenance and Component Installation Overview of the Processor Heatsink Module (PHM) Overview of the Processor Socket Assembly The processor socket assembly contains 1) the Intel SKX processor, 2) the processor clip, The Processor Heatsink Module (PHM) contains 1) a heatsink, 2) a processor clip, and 3) 3) the dust cover, and 4) the CPU socket.
  • Page 15 SuperServer 5019P-MT/MTR User's Manual Chapter 3: Maintenance and Component Installation Attaching the Non-F Model Processor to the Processor Clip to Attaching the Non-F Model Processor Carrier Assembly to the Create the Processor Carrier Assembly Heatsink to Form the Processor Heatsink Module (PHM) To properly install the CPU into the processor clip, please follow the steps below.
  • Page 16 Small Guiding Post Figure 3-2. Removing the Dust Cover from the CPU Socket Printed Triangle Note: Visit the product page on the Supermicro website for possible updates to memory Mounting the Processor Heatsink Module Tighten the screws in the support (www.supermicro.com).
  • Page 17 Removing the Processor Heatsink Module (PHM) from the Memory Support and Installation Motherboard Note: Check the Supermicro website for recommended memory modules. Before removing the processor heatsink module (PHM), unplug power cord from the power Important: Exercise extreme care when installing or removing DIMM modules to prevent outlet.
  • Page 18 SuperServer 5019P-MT/MTR User's Manual Chapter 3: Maintenance and Component Installation DIMM Module Population Sequence DIMM Installation COM1 FAN5 ASpeed USB6/7(3.0) 1. Insert the desired number of DIMMs into When installing memory modules, the DIMM slots should be populated in the following order:...
  • Page 19 SuperServer 5019P-MT/MTR User's Manual Chapter 3: Maintenance and Component Installation PCI Expansion Card Installation 3.4 Chassis Components The system includes one pre-installed riser card: RSC-RR1U-E16, for a standard size PCI-E x16 card. Riser cards position the expansion cards at a 90 degree angle, allowing them to Front Bezel fit inside the 1U chassis.
  • Page 20 SuperServer 5019P-MT/MTR User's Manual Chapter 3: Maintenance and Component Installation Motherboard Battery Hard Drives The motherboard uses non-volatile memory to retain system information when system power Your server may or may not have come with hard drives installed. Up to four 3.5" hard drives is removed.
  • Page 21 State/Condition Indication Green Blinking Drive activity Blinking Drive rebuilding Solid on Drive failure Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at http://www. supermicro.com/products/nfo/files/storage/SBB-HDDCompList.pdf...
  • Page 22 SuperServer 5019P-MT/MTR User's Manual Chapter 3: Maintenance and Component Installation System Cooling Four 4-cm fans provide the cooling for the system. The chassis provides two additional open fan housings, where an additional system fan may be added for optimal cooling.
  • Page 23 Power Supply: 5019P-MT Removing the Power Supply The SuperServer 5019P-MT has a single 350 Watts high-efficiency power supply. The power You do not need to shut down the system to replace a power supply module. The redundant supply module has an auto-switching capability, which enables them to automatically sense feature will keep the system up and running while you replace the failed hot-swap module.
  • Page 24 Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A severboard layout indicating component locations may be found in Appendix B.
  • Page 25: Headers And Connectors

    SuperServer 5019P-MT/MTR User's Manual Chapter 4: Motherboard Connections Processor Power Connector Disk-On-Module Power Connector JPWR1 is an 8-pin 12V DC power input for the CPU that must be connected to the power Two power connectors for SATA DOM (Disk-On-Module) devices are located at JSD1 and supply.
  • Page 26 PCH RAID KEY NVMe I C Header Connector JNVI C1 is a management header for the Supermicro AOC NVMe PCI-E peripheral cards. Please connect the I C cable to this connector. VRM SMBus Header JVRM1 is a voltage regulator module (VRM) SMBus header. Use this header to program the...
  • Page 27: Front Control Panel

    S-SATA ports (S-SATA0/S-SATA1) that include SATA DOM power. SATA ports with Supermicro chassis. See the figure below for the descriptions of the front control panel provide serial-link signal connections, which are faster than the connections of Parallel ATA.
  • Page 28 SuperServer 5019P-MT/MTR User's Manual Chapter 4: Motherboard Connections Power Fail LED Power LED The Power Fail LED connection is located on pins 5 and 6 of JF1. Refer to the table below The Power LED connection is located on pins 15 and 16 of JF1. Refer to the table below for pin definitions.
  • Page 29: Ports

    SuperServer 5019P-MT/MTR User's Manual Chapter 4: Motherboard Connections 4.4 Ports Universal Serial Bus (USB) Ports There are two USB 2.0 ports (USB0/1) and two USB 3.0 ports (USB6/7) located on the I/O Rear I/O Ports back panel. The motherboard also has two front access USB 2.0 headers (USB2/3 and USB4/5) and one front access USB 3.0 header (USB8/9).
  • Page 30: Explanation Of Jumpers

    SuperServer 5019P-MT/MTR User's Manual Chapter 4: Motherboard Connections 4.5 Jumpers Unit Identifier Switch/UID LED Indicator A Unit Identifier (UID) switch and an LED Indicator are located on the motherboard. The UID switch is located at UID SW, which is next to the VGA port on the back panel. The UID LED Explanation of Jumpers is located next to the UID switch.
  • Page 31: Led Indicators

    SuperServer 5019P-MT/MTR User's Manual Chapter 4: Motherboard Connections 4.6 LED Indicators Watch Dog Watch Dog (JWD1) is a system monitor that can reboot the system when a software application hangs. Close pins 1-2 to reset the system if an application hangs. Close pins 2-3 LAN LEDs to generate a non-maskable interrupt (NMI) signal for the application that hangs.
  • Page 32 SuperServer 5019P-MT/MTR User's Manual Onboard Power LED The Onboard Power LED is located at LEDPWR on the motherboard. When this LED is on, the system is on. Be sure to turn off the system and unplug the power cord before removing or installing components.
  • Page 33: Chapter 5 Software

    You must first configure RAID settings (if using RAID) before you install the Windows OS and the software drivers. To configure RAID settings, please refer to the RAID Configuration User Guides posted on our website at www.supermicro.com/support/manuals. Installing the Windows OS for a RAID System 1.
  • Page 34: Driver Installation

    The Supermicro FTP site contains drivers and utilities for your system at ftp://ftp.supermicro. The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based com. Some of these must be installed, such as the chipset driver. interface for Windows and Linux operating systems. The program monitors such system health...
  • Page 35: Ipmi

    SuperServer 5019P-MT/MTR User's Manual 5.4 IPMI The X11SPi-TF support the Inteliigent Platform Management Interface (IPMI). IPMI is used to provide remote access, monitoring and management. There are several BIOS settings that are related to IPMI. For general documentation and information on IPMI, please visit our website at:...
  • Page 36: Chapter 6 Bios

    Chapter 4: BIOS Chapter 6 BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.
  • Page 37: Main Setup

    SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS 6.2 Main Setup Memory Information Total Memory This item displays the total size of memory available in the system. 6.3 Advanced Setup Configurations When you first enter the AMI BIOS setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen.
  • Page 38 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS Bootup NumLock State Power Button Function Use this feature to set the Power-on state for the <Numlock> key. The options are On and Off. This feature controls how the system shuts down when the power button is pressed. Select 4 Seconds Override for the user to power off the system after pressing and holding the power Wait For "F1"...
  • Page 39 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS Intel Virtualization Technology Advanced Power Management Configuration Use feature to enable the Vanderpool Technology. This technology allows the system to run several operating systems simultaneously. The options are Disable and Enable.  CPU P State Control...
  • Page 40 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS Chipset Configuration  CPU C State Control  Warning: Setting the wrong values in the following features may cause the system to malfunc- Autonomous Core C-State tion. Enabling this setting allows the hardware to autonomously choose to enter a C-state based on power consumption and clock speed.
  • Page 41 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS IO Directory Cache (IODC)  Memory Topology IO Directory Cache is an 8-entry cache which stores the directory state of remote IIO This item displays the information of onboard memory modules as detected by the writes and memory lookups, and saves directory updates.
  • Page 42 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS Patrol Scrub  CPU SLOT2 PCI-E 3.0 X8 / CPU SLOT6 PCI-E X16 / CPU SLOT4 PCI-E X16 / CPU SLOT3 PCI-E X8 Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors...
  • Page 43 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS  Intel® VT for Directed I/O (VT-d)  Intel® VMD Technology Intel ® VT for Directed I/O (VT-d)  Intel® VMD for Volume Management Device on CPU Select Enable to use Intel Virtualization Technology for Direct I/O VT-d support by...
  • Page 44 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS XHCI Hand-off VMD Config for PStack2 When disabled, the motherboard will not support USB 3.0. The options are Enabled and Intel® VMD for Volume Management Device Disabled. Select Enable to use the Intel Volume Management Device Technology for this stack.
  • Page 45 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS Aggressive Link Power Management Configure sSATA as When this item is set to Enable, the SATA AHCI controller manages the power usage of the Select AHCI to configure an sSATA drive specified by the user as an AHCI drive. Select RAID SATA link.
  • Page 46 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS PCIe/PCI/PnP Configuration VGA Priority  Use this feature to select VGA priority when multiple VGA devices are detected. Select On- The following information will display: board to give priority to your onboard video device. Select Offboard to give priority to your •...
  • Page 47 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS Network Stack Configuration Change Settings This feature specifies the base I/O port address and the Interrupt Request address of a Network Stack serial port specified by the user. Select Auto to allow the BIOS to automatically assign the base I/O and IRQ address.
  • Page 48 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS COM1 Console Redirection Settings COM1 Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages Use this feature to specify how the host computer will exchange data with the client to a remote server.
  • Page 49 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS COM2 Bits Per second COM2 Putty KeyPad Use this feature to set the transmission speed for a serial port used in Console Redirection. This feature selects Function Keys and KeyPad settings for Putty, which is a terminal Make sure that the same speed is used in the host computer and the client computer.
  • Page 50 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS iSCSI Configuration Bits Per Second  This item sets the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower iSCSI Initiator Name transmission speed may be required for long and busy lines.
  • Page 51 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS 6.4 Event Logs MECI The Multiple Event Count Increment (MECI) counter counts the number of occurences that a duplicate event must happen before the MECI counter is incremented. This is a numeric value. The default value is 1.
  • Page 52 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS 6.5 IPMI Note: After making changes on a setting, be sure to reboot the system for the changes to take effect. BMC Network Configuration  BMC Network Configuration Configure IPV4 Support This section displays configuration features for IPV4 support.
  • Page 53 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS 6.6 Security VLAN This item displays the virtual LAN settings. The options are Disable and Enable. Configure IPV6 Support This section displays configuration features for IPV6 support. LAN Channel 1 IPV6 Support Use this feature to enable IPV6 support. The options are Enabled and Disabled.
  • Page 54 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS Secure Boot Mode  Key Exchange Keys Use this item to configure Secure Boot variables without authentication. The options are Set New Standard and Custom. Select Yes to load the KEK from the manufacturer's defaults. Select No to load the KEK CSM Support from a file.
  • Page 55 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS 6.7 Boot Append Select Yes to add the DBT from the manufacturer's defaults list to the existing DBT. Select No to load the DBT from a file. The options are Yes and No.
  • Page 56 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS • Legacy/UEFI/Dual Boot Option #7 UEFI Application Boot Priorities  • Legacy/UEFI/Dual Boot Option #8 This feature sets the system boot order of detected devices. • Boot Option #1 • UEFI/Dual Boot Option #9 •...
  • Page 57 SuperServer 5019P-MT/MTR User's Manual Chapter 4: BIOS 6.8 Save & Exit Restore Defaults To set this feature, select Restore Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance.
  • Page 58 SuperServer 5019P-MT/MTR User's Manual Appendix A BIOS Error Codes A-1 BIOS Error Beep (POST) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 59 Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de Read this appendix in its entirety before installing or configuring components in the Supermicro manipular cualquier equipo, considere los riesgos de la corriente eléctrica y familiarícese chassis.
  • Page 60 SuperServer 5019P-MT/MTR User's Manual Appendix B: Standardized Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ Warnung ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 61 SuperServer 5019P-MT/MTR User's Manual Appendix B: Standardized Warning Statements Power Disconnection Warning Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Warning! The system must be disconnected from all sources of power and the power Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung cord removed from the power supply module(s) before accessing the chassis interior nicht mehr als: 250 V, 20 A beträgt.
  • Page 62 SuperServer 5019P-MT/MTR User's Manual Appendix B: Standardized Warning Statements ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ Attention ‫انطاقت قبم‬ Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à...
  • Page 63 SuperServer 5019P-MT/MTR User's Manual Appendix B: Standardized Warning Statements Battery Handling Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace sonstigen Sicherheitsvorkehrung möglich.
  • Page 64 SuperServer 5019P-MT/MTR User's Manual Appendix B: Standardized Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ¡Advertencia! ‫اسحبذال البطارية‬ Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones.
  • Page 65 SuperServer 5019P-MT/MTR User's Manual Appendix B: Standardized Warning Statements Backplane Voltage ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ Warning! Hazardous voltage or energy is present on the backplane when the system is operating.
  • Page 66 SuperServer 5019P-MT/MTR User's Manual Appendix B: Standardized Warning Statements ‫תיאום חוקי החשמל הארצי‬ Attention !‫אזהרה‬ La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬...
  • Page 67 UL or CSA -certified cables (that have UL/CSA shown on the ¡Advertencia! code) for any other electrical devices than products designated by Supermicro only. Riesgo de piezas móviles. Mantener alejado de las aspas del ventilador. Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.
  • Page 68 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 69: Hard Drives

    Appendix C: System Specifications Appendix C System Specifications Processors Single Intel Xeon 81xx/61xx/51xx/41xx/31xx processor in an Socket P0-LGA3647 Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset Intel PCH C622 chipset BIOS 128 Mb AMI®...
  • Page 70 SuperServer 5019P-MT/MTR User's Manual Regulatory Compliance Electromagnetic Emissions: FCC Class B, EN 55022 Class B, EN 61000-3-2/3-3, CISPR 22 Class B Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11)
  • Page 71: Appendix D Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 72 Appendix D: UEFI BIOS Recovery SuperServer 5019P-MT/MTR User's Manual minutes to locate the SUPER.ROM file if the media size becomes too large because it contains Warning: Please stop pressing the <Ctrl> and <Home> keys immediately when you see the too many folders and files.
  • Page 73 SuperServer 5019P-MT/MTR User's Manual Note: Do not interrupt the BIOS flashing process until it has completed. 6. After the BIOS recovery process has completed, press any key to reboot the system. 7. Using a different system, extract the BIOS package into a bootable USB flash drive.

This manual is also suitable for:
