NIC1/NIC2 (LAN1/LAN2)
The Network Interface Controller (NIC) LED connection for LAN port 1 is located on pins
11 and 12 of JF1, and LAN port 2 is on pins 9 and 10. Attach the NIC LED cables here to
display network activity. Refer to the table below for pin definitions.
HDD LED/UID Switch
The HDD LED/UID Switch connection is located on pins 13 and 14 of JF1. Attach a cable
to pin 14 to show hard drive activity status. Attach a cable to pin 13 to use the UID switch.
Refer to the table below for pin definitions.
Power LED
The Power LED connection is located on pins 15 and 16 of JF1. Refer to the table below
for pin definitions.
NMI Button
The non-maskable interrupt (NMI) button header is located on pins 19 and 20 of JF1. Refer
to the table below for pin definitions.
LAN1/LAN2 LED
Pin Definitions (JF1)
Pins Definition
9 VCC
10 NIC2 Link/Active LED
11 VCC
12 NIC1 Link/Active LED
HDD LED/UID Switch
Pin Definitions (JF1)
Pin# Definition
13 3.3V Stdby/UID SW
14 HDD Active
Power LED
Pin Definitions (JF1)
Pin# Definition
15 3.3V
16 PWR LED
NMI Button
Pin Definitions (JF1)
Pin# Definition
19 Control
20 GND
