Front Features

The 5019C-WR is a 1U system. See the illustration below for the features included on the
front of the chassis.
1
5
Item Feature
1 Hard Drive Carrier
Slim FDD Bay/USB/COM
2
Port Tray
3 Slim DVD ROM Drive
4 Control Panel
5 Rack Ear Brackets
3
1
Figure 1-2. Chassis Front View
Front Chassis Features
Description
Carrier for hot-swap hard drive
Slim Fixed Disk Drive/USB/COM port tray (Optional)
Slim DVD-ROM drive (Optional)
Front control panel with LEDs and buttons (see preceding page)
Secures the server chassis to the rack
