SuperServer 5019C-WR User's Manual
TPM/Port 80 Header
A Trusted Platform Module (TPM)/Port 80 header is located at JTPM1 to provide TPM support
and Port 80 connection. Use this header to enhance system performance and data security.
Refer to the table below for pin definitions. Please go to the following link for more information
on the TPM: http://www.supermicro.com/manuals/other/TPM.pdf.
Standby Power
The Standby Power header is located at JSTBY1 on the motherboard. You must have a card
with a Standby Power connector and a cable to use this feature. Refer to the table below
for pin definitions.
Chassis Intrusion
A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable
from the chassis to inform you of a chassis intrusion when the chassis is opened. Refer to
the table below for pin definitions.
Trusted Platform Module Header
Pin Definitions
Pin# Definition Pin#
1 +3.3V 2
3 RESET# 4
5 SPI_CLK 6
7 SPI_MOSI 8
9 +3.3V Stdby 10
Standby Power
Pin Definitions
Pin# Definition
1 +5V Standby
2 GND
3 NC
Chassis Intrusion
Pin Definitions
Pin# Definition
1 Intrusion Input
2 GND
42
Definition
SPI_CS#
SPI_MISO
GND
NC
SPI_IRQ#
