Chapter 2 To Set the Vertical System

Chapter 2 To Set the Vertical System
MSO7000/DS7000 series provides four analog input channels (CH1-CH4), and each
channel is equipped with an independent vertical control system. The setting
methods for the vertical systems of the four channels are the same. This chapter
takes CH1 as an example to introduce the setting method for the vertical system. For
this oscilloscope, only CH1 is enabled by default.
Contents in this chapter:
To Enable or Disable the Analog Channel
◼
To Adjust the Vertical Scale
◼
Vertical Expansion
◼
To Adjust the Vertical Offset
◼
Channel Coupling
◼
Bandwidth Limit
◼
Probe Ratio
◼
Input Impedance
◼
Waveform Invert
◼
To Set the Probe
◼
Amplitude Unit
◼
Channel Delay
◼
Offset Cal
◼
Channel Label
◼
