48
TURN THE CONTROL BOX OFF
STEP 13. Attach front mount bracket to the operator. The gate must remain in the desired closed
position.
CLOSE THE GATE TO THE DESIRED CLOSED POSITION
A . Temporarily assemble the front mount of the gate by inserting the supplied 10mm x 40mm clevis pin, 10mm
I.D. nylon spacer, and clevis hairpin through the gate bracket.
NOTE
ALTERNATE TUBE GATE BRACKETS FOR MOUNTING TUBULAR GATES. (NOT FOR USE WITH FLAT PANEL
GATES) see below image. Tube brackets (AXTB) sold separately.
© G h o s t C o n t r o l s
®
2 0 2 0
