TURN CONTROL BOX ON. YOU SHOULD HEAR A SERIES OF BEEPS AS THE SYSTEM
IS TURNED ON
STEP 11. Locate the jog buttons at the top right of control box and press the job open button to test
the arm and connections.
STEP 12. Use the remote transmitter to fully retract the arm. The arm will stop on its own. The arm
in the fully retracted position will determine the CLOSED position of the gate.
NOTE
The arm has an internal limit switch that is fixed and is not adjustable.
WARNING
DO NOT SCREW THE OPERATOR ARM IN OR OUT TO ADJUST YOUR GATE POSITION. DOING SO
CAUSES THE SYSTEM TO NOT FUNCTION PROPERLY.
ARM EXTENDED
OUT 3-4 INCHES
ARM FULLY
RETRACTED
