PULL TO OPEN INSTALLATION
OPERATOR ARM INSTALLATION PERAT A OR ARM INSTAL AT
The dimensions and step-by-step instructions that follow are for mounting the GHOST CONTROLS sions and step-by-step instructions that fo fo f llow are fo fo f r mount
a installation system to a decorative metal gate that swings into property.
STEP 1. Establish and mark the horizontal center lines of the gate and the post for proper
alignment of gate brackets.
T TAL LATIO A ATIO N
NOTE
Wheels cannot be used with
any Ghost Controls gate
®
opener system!
For gates weighing over 200
lbs. ball bearing hinges are
recommended.
Operator is not for use on
solid panel privacy gates.
RTY
Gate Operator in
®
NOTE
This center point will be used
for mounting the post bracket
in STEP 4.
