Display assembly

NOTE:
All display assembly spare part kits include 2 microphones, 2 speakers, and 2 WLAN antenna
transceivers and cables.
Description
For use in model 2133:
8.9-inch, WXGA display assembly for use only with computer models equipped with camera module 483384-001
8.9-inch, WXGA display assembly for use only with computer models not equipped with camera
module
8.9-inch, WSVGA display assembly for use only with computer models equipped with camera
module and system boards with the following spare part numbers: 498308-001, 500754-001, and
500755-001
8.9-inch, WSVGA display assembly for use only with computer models not equipped with camera
module and system boards with the following spare part numbers: 498308-001, 500754-001, and
500755-001
For use in model 2140:
10.1-inch, WXGA display assembly for use only with SD computer models equipped with camera
module
10.1-inch, WXGA display assembly for use only with HD computer models equipped with camera
module
Before removing the display assembly, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
5.
Remove the following components:
a.
Keyboard (see
b.
Hard drive or solid-state drive (see
c.
Top cover (see
d.
Audio board (see
e.
System board (see
6.
Disconnect the wireless antenna cables from the WLAN module (see
Battery on page
44).
Keyboard on page
45)
Mass storage device on page
Top cover on page
52)
Audio board (Model 2133 only) on page
System board on page
49)
55)
59)
WLAN module on page
Component replacement procedures
Spare part number
482278-001
498309-001
502600-001
511743-001
511744-001
63).
71
