Right-side components

Item
(1)
(2)
(3)
(4)
(5)
(6)
(7)
Component
ExpressCard slot
SD Card Reader
USB port
RJ-45 (network) jack
Battery light
Power connector
Security cable slot
Function
Supports optional ExpressCards 54.
Supports the following optional digital card formats:
● Secure Digital (SD) Memory Card
●
MultiMediaCard (MMC)
Connects an optional USB device.
Connects a network cable.
●
Amber: A battery is charging.
●
Blue: A battery is close to full charge capacity.
● Blinking amber: A battery that is the only available
power source has reached a low battery level.
●
If the computer is plugged into an external power
source, the light turns off when all batteries in the
computer are fully charged. If the computer is not
plugged into an external power source, the light stays
off until the battery reaches a low battery level.
Connects an AC adapter.
Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being
mishandled or stolen.
Model 2133 9
