Spare part
number
459263-002
463958-001
468824-001
482262-001
482263-001
482264-001
482265-001
482266-001
482267-001
482268-001
482269-001
482271-001
482272-001
482274-001
482275-001
482276-001
482277-001
482278-001
482279-001
32
Chapter 3 Illustrated parts catalog
Description
Broadcom BCM4312 802.11b/g WLAN module for use in Afghanistan, Albania, Algeria, Andorra, Angola,
Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain,
Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina,
Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde,
the Central African Republic, Chad, Chile, the People's Republic of China, Colombia, Comoros, the Congo,
Costa Rica, Croatia, Cyprus, the Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic,
East Timor, Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland, France,
French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece, Grenada, Guadeloupe,
Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti, Honduras, Hong Kong, Hungary, Iceland, India, Ireland,
Israel, Italy, the Ivory Coast, Jamaica, Jordan, Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon,
Lesotho, Liberia, Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia,
the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia,
Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles,
the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama,
Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal, the Republic of Moldova, Romania,
Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles,
Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain,
Sri Lanka, St. Kitts and Nevis, St. Lucia, St. Vincent and the Grenadines, Suriname, Swaziland, Sweden,
Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan,
Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu,
Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe
65-W HP Smart AC adapter
RTC battery for use only in model 2133
3-cell, 28-Wh Li-ion battery for use only in model 2133
6-cell, 55-Wh Li-ion battery for use only in model 2133
Base enclosure for use only in model 2133 (includes 4 rubber feet)
Top cover for use only in model 2133 (includes power on switch board and cable, TouchPad board and cable,
and wireless on/off switch board and cable)
Bracket Kit for use only in model 2133 (see
information)
120-GB, 5400-rpm hard drive for use in model 2133 (includes bracket and SATA connector)
120-GB, 7200-rpm hard drive for use in model 2133 (includes bracket and SATA connector)
160-GB, 5400-rpm hard drive for use in model 2133 (includes bracket and SATA connector)
160-GB, 7200-rpm hard drive for use in model 2133 (includes bracket and SATA connector)
4-GB solid-state drive for use in model 2133 (includes bracket and SATA connector)
Audio board for use only in computer models with WXGA displays
System board equipped with 1.0-GHz processor and only for use with WXGA displays in model 2133 (includes
ExpressCard assembly, fan/heat sink, processor, RTC battery, and replacement thermal material)
System board equipped with 1.2-GHz processor and only for use with WXGA displays in model 2133 (includes
ExpressCard assembly, fan/heat sink, processor, RTC battery, and replacement thermal material)
System board equipped with 1.6-GHz processor and only for use with WXGA displays in model 2133 (includes
ExpressCard assembly, fan/heat sink, processor, RTC battery, and replacement thermal material)
8.9-inch, WXGA display assembly for use only with 2133 computer models not equipped camera module
(includes 2 microphones, 2 speakers, and 2 WLAN antenna transceivers and cables)
Fan/heat sink for use only in model 2133 (includes replacement thermal material)
Bracket Kit on page 28
for more Bracket Kit spare part number
