HP 2133 Mini-Note Maintenance And Service Manual

Hp 2133 mini-note: specifications.
Hide thumbs
HP 2133 Mini-Note PC
Maintenance and Service Guide

Advertising

   Related Manuals for HP 2133 Mini-Note

   Summary of Contents for HP 2133 Mini-Note

  • Page 1

    HP 2133 Mini-Note PC Maintenance and Service Guide...

  • Page 2

    Corporation. SD Logo is a trademark of its proprietor. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.

  • Page 3

    Safety warning notice WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow.

  • Page 4

    Safety warning notice...

  • Page 5: Table Of Contents

    Table of contents 1 Product description 2 External component identification Top components ... 4 Display ... 4 Keys ... 5 TouchPad ... 6 Front components ... 7 Right-side components ... 8 Left-side components ... 9 Bottom components ... 10 Wireless antennae (select models only) ... 11 3 Illustrated parts catalog Serial number location ...

  • Page 6: Table Of Contents

    Component replacement procedures ... 30 Serial number ... 30 Computer feet ... 31 Battery ... 32 Keyboard ... 33 Memory module ... 36 Mass storage device ... 37 Top cover ... 39 Audio board ... 41 Bluetooth module ... 43 System board ...

  • Page 7: Table Of Contents

    8 Backup and recovery Backup and recovery in Windows Vista ... 79 Overview ... 79 Backing up ... 79 Performing a recovery ... 80 Backup and recovery in Windows XP ... 82 Backing up your information ... 82 Backup and recovery in SUSE Linux Enterprise Desktop ... 85 Performing a recovery ...

  • Page 8

    viii...

  • Page 9: Product Description

    Product description Category Description Product Name HP 2133 Mini-Note PC Processors VIA Technology C7-M Ultra Low Voltage (ULV) processors ● ● ● Chipset Northbridge: VIA CN896 Southbridge: VIA 8237s Graphics VIA Universal Memory Architecture (UMA) graphics subsystem Panels All display assemblies include 2 microphones, 2 speakers, and 2 WLAN antenna transceivers and cables ●...

  • Page 10

    Category Description 80-GB solid state drive Supports 9.5-mm (2.5-inch) SATA 4-GB flash storage drive Optical drive Supports external USB optical drive only Diskette drive Supports external USB diskette drive only Audio HD audio - AD1984 Stereo speakers (2) Intergrated stereo microphones (2) Webcam Optional integrated VGA webcam Modem...

  • Page 11

    65-W AC adapter with localized cable plug support (3-wire plug, supports 2-pin DC connector) requirements 6-cell, 55-Wh Li-ion battery 3-cell, 28-Wh Li-ion battery Security Supports Kensington security lock HP 3D DriveGuard Operating Preinstalled: system Windows Vista® Basic 32 with Office 2007 Ready Windows Vista Business 32 with Office 2007 Ready Windows®...

  • Page 12: Top Components, Display

    External component identification Top components Display Item Component Speakers (2) Wireless antennae (2) Internal microphones (2) Webcam (select models only) Chapter 2 External component identification Function Produce sound. Send and receive signals from one or more wireless devices. NOTE: The antennae are not visible from the outside of the computer.

  • Page 13: Keys

    Item Component Keys Item Component Windows logo key Windows applications key Embedded numeric keypad keys Function keys Function ● Captures single frame or burst webcam snapshots. ● Connects to e-mail photos and video. Function Displays system information when pressed in combination with the key.

  • Page 14: Touchpad

    TouchPad Item Component TouchPad on/off button Left TouchPad button* TouchPad* TouchPad scroll zone Right TouchPad button* *This table describes factory settings. To view or change pointing device preferences, select Start > Control Panel > Hardware and Sound > Mouse. Chapter 2 External component identification Function Enables/disables the TouchPad.

  • Page 15: Front Components

    Options. Blinking: The hard drive is being accessed. ● Blue: An integrated wireless device, such as a wireless local area network (WLAN) device, the HP Broadband Wireless Module, and/or a Bluetooth® device, is on. ● Amber: All wireless devices are off.

  • Page 16: Right-side Components

    Right-side components Item Component ExpressCard slot SD Card Reader USB port RJ-45 (network) jack Battery light Power connector Security cable slot Chapter 2 External component identification Function Supports optional ExpressCards 54. Supports the following optional digital card formats: ● Secure Digital (SD) Memory Card ●...

  • Page 17: Left-side Components

    Left-side components Item Component External monitor port Vent Powered USB port Audio-in (microphone) jack Audio-out (headphone) jack Function Connects an external VGA monitor or projector. Enables airflow to cool internal components. NOTE: The computer fan starts up automatically to cool internal components and prevent overheating.

  • Page 18: Bottom Components

    Bottom components Item Component Battery release latches (2) Battery bay Service tag Vents (3) Chapter 2 External component identification Function Release the battery from the battery bay. Holds the battery. Provides the product brand and series name, serial number (s/n), and product number (p/n) of your computer. Have this information available when you contact technical support.

  • Page 19: Wireless Antennae (select Models Only)

    Wireless antennae (select models only) On select computer models, at least 2 antennae send and receive signals from one or more wireless devices. These antennae are not visible from the outside of the computer. NOTE: For optimal transmission, keep the areas immediately around the antennae free from obstructions.

  • Page 20: Illustrated Parts Catalog Serial Number Location

    Illustrated parts catalog Serial number location When ordering parts or requesting information, provide the computer serial number and model number located on the bottom of the computer. Chapter 3 Illustrated parts catalog...

  • Page 21: Computer Major Components

    Computer major components Item Description 8.9-inch, WXGA display assemblies (include 2 microphones, 2 speakers, and 2 WLAN antenna transceivers and cables) For use only with computer models equipped with camera module For use only with computer models not equipped camera module Spare part number 483384-001 482278-001...

  • Page 22

    Item Description 8.9-inch, WSVGA display assemblies (include 2 microphones, 2 speakers, and 2 WLAN antenna transceivers and cables) For use only with computer models equipped with camera module and system boards with the following spare part numbers: 498308-001, 500754-001, and 500755-001 For use only with computer models not equipped with camera module and system boards with the following spare part numbers: 498308-001, 500754-001, and 500755-001 Keyboards...

  • Page 23

    Item Description Memory modules (PC2-5300, 667-MHz, DDR2) 2048-MB 1024-MB 512-MB Mass storage devices Hard drives (include bracket and SATA connector) 160-GB, 7200-rpm 160-GB, 5400-rpm 120-GB, 7200-rpm 120-GB, 5400-rpm 80-GB solid-state drive (includes bracket and SATA connector) 4-GB solid-state drive (includes bracket and SATA connector) Top cover (includes power on switch board and cable, TouchPad board and cable, and wireless on/off switch board and cable) Audio board...

  • Page 24

    Item Description Equipped with 1.0-GHz processor and only for use with WXGA displays Equipped with 1.6-GHz processor Equipped with 1.2-GHz processor Equipped with 1.0-GHz processor (12) RTC battery (13) WLAN modules Broadcom 4311AG 802.11a/b/g WLAN modules: ● For use in Canada, the Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and the United States ●...

  • Page 25

    Item Description Macedonia, Madagascar, Malawi, Malaysia, the Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico, Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru, Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria, Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, Peru, the Philippines, Poland, Portugal, the Republic of Moldova, Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia, Senegal, Serbia, the Seychelles, Sierra Leone, Singapore, Slovakia, Slovenia, the Solomon Islands, Somalia,...

  • Page 26: Bracket Kit

    Bracket Kit Item Description Bracket Kit: ExpressCard assembly bracket USB/RJ-45 connector bracket Audio/USB connector bracket Chapter 3 Illustrated parts catalog Spare part number 482266-001...

  • Page 27: Plastics/cable Kit, Miscellaneous Parts

    ExpressCard slot bezel SD Card slot bezel Bluetooth module cable Miscellaneous parts Description 65-W HP Smart AC adapter Power cords: For use in Australia For use in Brazil For use in Denmark For use in Europe, the Middle East, and Africa...

  • Page 28: Sequential Part Number Listing

    Description For use the United States Screw Kit ● Phillips PM2.0×3.0 screw ● Torx8 T8M2.5×10.0 screw ● Torx8 T8M2.5×5.0 screw ● Torx8 T8M2.0×6.0 screw ● Torx8 T8M2.0×4.0 screw Sequential part number listing Spare part Description number 246959-001 Power cord for use in the United States 246959-011 Power cord for use in Australia and New Zealand 246959-021...

  • Page 29

    Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey, Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe 463958-001 65-W HP Smart AC adapter 482262-001 3-cell, 28-Wh Li-ion battery 482263-001...

  • Page 30

    Spare part Description number 482266-001 Bracket Kit (see 482267-001 120-GB, 5400-rpm hard drive (includes bracket and SATA connector) 482268-001 120-GB, 7200-rpm hard drive (includes bracket and SATA connector) 482269-001 160-GB, 5400-rpm hard drive (includes bracket and SATA connector) 482271-001 160-GB, 7200-rpm hard drive (includes bracket and SATA connector) 482272-001 4-GB solid-state drive (includes bracket and SATA connector) 482274-001...

  • Page 31

    Spare part Description number 482280-291 Keyboard for use in Japan 482280-AB1 Keyboard for use in Taiwan 482280-AD1 Keyboard for use in South Korea 482280-B31 Keyboard for use internationally 482280-B71 Keyboard for use in Sweden and Finland 482280-BA1 Keyboard for use in Slovenia 482280-BB1 Keyboard for use in Israel 482280-BG1...

  • Page 32: Removal And Replacement Procedures Preliminary Replacement Requirements, Tools Required, Service Considerations, Plastic Parts

    Removal and replacement procedures Preliminary replacement requirements Tools required You will need the following tools to complete the removal and replacement procedures: ● Flat-bladed screwdriver ● Magnetic screwdriver ● Phillips P0 and P1 screwdrivers ● Torx8 T8 screwdriver Service considerations The following sections include some of the considerations that you must keep in mind during disassembly and assembly procedures.

  • Page 33: Cables And Connectors, Drive Handling

    Cables and connectors CAUTION: When servicing the computer, be sure that cables are placed in their proper locations during the reassembly process. Improper cable placement can damage the computer. Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or seat the cables during removal and insertion.

  • Page 34: Grounding Guidelines, Electrostatic Discharge Damage

    Grounding guidelines Electrostatic discharge damage Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure determine the degree of sensitivity. Networks built into many integrated circuits provide some protection, but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions. A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or microcircuitry.

  • Page 35: Packaging And Transporting Guidelines, Workstation Guidelines

    Packaging and transporting guidelines Follow these grounding guidelines when packaging and transporting equipment: ● To avoid hand contact, transport products in static-safe tubes, bags, or boxes. ● Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging. ● Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.

  • Page 36: Equipment Guidelines

    Equipment guidelines Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation. ● When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap snugly against the skin at all times.

  • Page 37: Unknown User Password

    Unknown user password If the computer you are servicing has an unknown user password, follow these steps to clear the password: NOTE: These steps also clear CMOS. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 38: Component Replacement Procedures, Serial Number

    Make special note of each screw size and location during removal and replacement. Serial number Report the computer serial number to HP when requesting information or ordering spare parts. The serial number is located on the bottom of the computer.

  • Page 39: Computer Feet

    Computer feet The computer feet are adhesive-backed rubber pads. The feet are included in the Rubber Kit, spare part number 483382-001. There are 4 rubber feet that are installed on the base enclosure in the locations illustrated below. The rubber feet are attached to the base enclosure by tethers. Component replacement procedures...

  • Page 40: Battery

    Battery Description 6-cell, 55-Wh Li-ion battery 3-cell, 28-Wh Li-ion battery Before disassembling the computer, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.

  • Page 41: Keyboard

    Keyboard Keyboards for use in the following countries or regions: Country or region: Brazil Czechoslovakia Denmark Europe France French Canada Germany Greece Hungary Iceland International Israel Italy Japan Latin America Before removing the keyboard, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 42

    Remove the keyboard: Remove the three Phillips PM2.0×3.0 screws that secure the keyboard to the computer. Turn the computer display-side up, with the front toward you. Open the computer as far as possible. Lift the rear edge of the keyboard (1) until it rests at an angle, and then slide it back (2) until it rests on the display assembly.

  • Page 43

    Release the zero insertion force (ZIF) connector (1) to which the keyboard cable is attached, and disconnect the keyboard cable (2) from the system board. Remove the keyboard. Reverse this procedure to install the keyboard. Component replacement procedures...

  • Page 44: Memory Module

    Memory module Description 2048-MB (PC2-5300, 667-MHz, DDR2) 1024-MB (PC2-5300, 667-MHz, DDR2) 512-MB (PC2-5300, 667-MHz, DDR2) Before removing the memory module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 45: Mass Storage Device

    Mass storage device NOTE: All hard drive and solid-state drive spare part kits include a bracket and SATA adapter. Description SATA hard drives: 160-GB, 7200-rpm hard drive 160-GB, 5400-rpm hard drive 120-GB, 7200-rpm hard drive 120-GB, 5400-rpm hard drive 80-GB solid state drive 4-GB solid state drive Before removing the hard drive or solid-state drive, follow these steps: Shut down the computer.

  • Page 46

    Remove the hard drive or solid-state drive: Disconnect the drive cable (1) from the connector on the system board (2). Remove the Phillips PM2.0×5.0 screw (1) and the two PM2.0×5.0 screws (2) that secure the drive to the computer. NOTE: The screw highlighted by callout (1) is captive in hard drives, non-captive in solid state drives.

  • Page 47: Top Cover

    Top cover Description Top cover Before removing the top cover, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.

  • Page 48

    Lift the rear edge of the top cover (2) and swing it up and forward until it rests upside down in front of the computer. Disconnect the power switch board cable (1) from the system board. Release the ZIF connector (2) to which the TouchPad cable is connected and disconnect the TouchPad cable (3) from the system board.

  • Page 49: Audio Board

    Audio board Description Audio board for use only in computer models with WXGA displays Audio board Before removing the audio board, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 50

    Disconnect the audio board cables (3) from the audio board. Remove the audio board. Reverse this procedure to install the audio board. Chapter 4 Removal and replacement procedures...

  • Page 51: Bluetooth Module

    Bluetooth module NOTE: The Bluetooth module spare part kits do not include a Bluetooth module cable. The Bluetooth module cable is included in the Plastics/Cable Kit, spare part number 483381-001. See Kit on page 19 for more Plastics/Cable Kit spare part number information. Description For use in all countries and regions except Japan and Asia Pacific countries and regions For use only Japan and Asia Pacific countries and regions...

  • Page 52

    Disconnect the Bluetooth module cable (2) from the Bluetooth module. Remove the Bluetooth module. Reverse this procedure to install the Bluetooth module. Chapter 4 Removal and replacement procedures...

  • Page 53: System Board

    System board NOTE: All system board spare part kits include an ExpressCard assembly, fan/heat sink, processor, RTC battery, and replacement thermal material). Description Equipped with 1.6-GHz processor and only for use with WXGA displays Equipped with 1.2-GHz processor and only for use with WXGA displays Equipped with 1.0-GHz processor and only for use with WXGA displays Equipped with 1.6-GHz processor Equipped with 1.2-GHz processor...

  • Page 54

    Remove the system board: Disconnect the following cables from the system board: (1) Display panel cable (2) Microphone cable (3) Camera module cable (only on computer models equipped with webcam) Remove the wireless antenna cables from the clips built onto the system board. Remove the seven Torx8 T8M2.0×6.0 screws (1) that secure the system board and the three system board brackets to the base enclosure.

  • Page 55

    Remove the following brackets: (2) Audio/USB connector bracket (3) ExpressCard assembly bracket (4) USB/RJ-45 connector bracket NOTE: The audio/USB connector bracket, ExpressCard assembly bracket, and USB/RJ-45 connector bracket are included in the Bracket Kit, spare part number 482266-001. Flex the right side of the base enclosure (1) until the USB connector and RJ-45 jack (2) are clear of the base enclosure.

  • Page 56

    Disconnect the WLAN antenna cables from the terminals on the WLAN module. NOTE: The black WLAN antenna cable is connected to the WLAN module “Main” terminal. The white WLAN antenna cable is connected to the WLAN module “Aux” terminal. Remove the system board. Reverse the preceding procedure to install the system board.

  • Page 57: Wlan Module

    WLAN module Description Broadcom 4311AG 802.11a/b/g WLAN modules: ● For use in Canada, the Cayman Islands, Guam, Puerto Rico, the U.S. Virgin Islands, and the United States ● For use in Afghanistan, Albania, Algeria, Andorra, Angola, Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda, Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands, Brunei, Bulgaria, Burkina Faso, Burundi,...

  • Page 58

    Description the United Arab Emirates, the United Kingdom, Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe Before removing the WLAN module, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 59

    Remove the WLAN module (2) by pulling the module away from the slot at an angle. NOTE: WLAN modules are designed with a notch (3) to prevent incorrect insertion. Reverse this procedure to install the WLAN module. Component replacement procedures...

  • Page 60: Rtc Battery

    RTC battery NOTE: Removing the RTC battery and leaving it uninstalled for 5 or more minutes causes all passwords and CMOS settings to be cleared. Description RTC battery Before removing the RTC battery, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.

  • Page 61

    Detach the RTC battery (2) from the system board. NOTE: The RTC battery is attached to the system board with double-sided tape. Remove the RTC battery. Reverse this procedure to install the RTC battery. Component replacement procedures...

  • Page 62: Fan/heat Sink

    Fan/heat sink Description Fan/heat sink Before removing the fan/heat sink, follow these steps: Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system. Disconnect all external devices connected to the computer.

  • Page 63

    Remove the fan/heat sink (2). NOTE: The thermal material must be thoroughly cleaned from the surfaces of the fan/heat sink and system board components. Thermal grease is used on the video chip (1) and the surface of the fan/heat sink (1) that contacts the video chip. Thermal tape is used on the processor (2) and the surface of the fan/heat sink (2) that contacts the processor.

  • Page 64: Display Assembly

    Display assembly NOTE: All display assembly spare part kits include 2 microphones, 2 speakers, and 2 WLAN antenna transceivers and cables. Description 8.9-inch, WXGA display assembly for use only with computer models equipped with camera module 483384-001 8.9-inch, WXGA display assembly for use only with computer models not equipped with camera module 8.9-inch, WSVGA display assembly for use only with computer models equipped with camera module and system boards with the following spare part numbers: 498308-001, 500754-001, and...

  • Page 65

    Lift the display assembly (4) straight up and remove it. Reverse this procedure to reassemble and install the display assembly. Component replacement procedures...

  • Page 66: Starting Computer Setup

    Computer Setup Starting Computer Setup Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating system is not working or will not load. NOTE: Some of the Computer Setup menu items listed in this guide may not be supported by your computer.

  • Page 67: Using Computer Setup, Navigating And Selecting In Computer Setup, Restoring Factory Settings In Computer Setup

    Using Computer Setup Navigating and selecting in Computer Setup The information and settings in Computer Setup are accessed from the File, Security, Diagnostics, and System Configuration menus. Open Computer Setup by turning on or restarting the computer, and then pressing "F10 = ROM Based Setup"...

  • Page 68: Computer Setup Menus, File Menu, Security Menu

    Computer Setup menus The menu tables in this section provide an overview of Computer Setup options. NOTE: Some of the Computer Setup menu items listed in this chapter may not be supported by your computer. File menu Select System information Restore defaults Ignore changes and exit Save changes and exit...

  • Page 69: System Configuration Menu

    System Configuration menu NOTE: Some of the listed System Configuration options may not be supported by your computer. Select Boot Options Device Configurations Built-In Device Options To do this ● Set an delay when starting up. ● Set the Express Boot Popup delay in seconds. ●...

  • Page 70: Computer Specifications

    Specifications Computer specifications Dimensions Depth Width Height (front to back) Weight Equipped with a 3-cell battery, 120-GB hard drive, 1-GB memory, WLAN module, and 2 wireless antennae Equipped with a 3-cell battery, 4-GB solid-state drive, 1-GB memory, WLAN module, and 2 wireless antennae Input power Operating voltage Operating current...

  • Page 71: Inch, Wxga Display Specifications

    Nonoperating NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within this range of temperatures. 8.9-inch, WXGA display specifications Dimensions Height Width Diagonal Number of colors Contrast ratio Brightness Pixel resolution Pitch Format Configuration Backlight Character display Total power consumption...

  • Page 72: Inch, Wsvga Display Specifications

    8.9-inch, WSVGA display specifications Dimensions Height Width Diagonal Number of colors Contrast ratio Brightness Pixel resolution Pitch Format Configuration Backlight Total power consumption Viewing angle Chapter 6 Specifications Metric U.S. 11.3 cm 4.45 in 19.5 cm 7.68 in 22.6 cm 8.90 in 6-bit, 262,144 300:1 (typical)

  • Page 73: Hard Drive Specifications

    Hard drive specifications Dimensions Height Width Weight Interface type Transfer rate Security Seek times (typical read, including setting) Single track Average Maximum Logical blocks Disc rotational speed Operating temperature *1 GB = 1 billion bytes when referring to hard drive storage capacity. Actual accessible capacity is less. Actual drive specifications may differ slightly.

  • Page 74: System Dma Specifications

    System DMA specifications Hardware DMA DMA0 DMA1* DMA2* DMA3 DMA4 DMA5* DMA6 DMA7 *ExpressCard controller can use DMA 1, 2, or 5. Chapter 6 Specifications System function Not applicable Not applicable Not applicable Not applicable Direct memory access controller Available for ExpressCard Not assigned Not assigned...

  • Page 75: System Interrupt Specifications

    System interrupt specifications Hardware IRQ IRQ0 IRQ1 IRQ2 IRQ3 IRQ4 IRQ5* IRQ6 IRQ7* IRQ8 IRQ9* IRQ10* IRQ11 IRQ12 IRQ13 IRQ14 IRQ15 *Default configuration; audio possible configurations are IRQ5, IRQ7, IRQ9, IRQ10, or none. NOTE: ExpressCards may assert IRQ3, IRQ4, IRQ5, IRQ7, IRQ9, IRQ10, IRQ11, or IRQ15. Either the infrared or the serial port may assert IRQ3 or IRQ4.

  • Page 76: System I/o Address Specifications

    System I/O address specifications I/O address (hex) 000 - 00F 010 - 01F 020 - 021 022 - 024 025 - 03F 02E - 02F 040 - 05F 044 - 05F 062 - 063 065 - 06F 070 - 071 072 - 07F 080 - 08F 090 - 091...

  • Page 77

    I/O address (hex) 220 - 22F 230 - 26D 26E - 26 278 - 27F 280 - 2AB 2A0 - 2A7 2A8 - 2E7 2E8 - 2EF 2F0 - 2F7 2F8 - 2FF 300 - 31F 320 - 36F 370 - 377 378 - 37F 380 - 387 388 - 38B...

  • Page 78: System Memory Map Specifications

    System memory map specifications Size 640 KB 128 KB 48 KB 160 KB 64 KB 15 MB 58 MB 58 MB 2 MB 4 GB 64 KB Chapter 6 Specifications Memory address 00000000-0009FFFF 000A0000-000BFFFF 000C0000-000CBFFF 000C8000-000E7FFF 000E8000-000FFFFF 00100000-00FFFFFF 04800000-07FFFFFF 04800000-07FFFFFF 08000000-080FFFFF 08200000-FFFEFFFF FFFF0000-FFFFFFFF...

  • Page 79: Phillips Pm2.0×3.0 Screw

    Screw listing This section provides specification and reference information for the screws and screw locks used in the computer. All screws listed in this section are available in the Screw Kit, spare part number 483383-001. Phillips PM2.0×3.0 screw Color Silver Where used: 3 screws that secure the keyboard to the computer Quantity Length...

  • Page 80: Phillips Pm2.0×5.0 Screw

    Phillips PM2.0×5.0 screw Color Black Where used: 2 screws that secure the mass storage device to the computer Chapter 7 Screw listing Quantity Length 5.0 mm Thread Head diameter 2.0 mm 5.0 mm...

  • Page 81: Torx8 T8m2.0×6.0 Screw

    Torx8 T8M2.0×6.0 screw Color Silver Where used: One screw that secures the audio board to the system board Where used: (1) Three screws that secure the audio/USB connector bracket to the system board Quantity Length 6.0 mm Thread Head diameter 2.0 mm 4.5 mm Torx8 T8M2.0×6.0 screw...

  • Page 82

    (2) Two screws that secure the ExpressCard assembly bracket to the system board (3) Two screws that secure the USB/RJ-45 connector bracket to the system board Where used: 5 screws that secure the fan/heat sink to the system board Chapter 7 Screw listing...

  • Page 83: Torx8 T8m2.5×5.0 Screw

    Torx8 T8M2.5×5.0 screw Color Black Where used: One screw that secures the mass storage device to the computer Quantity Length 5.0 mm Thread Head diameter 2.5 mm 5.0 mm Torx8 T8M2.5×5.0 screw...

  • Page 84

    Where used: One screw that secures the WLAN module to the system board Where used: 2 screws that secure the display assembly to the base enclosure Chapter 7 Screw listing...

  • Page 85: Torx8 T8m2.5×10.0 Screw

    Torx8 T8M2.5×10.0 screw Color Silver Where used: 3 screws that secure the top cover to the computer Where used: One screw that secures the top cover to the computer Quantity Length 10.0 mm Thread Head diameter 2.5 mm 5.0 mm Torx8 T8M2.5×10.0 screw...

  • Page 86: Torx8 T8m2.0×4.0 Screw

    Where used: 4 screws that secure the display assembly to the base enclosure Torx8 T8M2.0×4.0 screw Color Silver Where used: One screw that secures the top cover to the computer Chapter 7 Screw listing Quantity Length 4.0 mm Thread Head diameter 2.0 mm 4.5 mm...

  • Page 87: Backup And Recovery In Windows Vista, Overview, Backing Up, Backup Tips

    Backup and recovery Backup and recovery in Windows Vista Overview To protect your information, use the Backup and Restore Center to back up individual files and folders, back up your entire hard drive (select models only), or create system restore points. In case of system failure, you can use the backup files to restore the contents of your computer.

  • Page 88: Performing A Recovery, Backing Up Your Information, Recovering The Hard Drive Using F11

    The recovery tool reinstalls the operating system and HP programs and drivers that were installed at the factory. Software not installed at the factory must be reinstalled.

  • Page 89

    To recover the original hard drive image, follow these steps: If possible, back up all personal files. If possible, check for the presence of the HP Recovery partition. To find the partition, select Start > Computer. NOTE: If the HP Recovery partition has been deleted, you will need to recover your operating system and programs using the Windows Vista operating system DVD and the Driver Recovery disc (purchased separately).

  • Page 90: Backup And Recovery In Windows Xp, Backing Up Your Information, When To Backup, Backup Suggestions

    Backing up your information NOTE: You can recover only the files that you have previously backed up. HP recommends that you use the Windows backup utility to create a hard drive backup as soon as you set up your computer.

  • Page 91: Backing Up Individual Files Or Folders, Backing Up All Files And Folders, Creating Recovery Points

    Backing up individual files or folders You can back up individual files or folders to an optional external hard drive or to a network drive. NOTE: This process will take several minutes, depending on the file size and the speed of the computer.

  • Page 92: Scheduling Backups, Performing A Recovery

    HP recommends that you create recovery points at the following times: ● Before you add or extensively modify software or hardware ● Periodically, whenever the system is performing optimally NOTE: Recovering to an earlier recovery point does not affect data files or e-mails created since that recovery point.

  • Page 93: Backup And Recovery In Suse Linux Enterprise Desktop, Performing A Recovery

    Using have created and any software installed on the computer are permanently removed. The tool reinstalls the operating system and HP programs and drivers that were installed at the factory. Software not installed at the factory must be reinstalled. To recover the original hard drive image using f11, follow these steps: If possible, back up all personal files.

  • Page 94: Connector Pin Assignments Audio-out (headphone), Audio-in (microphone)

    Connector pin assignments Audio-out (headphone) Audio-in (microphone) Chapter 9 Connector pin assignments Signal Audio out, left channel Audio out, right channel Ground Signal Audio signal in Audio signal in Ground...

  • Page 95: External Monitor

    External monitor Signal Red analog Green analog Blue analog Not connected Ground Ground analog Ground analog Ground analog +5 VDC Ground Monitor detect DDC 2B data Horizontal sync Vertical sync DDC 2B clock External monitor...

  • Page 96: Rj-45 (network), Universal Serial Bus

    RJ-45 (network) Universal Serial Bus Chapter 9 Connector pin assignments Signal Transmit + Transmit - Receive + Unused Unused Receive - Unused Unused Signal +5 VDC Data - Data + Ground...

  • Page 97: Power Cord Set Requirements, Requirements For All Countries And Regions

    10 Power cord set requirements The wide range input feature of the computer permits it to operate from any line voltage from 100 to 120 volts AC or from 220 to 240 volts AC. The 3-conductor power cord set included with the computer meets the requirements for use in the country or region where the equipment is purchased.

  • Page 98: Requirements For Specific Countries And Regions

    Requirements for specific countries and regions Country/region Australia Austria Belgium Canada Denmark Finland France Germany Italy Japan Korea The Netherlands Norway The People's Republic of China Sweden Switzerland Taiwan The United Kingdom The United States The flexible cord must be Type HO5VV-F, 3-conductor, 1.0-mm² conductor size. Power cord set fittings (appliance coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it will be used.

  • Page 99: Recycling Battery, Display

    NOTE: Materials Disposal. This HP product contains mercury in the backlight in the display assembly that might require special handling at end-of-life. Disposal of mercury may be regulated because of environmental considerations. For disposal or recycling information, contact your local authorities, or see the Electronic Industries Alliance (EIA) Web site at http://www.eiae.org.

  • Page 100

    Perform the following steps to disassemble the display assembly: Remove all screw covers (1) and screws (2) that secure the display bezel to the display assembly. Lift up and out on the left and right inside edges (1) and the top and bottom inside edges (2) of the display bezel until the bezel disengages from the display assembly.

  • Page 101

    Disconnect all display panel cables (1) from the display inverter and remove the inverter (2). Remove all screws (1) that secure the display panel assembly to the display enclosure. Remove the display panel assembly (2) from the display enclosure. Turn the display panel assembly upside down. Remove all screws that secure the display panel frame to the display panel.

  • Page 102

    Remove the display panel frame (2) from the display panel. Remove the screws (1) that secure the backlight cover to the display panel. Lift the top edge of the backlight cover (2) and swing it outward. Remove the backlight cover. Turn the display panel right-side up.

  • Page 103

    Remove the backlight cables (1) from the clip (2) in the display panel. Turn the display panel upside down. WARNING! The backlight contains mercury. Exercise caution when removing and handling the backlight to avoid damaging this component and causing exposure to the mercury. Remove the backlight frame from the display panel.

  • Page 104

    Remove the backlight from the backlight frame. Disconnect the display panel cable (1) from the LCD panel. Remove the screws (2) that secure the LCD panel to the display rear panel. Release the LCD panel (3) from the display rear panel. Release the tape (4) that secures the LCD panel to the display rear panel.

  • Page 105: Index

    Index AC adapter, spare part number 19, 21 antenna disconnecting 48 locations 4 audio board removal 41 spare part number 15, 22, 23, 41 audio, product description 2 audio-in jack location 9 pin assignments 86 audio-out jack location 9 pin assignments 86 audio/USB connector bracket illustrated 18 removal 47...

  • Page 106

    File menu 60 flash storage drive, product description 1 fn key 5 front components 7 function keys 5 graphics, product description 1 grounding equipment and methods 28 hard drive precautions 25 product description 1 removal 37 spare part numbers 15, 22, specifications 65 hard drive recovery 80 headphone jack...

  • Page 107

    flash storage drive 1 graphics 1 hard drive 1 keyboard 2 mass storage devices 1 memory module 1 modem 2 operating system 3 optical drive 2 panels 1 pointing devices 2 ports 2 power requirements 3 processors 1 product name 1 security 3 serviceability 3 solid-state drive 1...
