Fan/heat sink

Description
Fan/heat sink for use only in model 2133
Fan/heat sink for use only in model 2140
Before removing the fan/heat sink, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4.
Remove the battery (see
5.
Remove the following components:
a.
Keyboard (see
b.
Hard drive or solid-state drive (see
c.
Top cover (see
d.
Audio board (see
e.
System board (see
If you have model 2133, remove the fan/heat sink:
1.
Following the 1, 2, 3, 4, 5 sequence stamped into the fan/heat sink, remove the five Torx8
T8M2.0×6.0 screws (1) that secure the fan/heat sink to the system board.
68
Chapter 4 Removal and replacement procedures
Battery on page
44).
Keyboard on page
45)
Mass storage device on page
Top cover on page
52)
Audio board (Model 2133 only) on page
System board on page
55)
59)
Spare part number
482279-001
511750-001
49)
