Scope of supply

Standard components
All standard components are also available as spare parts. Further accessories and spare parts
can be found in the separate accessories overview.
Contact your local distributor to order components for your ventilation system.
Component
iV-Smart+
iV-Smart+ Corner
iV-Smart+ Nordic
iV-Smart+ Sylt
iV-Smart+ Top
Standard variant external termination
Smart weather protection hood, white ‒ RAL 9016
Smart weather protection hood, grey ‒ RAL 9006
Smart weather protection hood, Nord ‒ RAL 7011
Smart weather protection hood, anthracite ‒ RAL 7016
Smart weather protection hood, custom colour
Flex weather protection hood, white ‒ RAL 9016
Flex weather protection hood, grey ‒ RAL 9006
Flex weather protection hood, Nord ‒ RAL 7011
Flex weather protection hood, anthracite ‒ RAL 7016
Flex weather protection hood, custom colour
Wall sleeve with Styrofoam discs and mounting wedges
Wall sleeve R-D160x495
Wall sleeve R-D160x745
Thermal accumulator insert
iV-Smart+ thermal accumulator insert
Inner cover
Flair V-223x223 inner cover, white
Special variant: consisting of aluminium, with increased salt resistance
1)
Article numbers of the external termination variants in the separate installation instructions of the respective external termination.
2)
In connection with the Connect controller platform, the inner cover is not part of the scope of delivery. The Connect inner cover is
3)
ordered as part of the Connect controller platform and replaces the Flair or Undercover manual inner cover.
iV-Smart+ ventilation device | Installation instructions
: Weather protection hood including sealing tapes
2)
SCOPE OF SUPPLY
Item number
1001-0170
1001-0173
1001-0223
1001-0179
1001-0182
1508-0062
1508-0063
1508-0069
1508-0124
1508-0068
1508-0157 | 1508-0171
1508-0158 | 1508-0172
1508-0159
1508-0160 | 1508-0173
1508-0161 | 1508-0174
1506-0068
1506-0069
1507-0017
1505-0036
1)
1)
1)
1)
