PREPARING FOR INSTALLATION
3.3

Sectional drawing of the ventilation device

For sectional drawings of other variants of your ventilation device, see the installation instructions
for your specific external termination.
Sectional drawing of the iV-Smart+ standard variant ventilation device
10
4
D
Figure 3: Sectional drawing of the iV-Smart+ ventilation device with Smart (optional Flex) weather protection hood
A Interior plaster/ interior structure
B Masonry
1 Inner cover base plate
2 Inner cover panel
3 R-D160 wall sleeve
4 Smart weather protection hood
5 End-stop tape
16
16
150
6
5
260
43
C
7
1 – 2°
3
≥ 270
B
C Insulation
D Render
6 Thermal accumulator
7 inVENTron:
Xenion reversible fan embedded in double
guiding vane
iV-Smart+ ventilation device | Installation instructions
1
2
61
A
