Multi-zone control
Designation
Number of controll-
able ventilation devices
Multi-zone control
Operating concept
Operating modes
Functions
Fan speed
Unit communication
External interface
For detailed information, see the controller's installation and operating instructions.
iV-Smart+ ventilation device | Installation instructions
SYSTEM OVERVIEW: IV-SMART+ VENTILATION DEVICE
MZ-Home
ON
1 2
Operating Unit & Clust-Air module
Max. 16
(excl. sensors)
max. 4 zones with max. 4 devices
[plus sensors] per zone
Touch
•
Weekly timer
•
Heat recovery
•
Through-ventilation
•
OFF
•
Pause function (1 ... 8h)
•
per zone
Dehumidification with variable
•
air volume flow
4 Output levels,
freely selectable
• Cable
1 potential-free switching contact
per Clust-Air module (max. 4)
Pressure switch (NC/NO)
•
Other sensors (NO)
•
inVENTer Connect
Easy Connect e16
Max. 16
(incl. sensors)
max. 4 zones; any
number of devices per zone
Touch
•
Ventilation profiles
(time controlled)
•
App control
•
Heat recovery
•
Through-ventilation
•
OFF
•
Dehumidification with variable
•
air volume flow and other
demand ventilation
Pause function
•
(global and zonal)
Boost function
•
(global and zonal)
Basement ventilation
•
Summertime ventilation
•
4 Output levels,
freely selectable
• 868 MHz wireless network
• Cable
Several different sensors per
controller platform
(zone division
and number of sensors per zone
arbitrary)
