NOTE: You will then need to drive your vehicle to the predetermined measured mile. During this trip,
the speedometer should read something other than 0 MPH. If it does not change, return and locate the
problem before continuing. Otherwise, proceed with the calibration.
2. Stop at the beginning of the measured mile with your vehicle running and in odometer mode
(NOT trip mode), press and hold the push-button until the odometer displays 'HI-SP'. On its
own, the gauge will then cycle through the recorded performance in the following order: '0 –
60', '1/4', 'ODO', and 'CAL'.
3. While 'CAL' is displayed, quickly tap the push-button once. This will put the speedometer in
Program Mode. If you did not tap while 'CAL' is displayed, the pulses per mile will be displayed
on the odometer and the display will go back to MPH mode. Otherwise, you will now see 'CAL'
displayed along with the number '0'. This indicates that the microprocessor is now ready for
calibration.
4. When you are ready, begin driving on the metered mile. You will notice that the reading will
start counting up. The odometer will begin to display the incoming pulse count. Drive the
vehicle through the measured mile (speed is not important, only the distance traveled).
5. At the end of the mile, stop and press the push-button again. The odometer will now display the
new number of speedometer pulses that were registered over the distance. The odometer will
continue to display the pulse reading for a few seconds. Once it reverts to the default mode,
you have successfully calibrated your speedometer.
Warning: If, while in 'CAL' mode, you do not move the vehicle and press the button again, the
microprocessor will NOT have received any data and the unit will display 'Err' and will revert
to the factory settings. At a minimum, drive some distance and return to the start if necessary. If
you miss stopping the display at 'CAL', simply repeat the steps.
Trip Distance
A single tap of the recall button will activate the trip meter in the odometer display. A decimal point
will appear which will indicate that you are in trip meter mode. Holding the recall button will clear out
the trip distance. To return to the default odometer display, tap the recall button again. The decimal
point will disappear, indicating that you are back in the default odometer display.
Setting the Odometer
While scrolling through 'CAL' mode you will see 'ODO' appear. This will allow you to enter the
vehicle's actual mileage. Press the trip button again at this point and you will enter the odometer set
up mode. Press quickly to change the number of the digit on the right. Press and hold to advance to
the next digit. Do this for all 5 digits. For Example: To enter the mileage reading 23456 into the
odometer, at the 'ODO' prompt, tap the small black button (quickly) two times, until the number 2 is
displayed. Then press and hold the button until the numbers 20 are displayed. Tap the button 3 times
until 23 is displayed. Press and hold the button until 230 is displayed, and continue in this manner until
23456 is displayed. The speedometer will advance to the home screen, five seconds after the last
number is entered.
