PRM1 Register
• HT68F40/HT68F50
Bit 7
Name TCK2PS
R/W R/W
POR 0
Bit 7 TCK2PS: TCK2 Pin Remapping Control
0: TCK2 on PC2
1: TCK2 on PD0
Bit 6 TCK1PS: TCK1 Pin Remapping Control
0: TCK1 on PA4
1: TCK1 on PD3
TCK0PS: TCK0 Pin Remapping Control
Bit 5
0: TCK0 on PA2
1: TCK0 on PD2
Bit 4 Unimplemented, read as "0"
Bit 3~2 INT1PS1, INT1PS0: INT1 Pin Remapping Control
00: INT1 on PA4
01: INT1 on PC5
10: Undefined
11: INT1 on PE7
Bit 1~0 INT0PS1, INT0PS0: INT0 Pin Remapping Control
00: INT0 on PA3
01: INT0 on PC4
10: Undefined
11: INT0 on PE6
Rev. 2.10
HT68F20/HT68F30/HT68F40/HT68F50/HT68F60
HT68FU30/HT68FU40/HT68FU50/HT68FU60
Enhanced I/O Flash Type 8-Bit MCU with EEPROM
6 5 4
TCK1PS TCK0PS —
R/W R/W —
0 0 —
92
3 2 1
INT1PS1 INT1PS0 INT0PS1 INT0PS0
R/W R/W R/W
0 0 0
���� 02� 201�
0
R/W
0
