TMPC1 Register
• HT68F40
Bit 7
Name —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
T2CP1: TP2_1 pin Control
Bit 1
0: Disable
1: Enable
Bit 0 T2CP0: TP2_0 pin Control
0: Disable
1: Enable
• HT68F50/HT68F60
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5 T3CP1: TP3_1 pin Control
0: Disable
1: Enable
Bit 4 T3CP0: TP3_0 pin Control
0: Disable
1: Enable
Bit 3~2 Unimplemented, read as "0"
Bit 1 T2CP1: TP2_1 pin Control
0: Disable
1: Enable
Bit 0 T2CP0: TP2_0 pin Control
0: Disable
1: Enable
Rev. 2.10
HT68F20/HT68F30/HT68F40/HT68F50/HT68F60
HT68FU30/HT68FU40/HT68FU50/HT68FU60
Enhanced I/O Flash Type 8-Bit MCU with EEPROM
6 5 4
— — —
— — —
— — —
6 5 4
— T3CP1 T3CP0
— R/W R/W
— 0 1
108
3 2 1
— — T2CP1 T2CP0
— — R/W
— — 0
3 2 1
— — T2CP1 T2CP0
— — R/W
— — 0
���� 02� 201�
0
R/W
1
0
R/W
1
