Holtek HT68F Series Manual page 199

HT68F20/HT68F30/HT68F40/HT68F50/HT68F60
HT68FU30/HT68FU40/HT68FU50/HT68FU60
Enhanced I/O Flash Type 8-Bit MCU with EEPROM
MFI2 Register
Bit 7
Name DEF
R/W R/W
POR 0
DEF: Data EEPROM interrupt request flag
Bit 7
0: No request
1: Interrupt request
Bit 6 LVF: LVD interrupt request flag
0: No request
1: Interrupt request
Bit 5 XPF: External peripheral interrupt request flag
0: No request
1: Interrupt request
Bit 4 SIMF: SIM interrupt request flag
0: No request
1: Interrupt request
Bit 3 DEE: Data EEPROM Interrupt Control
0: Disable
1: Enable
LVE: LVD Interrupt Control
Bit 2
0: Disable
1: Enable
Bit 1 XPE: External Peripheral Interrupt Control
0: Disable
1: Enable
Bit 0 SIME: SIM Interrupt Control
0: Disable
1: Enable
MFI3 Register
• HT68F50/HT68F60
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5 T3AF: TM3 Comparator A match interrupt request flag
0: No request
1: Interrupt request
T3PF: TM3 Comparator P match interrupt request flag
Bit 4
0: No request
1: Interrupt request
Bit 3~2 Unimplemented, read as "0"
Bit 1 T3AE: TM3 Comparator A match interrupt control
0: Disable
1: Enable
Bit 0 T3PE: TM3 Comparator P match interrupt control
0: Disable
1: Enable
Rev. 2.10
6 5 4
LVF XPF SIMF
R/W R/W R/W
0 0 0
6 5 4
— T3AF T3PF
— R/W R/W
— 0 0
199
3 2 1
DEE LVE XPE
R/W R/W R/W
0 0 0
3 2 1
— — T3AE
— — R/W
— — 0
���� 02� 201�
0
SIME
R/W
0
0
T3PE
R/W
0
