• Address detect mode
Setting the Address Detect function enable control bit, ADDEN, in the UCR2 register, enables
this special function. If this bit is set to "1", then an additional qualifier will be placed on the
generation of a Receiver Data Available interrupt, which is requested by the RXIF flag. If the
ADDEN bit is equal to "1", then when the data is available, an interrupt will only be generated,
if the highest received bit has a high value. Note that the related interrupt enable control bit and
the EMI bit of the microcontroller must also be enabled for correct interrupt generation. The
highest address bit is the 9th bit if the bit BNO=1 or the 8th bit if the bit BNO=0. If the highest
bit is high, then the received word will be defined as an address rather than data. A Data Available
interrupt will be generated every time the last bit of the received word is set. If the ADDEN bit is
equal to "0", then a Receive Data Available interrupt will be generated each time the RXIF flag
is set, irrespective of the data last but status. The address detect and parity functions are mutually
exclusive functions. Therefore if the address detect function is enabled, then to ensure correct
operation, the parity function should be disabled by resetting the parity function enable bit PREN
to zero.
UART Module Power-down and Wake-up
The MCU and UART Module are powered down independently of each other. The method of
powering down the MCU is covered in the previous MCU section of the datasheet. The UART
Module must be powered down before the MCU is powered down. This is implemented by first
clearing the UARTEN bit in the UCR1 register to disable the UART Module circuitry after which
the SCS internal line can be set high to disable the SPI interface circuits. When the UART and
SPI interfaces are powered down, the SCK and CLKI clock sources to the UART module will be
disabled. The UART Module can be powered up by the MCU by first clearing the SCS line to zero
and then setting the UARTEN bit. If the UART circuits is powered down while a transmission is still
in progress, then the transmission will be terminated and the external TX transmit pin will be forced
to a logic high level. In a similar way, if the UART circuits is powered down while receiving data,
then the reception of data will likewise be terminated. When the UART circuits is powered down,
note that the USR, UCR1, UCR2, UCR3, transmit and receive registers, as well as the BRG register
will not be affected.
The UART Module contains a receiver RX pin wake-up function, which is enabled or disabled by
the WAKE bit in the UCR2 register. If this bit, along with the UART enable bit named UARTEN,
the receiver enable bit named RXEN and the receiver interrupt enable bit named RIE, are all set
before the MCU and UART module are is powered down, then a falling edge on the RX pin will
wake up the MCU from its power down condition. Note that as it takes a certain period of time
known as the System Start-up Time for oscillator to restart and stabilize after a wake-up, any data
received during this time on the RX pin will be ignored.
For a UART wake-up interrupt to occur, in addition to the bits for the wake-up enable control
and Receive interrupt enable control being set, the global interrupt enable control and the related
interrupt enable control bits must also be set. If these two bits are not set, then only a wake-up
event will occur and no interrupt will be serviced. Note also that as it takes a period of delay after a
wake-up before normal microcontroller resumes, the relevant UART interrupt will not be serviced
until this period of delay time has elapsed.
