Bit 3 T1OC: TP1_0, TP1_1 Output control bit
Compare Match Output Mode
0: initial low
1: initial high
PWM Mode/Single Pulse Output Mode
0: Active low
1: Active high
This is the output control bit for the TM output pin. Its operation depends upon
whether TM is being used in the Compare Match Output Mode or in the PWM
Mode/Single Pulse Output Mode. It has no effect if the TM is in the Timer/Counter
Mode. In the Compare Match Output Mode it determines the logic level of the TM
output pin before a compare match occurs. In the PWM Mode it determines if the
PWM signal is active high or active low.
Bit 2 T1POL: TP1_0, TP1_1 Output polarity Control
0: Non-invert
1: Invert
This bit controls the polarity of the TP1_0 or TP1_1 output pin. When the bit is set
high the TM output pin will be inverted and not inverted when the bit is zero. It has no
effect if the TM is in the Timer/Counter Mode.
T1DPX: TM1 PWM period/duty Control
Bit 1
0: CCRP - period; CCRA - duty
1: CCRP - duty; CCRA - period
This bit, determines which of the CCRA and CCRP registers are used for period and
duty control of the PWM waveform.
Bit 0 T1CCLR: Select TM1 Counter clear condition
0: TM1 Comparatror P match
1: TM1 Comparatror A match
This bit is used to select the method which clears the counter. Remember that the
Standard TM contains two comparators, Comparator A and Comparator P, either of
which can be selected to clear the internal counter. With the T1CCLR bit set high,
the counter will be cleared when a compare match occurs from the Comparator A.
When the bit is low, the counter will be cleared when a compare match occurs from
the Comparator P or with a counter overflow. A counter overflow clearing method can
only be implemented if the CCRP bits are all cleared to zero. The T1CCLR bit is not
used in the PWM, Single Pulse or Input Capture Mode.
